Sony XCU-CG160 Technical Manual page 35

Category ( ) / Sub category (
Feature
DeviceLinkThroughputLimit
DeviceLinkConnectionCount
DeviceLinkCommandTimeout
DeviceStreamChannelCount
DeviceStreamChannelSelector
DeviceStreamChannelType
DeviceStreamChannelLink
DeviceStreamChannelEndianness
DeviceEventChannelCount
DeviceCharacterSet
DeviceReset
DeviceRegistersEndianness
DeviceTemperature
TimestampLatch
TimestampLatchValue
FactoryDefault
ImageFormatControl
SensorWidth
SensorHeight
SensorUnitCellSizeH
SensorUnitCellSizeV
WidthMax
HeightMax
Width
Height
OffsetX
OffsetY
BinningHorizontal
BinningVertical
ReverseX
ReverseY
PixelFormat
PixelSize
TestPattern
*1 RO: Read only, WO: Write only, RW: Read/Write
*2 Color cameras are RO.
*3 Target models: Color cameras
*4 Enabled when color camera is set to BGR8, YCbCr8, or YCbCr422_8.
*5 Target camera mode: NORMAL
) Read/ Description
*1
Write
RW Limits the maximum bandwidth of the data that will be
streamed out by the device on the selected link.
RO Returns the number of physical connection of the device
used by a particular link.
RO Indicates the command timeout of the specified link.
RO Indicates the number of streaming channels supported by the
device.
RW Selects the stream channel to control.
RO Returns the type of the stream channel.
RW Index of device's link to use for streaming the specified
stream channel.
RO Endianness of multi-byte pixel data for this stream.
RO Indicates the number of event channels supported by the
device.
RO Character set used by the strings of the device's bootstrap
registers.
WO Resets the device to its power up state.
RO Endianness of the registers of the device.
RO Device temperature in degrees Celsius (°C).
WO Latches the current timestamp counter into
TimestampLatchValue.
RO Returns the latched value of the timestamp counter.
RW Restores all settings to the factory default.
RO Category for image format control features.
RO Effective width of the sensor (in pixels).
RO Effective height of the sensor (in pixels).
RO Horizontal pixel cell size.
RO Vertical pixel cell size.
RO Maximum width of the image (in pixels).
RO Maximum height of the image (in pixels).
RW Width of the image provided by the device (in pixels).
RW Height of the image provided by the device (in pixels).
RW Horizontal offset from the origin to the region of interest (in
pixels).
RW Vertical offset from the origin to the region of interest (in
pixels).
*2
RW Number of horizontal photo-sensitive cells to combine
together.
*2
RW Number of vertical photo-sensitive cells to combine together. 11
RW Flip horizontally the image sent by the device.
RW Flip vertically the image sent by the device.
RW Format of the pixels provided by the device.
RO Total size in bits of a pixel of the image.
RW Selects the type of test pattern that is generated by the device
as the image source.
35
See
page
–
–
–
–
–
–
–
–
–
–
33
–
30
–
–
–
–
–
–
–
–
–
–
11
11
11
11
11
15
15
14
–
26
