Page 16
Pin assignments for the RS-485 Connector of the AXIS Q7900 Rack
Pin
AXIS Q7406
1
Channel 1, RS485A
2
Channel 1, RS485B
3
Channel 2, RS485A
4
Channel 2, RS485B
5
Channel 3, RS485A
6
Channel 3, RS485B
7
Channel 4, RS485A
8
Channel 4, RS485B
9
Channel 5, RS485A
10
Channel 5, RS485B
11
Channel 6, RS485A
12
Channel 6, RS485B
Note:
For RS-485 unit connector information for the AXIS Q7406 see Unit connectors, on page 13. For
other video encoders, refer to their respective Installation Guide for I/O connector information.
LED Indicators
Green
Status
Red
Green/red
Green
Power
Green/Amber Flashes for one or more channel upgrade
Steady green - normal operation
One flash - the corresponding channel is starting up
Two flashes - the corresponding channel is resetting to factory default settings
Steady red - hardware error on the corresponding channel
Flashes for no connection to AXIS Internet Dynamic DNS Service
Normal operation
AXIS Q7406 Installation Guide
