- Page 1 English Worktop lift Baselift 6210 Doc. No: M6210 Edition: 5 Datum: 2017-06-19 INSTUCTION MANUAL Floor-standing worktop lift Baselift 6210...
- Page 2 For more information, see: www.granberg.se...
-
Page 3: Table Of Contents
Contents Section: Headline: Page: Introduction ..............................4 Declaration of conformity with EU directives ..................4 Intended use - Technical data ........................4 Mounting Instructions:: Mechanical construction ...........................5 Modules delivered ............................6 Planning sketch, location of electrical outlets, water and sewer ..........7 Electrical connection ...........................8 Water and sewer connection ........................8 Assembly .................................9 Mounting the fronts .......................... -
Page 4: Introduction
We have the pleasure to deliver a Granberg worktop lift Baselift, an electrically operated lifting and lowering system . The worktop lift used separately, or together with the Granberg Wall cabinet lifts and becomes then a total adaptation of the kit- chen. -
Page 5: Mechanical Construction
Technical data Model: 6210 Build Form Straight Width 590 - 3400 mm Worktop height, excl. top 650 - 950 mm Depth, from wall, excl. front 560 - 580 mm Vertical stroke, max 300 mm Time for lifting or lowering movement approx. -
Page 6: Modules Delivered
Modules delivered The worktop lift is delivered in boxes, parts should be installed according to instructions. All installation work must be perfor- med by persons with the necessary expertise. Installers should have red these instructions, and perform the installation in the prescribed manner. -
Page 7: Planning Sketch, Location Of Electrical Outlets, Water And Sewer
Planning sketch, location of electrical outlets, water and sewer Electrical outlets, water and sewer connection must be placed in the marked spaces below. Baselift 6210 with one motor pillar (59,0 - 180 cm) B = Width of worktop lift Sketch of the floor plate... -
Page 8: Electrical Connection
Professionals must make the connection of the water and sewer pipes, to prevent water damages. It is important that the right materials are used, and that location and fixing ismade properly. The use of Granberg original installation materials, and the instructions in this manual, ensures correct execution, if a competent fitter carries out the installation work. -
Page 9: Assembly
Mounting a straight Baselift 6210 Note! - Check if the floor is equipped with floor heating before installation! - Tiles on the wall will be put before the assembly of the worktop lift begins. - To facilitate the placement laterally mounted cabinets on one side before bench lifter mounted. - Page 10 4.6.1 Check the type of floor and the floor’s stability before fixation. If the floor’s condition is poor, an additional wall mount can be ordered. The wall bracket secures stability 4.6.2 1. Remove the screws and washers that are slotted nuts in the aluminum profile. 2.
- Page 11 4.6.4 Connect the motors, the security strip, push button and the electricity cable according the instructions below. Synchronise the motors (if the lifting system have two motors): Run the lift to it’s lower position and hold the button (at least 5 sec.) until you hear a click from the control box. The synchronisation has succeed when you hear the click sound.
- Page 12 4.6.5 Adjust the aluminium frame in depth and side wise. Adjust the depth so it suits with the rest of the kitchen. (The depth is adjustable between 560 to 580 mm). A gap of at least 5 mm must exist around the bench lifter! Lock the position when the adjustment is ready.
-
Page 13: Mounting The Fronts
The distance between the holes shall be 72 mm centre - centre. Power switch can also be used in combination with buttons. Power switch must be moun- ted together with a damp-proof cover that is delivered from Granberg. The hole for power switch shall be 73 mm. -
Page 14: Mounting The Trailing Edge Aluminum
Mounting the trailing edge Aluminum If the trailing edge Aluminum is mounted on complete sink, the metal must be predrilled with a 2 mm drill. 4.10 Mounting the worktop Place the top board at the worktop lift and mark where the hob and sink are going to be placed. -
Page 15: Mounting Of Complete Sink Units
Granberg worktop lifts do only suit complete sinks delivered from Granberg. (These sinks are special made to suit the worktop lift). Do always contact granberg before use of a complete sink that is not delivered by Granberg. See section 4.5 for correct drain connection. -
Page 16: Installation Of The Cover Plates
The upper and lower cover plate has the same dimension. The thickness of the plate can be 12 - 16 mm. If cover plates are not ordered from Granberg, see dimensions according the sketch to the right. 4.12.1 Mounting the lower cover plate 1. -
Page 17: Operation Test
4.13 Operation Test After installation a complete functional test with full load shall be made: • Run the worktop lift up and down all the way to respectively end position. Check that the bench runs freely without trapping risks and jarring sounds. Make sure it stays in the lower respective upper positions. •... -
Page 18: Safe Use
• Decals and markings must not be removed or made illegible. • During inspections, service and repair work there shall be no load on the worktop or in the cabinets. The most common func- tions can be reached when the cover panels have been removed. • Competent persons only must carry out installation, service and repair works. • Only Granberg original spare parts shall be used when replacing any parts. Our warranty commitment can otherwise be invalidated. Safety arrangements The underside of the Worktop lift unit is provided with a se- curity strip. If the security strip is pressed during lowering, the worktop lift unit shall stop immediately. -
Page 19: Load Distribution And Lateral Forces
Discuss suitable actions with your Granberg representative or with the health and safety inspection. We recommend that a Risk assessment in accordance with the Machinery Directive shall be made for the actual working con- ditions. If the owner fits accessories, contact Granberg to get approval for the loading conditions. Actions after use TheWorktop lift unit shall after use be left in its current position. -
Page 20: Cleaning
When the Diagonal lift unit shall be re-used shall it must be cleaned, inspected and go through a full operation test before it is installed on the new site. We recommend the machine to be sent to Granberg or to the Granberg distributor to get this done. The machine ismanufac- tured from re-usable materials or from materials that can be recycled. -
Page 21: Warranty
Damages caused by misuse or incorrect operation of the equipment means that the warranty would expire. Before any warranty work is commenced by a customer Granberg must be contacted for analysis and approval. We do not ac- cept to carry any warranty costs if the repair work has started without an agreement by us. -
Page 22: Troubleshooting
(See section 4.13). Spare parts list If any component does not work or has broken, contact your supplier. Only Granberg original spare parts must be used when replacing any parts.Our warranty commitment may otherwise be invalidated. -
Page 23: Electric System / Electric Circuit Diagram
Electric system / Electric diagram Control box, 2-3 motors Control box, 4 motors CE-Declaration of conformity (According Machinery Directive 2006/42/EG, Annexe 2A) Manufacturer: Granberg Interior AB Tel. +46-11-19 77 50 Box 6112, SE-600 06 NORRKÖPING, Sweden declares under sole responsibility that the product:... - Page 24 Granberg Interior AB Box 6112 600 06, Norrköping, Sweden Tel: +46(0)11-19 77 50 E-mail: info@granberg.se Internet: www.granberg.se...
