Connector pin-outs

VGA connector

EGA connector

802R-PCI Video Test Generator User Guide (Rev A)
Pin Description
1 Analog red video
2 Analog green video
3 Analog blue video
4 No connection
5 Digital ground
6 Red analog video ground
7 Green analog video ground
8 Blue analog video ground
Pin Description
1 Ground
2 Red intensity
3 Red
4 Green
5 Blue
6 Green intensity
7 Blue intensity
8 Horizontal sync
9 Vertical sync
Pin Description
9 DDC/EDID +5 VDC out
10 Digital ground
11 No connection
12 DDC/EDID serial data
13 Horizontal sync
14 Vertical sync
15 DDC/EDID data clock
