Page 1: Installation Instructions
Smart Load SHS51XP Smart Load Installation Instructions (Translation of Original Instructions) Installatie handleiding (Oorspronkelijke installatie handleiding) Verpa Senco BV Pascallaan 88 8218 NJ Lelystad The Netherlands SLM_10-02-2015 EMEA: www.senco-emea.com © 2015 by Senco Brands, Inc. - Page 2 English Nederlands...
-
Page 3: Table Of Contents
TABLE OF CONTENTS 1 Foreword 2 Introduction Users 3 Purpose and function of the Smart Load 4 Safety Symbols used Safety rules 5 Getting Smart Load ready for use 6 Maintenance 7 Malfunctions 8 Scrapping of Smart Load 9 Technical data 10 Parts of Smart Load 10.1 Smart Load assemby 10.2 Smart Load housing site... -
Page 4: Foreword
Keep this documentation in a safe place; it contains information that can be useful or necessary later, for example, for repair work or maintenance. Work activities that must be performed by personnel from Senco are not included in this documentation. Using this documentation. -
Page 5: Safety
4.2 Safety rules • The user has read and is fully familiar with the manual! • Only fasteners from Senco are used. These are tested by Senco for these devices. • The Smart Bridge receives the correct maintenance (see Maintenance chapter). -
Page 6: Getting Smart Load Ready For Use
GETTING SMART LOAD READY FOR USE 5 Getting Smart Load ready for use At the top of the Smart Load there are two attachment options. M10 bolt M12 bolt (other location) Secure the Smart Load to the installation using the M12 bolt in the middle of the attachment unit. The tightening torque is 125 Nm. -
Page 7: Malfunctions
Staples stuck in staple compartment. Pressure in the loading cylinder is ei- ther too high or too low. The pressure can be adjusted by the Senco service engineer. Staple stuck in guide body. Open the nozzle and remove the staples. -
Page 8: Parts Of Smart Load
PARTS OF SMART LOAD 10 Parts of Smart Load 10.1 Smart Load assemby Position Description Order number Tacker with upper- and vertical plate VSP-00319 Site cover VSP-00212 Remote control SHS51XP VSP-00239 Changing magazine SHS51XP VSP-00228 Steel-housing and staple transport VSP-00320 Bolts VSP-00247... -
Page 9: Smart Load Housing Site
10.2 Smart Load housing site Position Description Order number Site housing VSP-00212 Bolts VSP-00247... -
Page 10: Smart Load Tacker With Upper- And Vertical Plate
VSP-00225 Connector 4000102 verticale plate VSP-00226 Bolts VSP-00216 Bolts VSP-00227 Upper plate VSP-00217 Magazine VSP-00228 Bolts VSP-00218 Seal AC0464EU Valve VSP0-0219 Remote control VSP-00239 Valve VSP-00220 SHS51XP 7C2001N Valve VSP-00221 pushin connector VSP-00222 pushin connector VSP-00224 Bolts VSP-00321 Bolts VSP-00213... -
Page 11: Smart Load Remote Control
10.4 Smart Load remote control Position Description Order number Nuts VSP-00241 Remote control housing VSP-00243 pushin connector VSP-00242 Bolts VSP-00244 Cylinder VSP-00240 Bolts VSP-00277 10.5 Smart Load changing magazine Position Description Order number Guide pin VSP-00230 Bolts VSP-00232 Magazine rail VSP-00231 Lath assembly GA0693EU... -
Page 12: Smart Load Steel-Housing And Staple Transport
10.6 Smart Load steel-housing and staple transport... - Page 13 Position Description Order number Position Description Order number Valve VSP-00245 Pushin connector with flow control VSP-00263 Barbed Y-connector VSP-00246 Bracket cylinder VSP-00264 Bolts VSP-00247 Bolt VSP-00265 rail VSP-00248 Nuts VSP-00235 Bolts VSP-00249 Cylinder VSP-00266 Valve VSP-00250 Bolts VSP-00234 Nuts VSP-00251 Nuts VSP-00241 Tube 2 meter...
- Page 15 INHOUDSOPGAVE 1 Voorwoord 2 Inleiding Gebruikers 3 Doel en functie van de Smart Load 4 Veiligheid Gebruikte symbolen Veiligheidsregels 5 In gebruikstelling Smart Load 6 Onderhoud 7 Storingen 8 Afvoeren van Smart Load 9 Technische data 10 Onderdelen Smart Load 10.1 Smart Load assemby 10.2 Smart Load housing site 10.3 Smart Load Tacker with upper- and vertical plate...
-
Page 16: Voorwoord
Bewaar deze documentatie zorgvuldig; er staat informatie in, die ook later van pas komt of nodig is voor bijvoorbeeld reparatie of onderhoud. Werkzaamheden die uitgevoerd dienen te worden door personeel van Senco zijn niet in deze documentatie opgenomen. Het gebruiken van deze documentatie De instructies zijn ingedeeld naar de soort gebruiker van de installatie. -
Page 17: Veiligheid
4.2 Veiligheidsregels • De gebruiker de handleiding heeft gelezen en begrepen! • Uitsluitend bevestigingsmiddelen van Senco worden gebruikt. Deze zijn door Senco getest voor deze apparaten. • De Smart-Load het juiste onderhoud krijgt. (zie hoofdstuk Onderhoud.) • De gebruiker en de medewerkers die aan de Smart Load of omgeving werken, een veiligheidsbril en de juiste gehoorbescherming dragen. -
Page 18: In Gebruikstelling Smart Load
IN GEBRUIKSTELLING SMART LOAD 5 In gebruikstelling Smart Load De bovenzijde van de Smart Load is voorzien van 2 bevestigingsmogelijkheden. M10 bout M12 bout (op andere locatie) Zet de Smartload vast in de opstelling mbv de M12 bout die in het hart van de hechtunit is aangebracht. Het aandraaimoment is 125Nm. -
Page 19: Storingen
Nieten vastgelopen in het magazijn. Druk aanvoercilinder te hoog of te laag. Kan worden ingeregeld door service monteur Senco. Nieten vastgelopen in guide body. Open de neus en verwijder de nieten. Geen of onvoldoende perslucht. Controleer perslucht (7-8 bar) „Materiaal sensor”... -
Page 20: Onderdelen Smart Load
ONDERDELEN SMART LOAD 10 Onderdelen Smart Load 10.1 Smart Load assemby Position Description Order number Tacker with upper- and vertical plate VSP-00319 Site cover VSP-00212 Remote control SHS51XP VSP-00239 Changing magazine SHS51XP VSP-00228 Steel-housing and staple transport VSP-00320 Bolts VSP-00247... -
Page 21: Smart Load Housing Site
10.2 Smart Load housing site Position Description Order number Site housing VSP-00212 Bolts VSP-00247... -
Page 22: Smart Load Tacker With Upper- And Vertical Plate
VSP-00225 Connector 4000102 verticale plate VSP-00226 Bolts VSP-00216 Bolts VSP-00227 Upper plate VSP-00217 Magazine VSP-00228 Bolts VSP-00218 Seal AC0464EU Valve VSP0-0219 Remote control VSP-00239 Valve VSP-00220 SHS51XP 7C2001N Valve VSP-00221 pushin connector VSP-00222 pushin connector VSP-00224 Bolts VSP-00321 Bolts VSP-00213... -
Page 23: Smart Load Remote Control
10.4 Smart Load remote control Position Description Order number Nuts VSP-00241 Remote control housing VSP-00243 pushin connector VSP-00242 Bolts VSP-00244 Cylinder VSP-00240 Bolts VSP-00277 10.5 Smart Load changing magazine Position Description Order number Guide pin VSP-00230 Bolts VSP-00232 Magazine rail VSP-00231 Lath assembly GA0693EU... -
Page 24: Smart Load Steel-Housing And Staple Transport
10.6 Smart Load steel-housing and staple transport... - Page 25 Position Description Order number Position Description Order number Valve VSP-00245 Pushin connector with flow control VSP-00263 Barbed Y-connector VSP-00246 Bracket cylinder VSP-00264 Bolts VSP-00247 Bolt VSP-00265 rail VSP-00248 Nuts VSP-00235 Bolts VSP-00249 Cylinder VSP-00266 Valve VSP-00250 Bolts VSP-00234 Nuts VSP-00251 Nuts VSP-00241 Tube 2 meter...
-
Page 26: Guarantee
For every replacement product or part, the remaining original warranty period of the replaced product or part is Senco will become the owner of the products or parts that have been replaced by Senco or its distributors as a result of applicable. -
Page 27: Ec Declaration Of Conformity
Machinerichtlijn 2006/42/EC. Declare under our sole responsibility that Verklaren onder onze eigen verantwoordelijkheid dat: Equipment: Apparatuur: Model type: Smart Load SHS51XP Model type: Smart Load SHS51XP EC Directives: 2006/42/EC EC Directives: 2006/42/EC Authorized Representative: (authorized to Geautoriseerde vertegenwoordiger: (gemachtigd...
