Sony XCD-SX90 Service Manual

B/w digital camera module; color digital camera module
Hide thumbs

Advertisement

B/W DIGITAL CAMERA MODULE
XCD-U100
XCD-SX90
XCD-V60
COLOR DIGITAL CAMERA MODULE
XCD-U100CR
XCD-SX90CR
XCD-V60CR
SERVICE MANUAL
1st Edition

Advertisement

Table of Contents
loading

  Related Manuals for Sony XCD-SX90

  Summary of Contents for Sony XCD-SX90

  • Page 1 B/W DIGITAL CAMERA MODULE XCD-U100 XCD-SX90 XCD-V60 COLOR DIGITAL CAMERA MODULE XCD-U100CR XCD-SX90CR XCD-V60CR SERVICE MANUAL 1st Edition...
  • Page 2 ! WARNING This manual is intended for qualified service personnel only. To reduce the risk of electric shock, fire or injury, do not perform any servicing other than that contained in the operating instructions unless you are qualified to do so. Refer all servicing to qualified service personnel.
  • Page 3: Table Of Contents

    Manual Structure Purpose of this manual ... 3 Related manuals ... 3 1. Service Overview 1-1. Board Location ... 1-1 1-2. Removing/Installing the Cabinet ... 1-1 1-2-1. Upper case/Lower case ... 1-1 1-2-2. Rear Panel Assembly ... 1-2 1-2-3. Front Panel Assembly ... 1-2 1-3.
  • Page 5: Manual Structure

    XCD-U100/SX90/V60 XCD-U100CR/SX90CR/V60CR Manual Structure This manual is the Service Manual of the B/W Digital Camera Module XCD-U100/ SX90/V60 and Color Digital Camera Module XCD-U100CR/SX90CR/V60CR. This manual contains the service overview, adjustment, circuit description, spare parts, block diagrams, and frame wiring.
  • Page 7: Service Overview

    FM-96 board CN-3020 board DC-DC converter IF-1068 board BI-217/218/219 board Board name Model name BI-217 board XCD-V60 XCD-V60CR BI-218 board XCD-SX90 XCD-SX90CR BI-219 board XCD-U100 XCD-U100CR CN-3020 board Common DC-DC converter XCD-V60/V60CR/U100/U100CR XCD-SX90/SX90CR FM-96 board Refer to “Section 4 Spare Parts”...
  • Page 8: Rear Panel Assembly

    PM2 x 4 cable CN101 BI-217/218/219 board Front panel assembly This illustration is for XCD-SX90/SX90CR. 4. Attach the front panel assembly in the reverse order of steps 1 to 3. Front panel assembly When attaching the front panel assembly, securely attach it while pushing it against the chassis.
  • Page 9: Removing/Installing The Board

    (Refer to Section 1-2-3.) 4. Disconnect the three flexible flat cables from the connectors (CN200, CN400 and CN700) on the FM-96 board. 5. XCD-SX90/SX90CR: Remove the three screws, then remove the shield sheet and FM-96 board. XCD-V60/V60CR/U100/U100CR: Remove the three screws, then remove the FM-96 board.
  • Page 10: Dc-Dc Converter

    1-3-3. DC-DC Converter 1. Remove the upper case and lower case. (Refer to Section 1-2-1.) 2. Remove the rear panel assembly. (Refer to Section 1-2-2.) 3. Remove the front panel assembly. (Refer to Section 1-2-3.) 4. Remove the FM-96 board. (Refer to Section 1-3-2.) 5.
  • Page 11: Cn-3020 Board

    1-3-5. CN-3020 Board 1. Remove the upper case and lower case. (Refer to Section 1-2-1.) 2. Remove the rear panel assembly. (Refer to Section 1-2-2.) 3. Remove the twelve solders of the connector from the CN-3020 board. 4. Remove the screw, then remove the CN-3020 board. Rear panel assembly Solders PM2 x 4...
  • Page 12: Lens Mount Cap, Filter Bracket, Optical Dust Cover (Xcd-V60/Sx90/U100), Infrared Cut Filter (Xcd- V60Cr/Sx90Cr/U100Cr), Sealing Rubber

    1-4. Lens Mount Cap, Filter Bracket, Optical Dust Cover (XCD-V60/SX90/ U100), Infrared Cut Filter (XCD-V60CR/SX90CR/U100CR), Sealing Rubber 1. Remove the upper case and lower case. (Refer to Section 1-2-1.) 2. Remove the front panel assembly. (Refer to Section 1-2-3.) 3. Remove the lens mount cap. 4.
  • Page 13: Round Type Connector (12-Pin)

    1-5. Round Type Connector (12-Pin) 1. Remove the upper case and lower case. (Refer to Section 1-2-1.) 2. Remove the rear panel assembly. (Refer to Section 1-2-2.) 3. Remove the CN-3020 board. (Refer to Section 1-3-5.) 4. Remove the nut and washer, then remove the round type connector (12-pin).
  • Page 14: Unleaded Solder

    1-8. Unleaded Solder Boards requiring use of unleaded solder are printed with a lead free mark (LF) indicating the solder contains no lead.(Caution: Some printed circuit boards may not come printed with the lead free mark due to their particular size.) : LEAD FREE MARK .
  • Page 15: Adjustment

    2-1. Writing of Serial Number and Node Unique ID Perform the writing when replacing the FM-96 board or front panel assembly. Required equipment . Personal computer (PC) . IEEE1394.b board . IEEE1394b cable (Commercially available products) . IIDC_CAM**** software: J-7120-410-A (**** represents the version number.) Connection Camera...
  • Page 16: Camera Adjustment

    5. Click the “Flash” tab. 6. Click the [Restart|the|Camera] button to restart. Flash tab [Restart|the|Camera] button 7. Check if the serial number and Node Unique ID on the model nameplate correspond to each number in the IIDC control window. If not, perform the procedure from step 1 again.
  • Page 17: Black And White (B/W) Camera

    (does not exceed 100% (236)) in the WFMwindow. The shutter value (reference value) at which the Green level reaches close to 100% on WFM is as follows. XCD-V60: XCD-SX90: 19 XCD-U100: 19 Exposure tab 7. Click the “Adjust” tab in the IIDC control window.
  • Page 18: Color Camera (Xcd-U100Cr/Sx90Cr/V60Cr)

    2-2-2. Color Camera (XCD-U100CR/SX90CR/V60CR) 1. Shoot the pattern box in the center of the window through the clear chart at the wide end. 2. Start the IIDC_CAM**** software. 3. Click WFM (Waveform Monitor) in the menu. The waveform is displayed. 4.
  • Page 19: Circuit Description

    3-1. BI-217, BI-218, and BI-219 Boards These boards consist of CCD (IC101) and ADC (BI-217: IC105), BI-218: IC102), and BI-219: IC105) that are used for VGA color/black & white (BI-217), SXGA color/black & white (BI-218), and UXGA color/black & white (BI- 219).
  • Page 21: Spare Parts

    Therefore, specified parts should be used in the case of replacement. 2. Standardization of Parts Some repair parts supplied by Sony differ from those used for the unit. These are because of parts common- ality and improvement. 3. Stock of Parts Parts marked with “o”...
  • Page 22: Exploded Views

    Overall Block 4-2. Exploded Views XCD-V60 XCD-SX90 XCD-U100 F900 F800 XCD-V60CR XCD-SX90CR XCD-U100CR XCD-U100/SX90/V60 XCD-U100CR/SX90CR/V60CR...
  • Page 23: Overall Block

    A-1466-663-A s PANEL ASSY (RP), FRONT (FOR XCD-V60) A-1466-746-A s PANEL ASSY (RP), FRONT (FOR XCD-V60CR) A-1466-748-A s PANEL ASSY (RP), FRONT (FOR XCD-SX90) A-1466-768-A s PANEL ASSY (RP), FRONT (FOR XCD-SX90CR) A-1466-769-A s PANEL ASSY (RP), FRONT (FOR XCD-U100)
  • Page 24: Packing Materials & Supplied Accessories

    4-3. Packing Materials & Supplied Accessories ---------------------------------------- PACKING MATERIALS & SUPPLIED ACCESSORIES ---------------------------------------- Ref. No. or Q'ty Part No. SP Description 3-287-508-01 s MANUAL, INSTRUCTION (JAPANESE,ENGLISH) 3-287-508-11 s MANUAL, INSTRUCTION (KOREAN) XCD-U100/SX90/V60 XCD-U100CR/SX90CR/V60CR...
  • Page 25: Block Diagram

    Overall IC201 FPGA SDRAM (4MB x32) SD_D0-D31 IC502 SDRAM (16MB) P_D0-D15 X200 36.000MHz FLASH MEMORY (XCD-U100/U100CR, (2MB) P_D0-D15 XCD-V60/V60CR) 49.302MHz (XCD-SX90/SX90CR) +3.3V_FM +15V_BI IC402 _7.5V/_8.5V_BI +1.3V_FM EEPROM +1.95V_BI +5V/+3.6V_BI (256kBIT) IF-1068 BOARD IC803 THREE-PORT S800 CABLE PHY-IF TRANSCEIVER/ 1394 ARBITER X800 98.301MHz...
  • Page 27: Frame Wiring

    Section 6 Frame Wiring CN101 BI-217 (XCD-V60/V60CR) BI-218 (XCD-SX90/SX90CR) BI-219 (XCD-U100/U100CR) LENS XCD-U100/SX90/V60 XCD-U100CR/SX90CR/V60CR Frame Wiring Frame Wiring CN200 CN400 FLEXIBLE FLAT CABLE CN500 CN700 FM-96 JTAG FLEXIBLE FLAT CABLE CN001 CN002 DC-DC CONVERTER FLEXIBLE FLAT CABLE CN801 CN802 CN800...
  • Page 30 XCD-U100 (SY) XCD-U100CR (SY) XCD-SX90 (SY) XCD-SX90CR (SY) XCD-V60 (SY) Printed in Japan Sony Corporation XCD-V60CR (SY) E 2007. 12 22 9-968-402-01 ©2007...
