AquaKing

User's Guide
 WARNING!
Read the technical instructions before installing the bath
Read the users instructions before using the bath
Do not bring sharp objects into the bath
Contact the seller if the colours appear to be changing under or on top of the coating
If a leakage appears contact the seller immediately.
All electrical work should be perfomed by a qualified electrician
Do not leave children in the bath without supervision
Do not sit with your back or head against the skimmer
For AquaKing a mains connection of 230V, 1x16A, 2x16A with Ground Fault Current Interrupt (GCFI) is required. A service
switch, which is closely installed to the electrical connection is recommended.
ATTENTION! If the hot tub will be integrated e.g. into a terrace it is necessary that the access is not obstructed in any way
order to be able to service it. Service hatch and outer panel should be removable without difficulties.
If automatic dispensers (floating, etc.) are used, careful adjustment should be made to avoid incorrect dosage. Follow the
recommendations in our instructions.
The circulation pump also generates heat and if it is running a long time (eg, continuous filtration TM) it can raise the
temperature by several degrees in one day when the tub is well insulated.
Check the quality of the water, as well as temperature and function, regularly, don't leave the spa unmonitored for long time
periods.


Advertisement

loading
Need help?

Need help?

Do you have a question about the Polar AquaKing and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for SpaDealers Polar AquaKing

  • Page 1 AquaKing     User’s Guide  WARNING!  Read the technical instructions before installing the bath  Read the users instructions before using the bath  Do not bring sharp objects into the bath  Contact the seller if the colours appear to be changing under or on top of the coating ...
  • Page 2 2289 (2620) ~ 1814,5 (2057) Water drainage and electric wiring Hose Ø 33 mm Article Part Number Material Page Size Polar AquaKing LunaWood 2248 (2570) Designed by Scale JI 31.01.11 1:18 Checked by Revision v 2.4 Aproved by Sheet 23/23...
  • Page 3 1  2  4  3 ...
  • Page 4 5  6  7  8 ...
  • Page 5 Picture 2 show how the air pump for the bubble system is placed. It should not be oriented with the air exhaust upwards. If the AquaKing is equipped with the BactiSafe (accessory) then it is positioned according to picture 1. The control system is fastened in the position that is shown in picture 2.
  • Page 6: Water Level

    CLEANING AND CHANGING THE FILTER           3    A    B        All screw connections must use the rubber seals provided. Own Assembly: During assembly of wall and base fittings, silicone shall be used on both sides of the connections, as well as the threads. ATTENTION! Near the bottom of the filter holder there is an arrow, which must be pointed towards the pump.
  • Page 7 CLEANING AND CHANGING THE FILTER   Cleaning /change of filter AquaKing For a good water hygiene it is very important that the filter gets cleaned on a regular basis. At least every second week it should be rinsed. Every second month or whenever it is required it needs to get cleaned “thoroughly”...
  • Page 8: Installation

    USER MANUAL for the SG‐0007B SYSTEM  This  product  is  meant  to  be  used  for  electronic  control  of  functions  for  spa  baths.  Please  read  all  of  the  instructions  carefully  before  enjoying  the  spa.  WARNING:  Operating  the  system  without  water  will  cause  severe  damage.  Contains  electronic  components,  shock  hazard.  Does  not  contain  user  serviceable  parts.  Do  not  try  to  repair  the  control  unit.  Contact your dealer or service center for help. Follow all user instructions. ...
  • Page 9 II. Operating instructions                                  (Fig 2)   ON/OFF key (power key): Connect the power supply and press the ON/OFF key. All the control systems are now ready to run  (indicator light is on), and the circulation and Ozone disinfection system (if one exists) will start working automatically (if the  water temperature is not at the pre‐set temperature, the heating system will start to work in 60 seconds). The panel will  display the circulation and Ozone symbols (a symbol for the heating system              will also be displayed on the panel if the  heating system is working). The panel will also display the detected water temperature. Note! If no button is pressed within  60 seconds, the displays backlight goes off, it reactivates if a button is pressed.   PUMP  key:  press  the  (JET1) key.  Its  symbol   ...
  • Page 10 the +/‐ key will adjust the current frequency. This frequency will be stored automatically after flashing for 3 seconds. With a  third  press,  the  panel  will  show  the  radio  channel.  Press  the  +/‐  key  to  select  pre‐stored  radio  stations  (  the  panel  will  automatically show the previous radio frequency after you stop adjusting for 3 seconds). With a long press for 5 seconds, the  system  will  automatically  search  for  radio  frequencies  again  and  store  the  searched  frequencies  at  a  different  channel  sequentially. ...
  • Page 11 NOTE:   If the spa is in automatic working mode, please don’t turn off the spa when not in use. Make sure the spa is  always “on”.   When in automatic mode, the filtration pump will also be controlled by temperature. If the water temperature  is lower than the preset level, during the “OFF” period, the filtration pump and heater will work until the water  temperature has reached the preset level. Then, the filtration pump will return to work for 1 hour and stop for  3  hours  repeatedly.  When  the  automatic  mode  is  not  in  use  the  circulation  pump  is  always  on.  If  the  water  temperature drops 2° under the pre‐set level the heater will activate.   Each time the spa is switched on, the system will go into the previously set mode. Press and hold the    or    key for 3 seconds (the indicator will show GREEN) to switch between automatic mode and manual mode.    Summary:    and    If ...
