Full-Length Mirrored Cabinet
Congratulations on your purchase of Americas finest Mirrored Cabinet by GlassCrafters, Inc.
World class engineering and state of the art design will enable you to enjoy your cabinet for many years to come.
We realize that the marketplace offers many choices and we thank you for selecting
The following instruction sheets include the ALL MODELS listed below in both
To insure proper installation we recommend installation by a professional installer.
To view a video showing helpful tips
on how to --
adjust our Cabinet HInges
or
to install our Mirrored Side Kits,
please go to:
GlassCraftersMirroredCabinets.com
and navigate to the cabinet product
that you are installing.
Simply click on the
installation tab
(located below the
product images)
to view our
installation videos."
SAVE THESE INSTRUCTIONS
FOR FUTURE REFERNCE
Please use extreme care while unpacking and handling your GlassCrafters' Mirrored Cabinet. Report any damage
immediately to our GlassCrafters customer service team at 800-233-7362,
GLASSCRAFTERS, INC
193 Veterans Blvd., Carlstadt, NJ 07072
Installation Instructions
GlassCrafters for your Mirrored Cabinet needs.
4" deep and 6" deep Mirrored Cabinets.
GC1672
Monday thru Friday from 8:00 am to 5:00 pm (EST)
1+(800) 233-7362 (F) 1+(888) 233-7362
sales@glasscraftersinc.com
GC2072
1
Revised 05/2016
Advertisement
Related Manuals for GlassCrafters GC1672
Summary of Contents for GlassCrafters GC1672
-
Page 1: Installation Instructions
SAVE THESE INSTRUCTIONS FOR FUTURE REFERNCE Please use extreme care while unpacking and handling your GlassCrafters’ Mirrored Cabinet. Report any damage immediately to our GlassCrafters customer service team at 800-233-7362, Monday thru Friday from 8:00 am to 5:00 pm (EST) -
Page 2: Table Of Contents
Full-Length Mirrored Cabinet Installation -- Unpack all parts carefully and protect Glass and Mirror parts during installation. Index Surface Mount Side Kit Installation....7 Parts List for All Models ........2 Glass Shelves...........8 Determining the Rough Opening......3 Cleaning Recommendation ......8 & 12 Recessing the Cabinet ........4 Door Installation and Adjustment......9 Combining two (2) or three (3) Cabinets ..5... -
Page 3: Determining The Rough Opening
Tools Required for Installation E. Power Screw Driver GlassCrafters recommends the following tools to F. Electric Drill properly and safely install your Mirrored Cabinets. G. 8mm 3/16” Masonry Drill Bit H. 7/32” Drill Bit A. Safety Glasses -- should be worn at all times I. - Page 4 Installing a Recessed & Semi-Recessed Mirrored Cabinet A. Determine the rough opening for the cabinet. Refer to “R.O.” formula chart on page 3. Opening must be plumb and level. B. Cabinet comes hinged on left or righ side. Be sure to determine the proper hinge location for the unit before in- stalling.
-
Page 5: Combining Two (2) Or Three (3) Cabinets
Combining Two (2) or Three (3) Parts required to join Two (2) Cabinets: Cabinet Units before Installation. Cabinet Connector Screws Screw Qty depth Part# Caps Any of the cabinets that are the same height may be 4” deep #426 10-32 x 1 1/2” 12 #434 12 joined to form one unit. - Page 6 Installing a Surface Mount Mirrored Cabinet A. Determine the desired height and use a level to mark a horizontal line. Be sure to allow a minimum clearance of 1” above any base molding or a mini- mum of 4” for Toe Kick. Remember the base of the cabinet box is 3/4” smaller than the face and the door.
- Page 7 Side Mirror Kit Installation Align mirror to level with Top Edge For surface mounted 4” & 6” Mirrored Cabinet and semi-recessed 6” Mirrored Side Mirror Kit Bracket Cabinets. Peel off paper covering adhesive 1) Attach the side mirror kit brackets thru the pre-punched holes in your cabinet.
-
Page 8: Glass Shelves
Glass Shelves Installation For cleaning the mirror, we recommend using “ammonia free” Sprayway brand glass cleaner, After the Mirrored Cabinet box has been properly in- which is available at a variety of retail outlets. stalled, determine the appropriate height and location for www.spraywayinc.com/content/glass-cleaner the glass shelves. - Page 9 Door Installation 2) Lift and snap The doors are packed individually for protection of the Door with Hinge into place mirror surfaces. Carefully remove the door from the carton.* Hold the door in the upright position snap open the factory installed hinges. Place the hinge onto Hinge Plate the factory-installed mounting plate in the cabinet -- 1) Insert into...
-
Page 10: Limit Clips
Limit Clips Limit Clips are provided should you need to reduce the opening swing of the cabinet door from 170 degrees to 130 degrees (see top view) This will eliminate the possi- bility of the door hitting a wall sconce or other decorative items. - Page 11 Master Parts List for Full-Length Mirrored Cabinets This installation manual serves the complete line of Model: GC1672-4" GlassCrafters Full-Length Model: GC 1672-6” Mirrored Cabinets including all Qty. Part Number 4” deep and 6” deep models. Cabinet 4" Cabinet GC1672-4-Cab The general parts list pictured Cabinet 6"...
-
Page 12: Warranty
Blum, Inc. will send replacement hardware without charge. warded in writing to GlassCrafters within three years of the delivery date to the end user of the product. GlassCrafters shall not be responsible for any installation or removal GlassCrafters shall not have any liability for any consequential damages stemming costs.
