S
KIT/18F -
KIT FOR SLIDING GATES UP TO 1800 kg - 230/400 V~
SR 24.19F
KIT/25H -
MOTOR WITH CONTROL UNIT FOR SLIDING GATES UP TO 2500 kg - 230/400 V~
SR 24.24
KIT/18H -
MOTOR WITH CONTROL UNIT FOR SLIDING GATES UP TO 1800 kg - 230/400 V~
SR 24.20
Thank you for choosing a SERAI ELETTRONICA product, which we are confident will perform to your requirements.
Please be advised that you are about to fit a system classified as "a power-operated drive designed to move automatic
gates and doors in commercial or residential buildings accessed by vehicles and persons", and, as such, the system
must be considered potentially hazardous. By law, you are responsible for rendering this equipment as "safe" as is
reasonably possible.
Installation and maintenance of equipment of this kind must therefore be carried out by skilled, qualified and trained
personnel, working in a professional manner, as provided for by law n. 46/90 and subsequent amendments and
supplements thereto. The law in question prohibits the construction of these types of systems by non-qualified
personnel.
SERAI manufacturing complies with the following legislation:
Applicable directives for the CE marking:
Machines:
Low voltage:
Electromagnetic compatibility:
R&TTE (Radio and Telecommunications Terminal Equipment):
General applicable standards:
Electrical safety:
Electromagnetic compatibility - emissions:
Electromagnetic compatibility - immunity:
Apart from the legislation mentioned above, you are also reminded to comply with the following standards during the
installation phase.
General applicable standards:
Safety of electrical systems in non-specialised environments:
Specific product standards applicable:
Safety in the use of power-operated doors requirements:
Safety in the use of power-operated doors testing methods:
SERAI products enable users to build systems which comply with these standards. This is extremely important as
!
THE INSTALLER IS LIABLE FOR THE SYSTEM AND FOR ENSURING ITS OPERATION COMPLIES WITH
LEGAL PROVISIONS.
This handbook must be read in full, at least once, before proceeding with the installation of the various parts
of the system.
The installation of the mechanical end stops for gate opening and closure is necessary for system safety
purposes and therefore this operation must be performed before proceeding with the installation of the
control unit.
E
R
GATE AUTOMATION DIVISION
INSTALLATION MANUAL
A
I
98/37/EEC
73/23/EEC
89/336/EEC
99/5/EEC
IEC EN60335-1 + IEC EN60335-2-103
IEC EN61000-6-3
IEC EN61000-6-1
CEI 64-8
UNI EN12453
UNI EN12445
Pag. 1/10
Advertisement
Related Manuals for Serai KIT/18F
Summary of Contents for Serai KIT/18F
- Page 1 MOTOR WITH CONTROL UNIT FOR SLIDING GATES UP TO 1800 kg - 230/400 V~ SR 24.20 Thank you for choosing a SERAI ELETTRONICA product, which we are confident will perform to your requirements. Please be advised that you are about to fit a system classified as “a power-operated drive designed to move automatic gates and doors in commercial or residential buildings accessed by vehicles and persons”, and, as such, the system...
- Page 2 COMPONENTS OF THE KIT KIT/18F KIT/18H KIT/25H Motor MT/18 Motor MT/25 with inside fan Electronic control panel CR/14 Radio receiver card SOG/4A Minitransmitter OG/62 Flasher with antenna RZ/07/1F Electric key M/10 Pair of photocells P/94 Pair of limit switch slide blocks...
-
Page 3: Standard Installation
STANDARD INSTALLATION 4x0,5 mm² 4 x 0 , 5 2 x 0 , 5 m m ² m m ² 3 x 1 , 5 m m ² 2 x 0 , 5 m m ² 4 0 0 V 2 x 0 , 5 m m ²... - Page 4 1) BEFORE BEGINNING THE INSTALLATION OF THE GEARED MOTOR - Check that the gate is provided with a rugged rail. - Check that the rail is well fixed in the ground. - Check that some rugged stop blocks are fixed at the further ends of the rail.
- Page 5 5) INSTALLATION OF THE RACK MT/25 MT/18 - Release the motor. Insert the key in the cylinder, give it half a turn anticlockwise and then take key and cylinder out. Insert the hexagonal release key and turn it clockwise until it stops (Picture 5). - Solder the rack to an iron angle bar (ex: 40 ×...
- Page 6 7) ADJUSTING OF THE MOTOR POWE MT/18 ATTENTION: Turn power supply off, the HEXAGONAL RELEASE KEY motor could be accidentally started up while the friction is being adjusted. FLAT KEY a) Insert the release key in the hexagonal opening of the driving shaft. b) Insert the flat key in the opening on the motor flange so as to block the driving mast ring nut.
-
Page 7: Wiring Diagram
WIRING DIAGRAM TRIMMER DIP-SWITCH CR/14 FUSE F1 F2 F3 F4 CN 1 CN 1 250V~ F4 500mA 250V~ WIRING DIAGRAM CR/14 PER 400V~ -factory setup- STOP OPEN/ CLOSE MOTOR 400 V~ FLASHING LIGHT THREE-PHASE 230V~ single-phase -see Fig.11- GATE OPEN INDICATOR INSIDE FAN 230V~ single-phase... - Page 8 MOTOR CONNECTIONS MOTOR ON THE LEFT MOTOR ON THE RIGHT (FACTORY SETUP) 15 16 17 To connect the motor on the left-hand side of the CR/14 BLACK gate, swap the following connections: BROWN R S T 4 with 5 BLUE 16 with 17 GROUND CONNECTION BETWEEN MOTOR AND HOUSE-PLANT YELLOW-GREEN CABLE...
- Page 9 RADIO CONTROL 433,92 MHz ELECTRIC LOCK 1° CHANNEL MEMORY EXPANSION FROM N°40 TX TO N°834 LIGHTS 2° CHANNEL BISTABLE MONOSTABLE FUNCTION FUNCTION 1A 24 V~ CR/14 ANTENNA F1 F2 F3 F4 CN 1 RADIO CARD PROGRAMMING ATTENTION: before using each minitransmitter it is 1°...
- Page 10 TERMS OF GUARANTEE The company reserves the right to make modifications to the equipment without prior notice thereof. SERAI products are covered by a standard guarantee with a term of 24 months. Coverage starts on the date on which the tax document constituting proof of purchase is issued and guarantee services shall be provided on the company's premises at Legnaro - PD - or at the Authorised Service Centres.
