Network Video Recorder User Manual
Network video recorder
F-series user manual
I

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the F series and is the answer not in the manual?

Questions and answers

Related Manuals for XtendLan F series

Summary of Contents for XtendLan F series

  • Page 1 Network Video Recorder User Manual Network video recorder F-series user manual...

  • Page 2: Table Of Contents

    Network Video Recorder User Manual Contents Chapter 1 Installation ........................1 1.1 NVR Installation ......................... 1 1.2 Hard Disk Installation ......................1 Chapter 2 Getting Started ....................... 3 2.1 Start up and Shutdown ......................3 2.1.1 Start up ........................3 2.1.2 Shutdown .........................
  • Page 3 Network Video Recorder User Manual 7.2.2 Recording Parameters .................... 23 7.2.3 Snapshot Parameters ....................24 7.2.4 Motion ........................25 7.2.5 Video Lost ......................26 7.2.6 Video Tampering ....................27 Note：Onvif protocol can’t support video tampering ............. 28 7.2.7 Privacy Mask ......................28 7.3 Planning ..........................
  • Page 4 Network Video Recorder User Manual 10.3.3 Email Setting ......................45 10.3.4 Advanced Setting ....................46 10.3.5 Management Platform ..................47 10.4 Alarm Management ......................48 10.4.1 Alarm Input ......................48 10.4.2 Alarm Output ......................49 10.4.3 Exception ......................50 10.4.4 Linkage Setting ....................50 10.5 User Management ......................

  • Page 5: Chapter 1 Installation

    Network Video Recorder User Manual Chapter 1 Installation 1.1 NVR Installation During installation of the NVR： Ensure the device is installed in a well-ventilated, dust-free environment. The device is designed for indoor use only. Keep all liquids away from the device. Ensure environmental conditions meet factory specifications....
  • Page 6 Network Video Recorder User Manual (4) Close the cover and fasten it with the screws. NVR with 1 or 2 HDD ： Steps (1) Remove the cover from the NVR by unfastening the screws on the side and rear panel. (2) Fasten the HDD with the screws on the bottom.

  • Page 7: Chapter 2 Getting Started

    Network Video Recorder User Manual Chapter 2 Getting Started 2.1 Start up and Shutdown 2.1.1 Start up Plug in the power cord, press the power switch, the power indicator light should turn bright. The device will begin to start. After the device starts up, the video output defaults to multiple screen output mode.

  • Page 8: Using Guide

    Network Video Recorder User Manual 2.3 Using Guide The Guide starts once login, as shown in figure 2.3. Figure 2.3 Language Setting Operating the Guide The Guide can walk you through some basic settings of the NVR. If you don’t want to 1）...

  • Page 9: Menu Operation

    Network Video Recorder User Manual Figure 2.5 Network Setting After the network setting, click Next button to enter the QR Code interface, as shown in 4） figure 2.6. Figure 2.6 Qr Code Click Finish to complete the Guide setup. 5） 2.4 Menu operation After the user login successfully, according to the interface of the upper toolbar to perform associated settings,as shown in figure 2.7.
  • Page 10 Network Video Recorder User Manual Figure 2.8 Begin Setup Logout: Click Logout button, can exit the current user. 1） Guide: Click Guide button, it will pop-up boot wizard setting interface, simply configure 2） language, display resolution, basic network parameters, and mobile phone app to access the QR Code display.

  • Page 11: Chapter 3 Preview

    Network Video Recorder User Manual Chapter 3 Preview 3.1 Introduction of Preview Preview shows you the video image getting from each camera in real time. The NVR will automatically enter live view mode when powered on, as shown in figure 3.1. Figure 3.1 Preview Interface Channel Preview Icons In the Preview mode, there are hide icons on the screen of each channel, which shows when...
  • Page 12 Network Video Recorder User Manual When you click , it will pop-up the alarm information, as shown in figure 3.3. Figure 3.3 Alarm Information When you click , it will hide the real-time alarm information. (2) Other functions Table 3.2 Other Function Description Icons functions Icons...

  • Page 13: Using The Mouse In Preview

    Network Video Recorder User Manual 3.3 Using the Mouse in Preview Figure 3.4 Right Click Menu Table 3.3 Right Click Function Description Name Description Full Screen Quick enter full screen mode. Open/Close cruise. Cruise On/Off Manual Recording On/Off Open/Close manual record. Channel Connecting Quick enter IP Camera Management interface.

  • Page 14: Right Tool Bar

    Network Video Recorder User Manual 3.4 Right Tool Bar （1） Images play mode There are three kinds of play mode，as shown in figure 3.5, preview picture can show according to "Device List", "Structure" and "Tour" preview as required，the default play mode is "device list", note that, “Structure”and "Tour"can be used only when they are configured in advance, see below the detailed operation, channel configuration section.

  • Page 15: Channel Exchange

    Network Video Recorder User Manual Figure 3.7 Video Parameter （4） PTZ/Preset/Cruise/Pattern Please confirm whether the related parameters setting is correct before control the PTZ.After setting up parameters, select the channel to be controlled in the preview interface, then control the direction of the lens, focal length, focus, aperture amplification and narrow in PTZ operation interface，and adjust the speed of PTZ, as shown in figure 3.8.

  • Page 16: Chapter 4 Playback

    Network Video Recorder User Manual Chapter 4 Playback 4.1 Instant Playback Purpose: Playback the recorded video files of a specific channel in the live view mode. Steps: Choose a channel in live view mode and click the button in the bottom of the channel,as shown in figure 4.1.
  • Page 17 Network Video Recorder User Manual Playback by time Purpose: Playback video files recorded in specified time duration. Multi-channel simultaneous playback is supported. Steps: Enter playback interface. 1） Check the check-box of channel(s) in the channel list and then double-click to select a 2）...

  • Page 18: Playback By Event Search

    Network Video Recorder User Manual 4.2.2 Playback by Event Search Purpose: Playback record files on one or several channels searched out by event type (e.g. alarm detection, motion ). Steps: Enter the Playback interface. 1） Select the Retrieving type: There are many types you can select,such as Count Alarm, 2）...

  • Page 19: Playback External File

    Network Video Recorder User Manual Note: Click the check-box of the picture listed, then click Backup button, can enter the Snapshot back-up interface, as shown in figure 4.6. Figure 4.6 Snapshot Backup 4.2.4 Playback External File Purpose: Perform the following steps to look up and playback files in the external devices,as shown in figure 4.7.

  • Page 20: Chapter 5 Ptz Controls

    Network Video Recorder User Manual Chapter 5 PTZ Controls 5.1 Configuring PTZ Settings Follow the procedure to set the parameters for PTZ. The configuring of the PTZ parameters should be done before you control the PTZ camera. Steps: Enter the PTZ Setting interface,as shown in figure 5.1; 1）...

  • Page 21: Preset Setting

    Network Video Recorder User Manual Figure 5.2 PTZ Setting Interface 5.2.1 Preset Setting Follow the steps to set the Preset location which you want the PTZ camera to point to when an event takes place. Steps: 1) Use the directional button to wheel the camera to the location where you want to set preset, and the zoom and focus operations can be recorded in the preset as well.

  • Page 22: Pattern Setting

    Network Video Recorder User Manual Configure key point parameters, such as the key point No., duration of staying for one key 3） point and speed of cruise. The key point is corresponding to the preset. The Key Point No. determines the order at which the PTZ will follow while cycling through the cruise. The Cruise time refers to the time span to stay at the corresponding key point.

  • Page 23: Chapter 6 File Backup

    Network Video Recorder User Manual Chapter 6 File Backup Purpose: The record files can be backup to various devices, such as USB devices (USB flash drives, USB HDDs). Click icon to enter the local backup interface,as shown in figure 6.1. Figure 6.1 Backup Interface 6.1 Picture Backup Figure 6.2 Picture Backup Interface...

  • Page 24: Video File Backup

    Network Video Recorder User Manual After finish, click Confirm. 7） 6.2 Video File Backup Steps: Figure 6.3 Video Backup Interface 1）Select the Channel to backup. 2）Set the time of file to backup. 3）Select the File Type:Video. Select the File Format. 4）...

  • Page 25: Chapter 7 Channel Setting

    Network Video Recorder User Manual Chapter 7 Channel Setting 7.1 Adding IP Cameras Purpose: Before you can get live video or record the video files, you should add the network cameras to the connection list of the device. Before you start: Ensure the network connection is valid and correct, and the IP camera to add has already been activated.

  • Page 26: Channel Parameter

    Network Video Recorder User Manual 7.2 Channel Parameter 7.2.1 Display Setting Purpose: You can configure the OSD(On-screen Display) settings for the camera, including camera name, date /time, etc. Steps: Enter the OSD Configuration interface. 1） Channel Setting ->Channel Parameter ->Display Setting Select the channel of camera to configure OSD settings.

  • Page 27: Recording Parameters

    Network Video Recorder User Manual Figure 7.4 Image Setting Interface  Camera Lens Parameters Setting: Set the channel Camera Lens Parameters, as shown in figure 7.5. Figure 7.5 Camera Lens Parameters Setting Interface  Click Save button to save the settings. 7.2.2 Recording Parameters Purpose: Sometimes you need to edit the channel Camera recording parameters for better image.

  • Page 28: Snapshot Parameters

    Network Video Recorder User Manual Figure 7.6 Recording Parameter Set the video parameter： 2） （1） Channel:Select the channel of camera to configure the encoding type. （2） Encoding Type: Select Main Stream or Sub Stream. （3） Resolution: Select the video resolution. （4）...

  • Page 29: Motion

    Network Video Recorder User Manual 7.2.4 Motion Motion detection interface is shown in figure 7.8, can set the related parameters of motion detection. Figure 7.8 Motion Detect Mode：The default is "Camera"，when NVR support smart（smart detection） ， （1） can switch mode to "NVR"; （2）...

  • Page 30: Video Lost

    Network Video Recorder User Manual Figure 7.10 Planning （5） Linkage Operation：Choose the mode that needs linkage，as shown in figure 7.11. Figure 7.11 Linkage （6） Full screen：One click to set the whole screen area for motion detection area; （7） Clear all：One click to clear the motion detection area on the screen set before. 7.2.5 Video Lost Video lost configuration interface, as shown in figure 7.12.

  • Page 31: Video Tampering

    Network Video Recorder User Manual （1） Channel：Choose the channel number; （2） Planning：Set the arming schedule of video loss, as shown in figure 7.13. Figure7.13 Planning （3） Linkage：Set the linkage mode, as shown in figure 7.14. Figure7.14 Linkage 7.2.6 Video Tampering Purpose: Trigger alarm when the lens is covered and take alarm response action(s).

  • Page 32: Note：onvif Protocol Can't Support Video Tampering

    Network Video Recorder User Manual Set the video mask alarm handling action of the channel. 2）  Check the check-box of Enable Video Tampering.  Select the sensitivity.  Use the mouse to draw an area you want to detect video mask. 3）Setup the planning of the channel,as shown in figure 7.16.

  • Page 33: Planning

    Network Video Recorder User Manual Figure 7.18 Video Mask Select the camera to set privacy mask. 2） Click the check-box of Enable Privacy Mask to enable this feature. 3） Use the mouse to draw a zone on the window, up to 4 privacy mask zones can be 4）...

  • Page 34: Planning

    Network Video Recorder User Manual  Select the Channel you want to configure.  Select the Record Mode.  Click Setting button to set the record time, as shown in figure 7.20. Figure 7.20 Arming Schedule  Pre-Record: The time you set to record before the scheduled time or event. ...

  • Page 35: Manual Operation

    Network Video Recorder User Manual Figure 7.22 Planning Note:Use the Copy to to do the same setting to the channel needed. 7.4 Manual Operation 7.4.1 Manual Recording The Manual Recording Interface,as shown in Figure 7.23. Figure 7.23 Manual Recording 7.4.2 Snapshot The snapshot interface,as shown in Figure 7.24.

  • Page 36: Manual Alarm

    Network Video Recorder User Manual Figure 7.24 Snapshot 7.4.3 Manual Alarm The manual alarm interface,as shown in Figure 7.25. Figure 7.25 Manual Alarm 7.5 Channel Grouping 7.5.1 Structure The role of setting organizational structure is to group the channel and preview, can group according to a standard, as shown in figure 7.26, that is group according to the region, the same channel can be divided into different groups according to the needs.

  • Page 37: Cruise Preview

    Network Video Recorder User Manual Figure 7.26 Organizational Structure Icon function is shown in table 7.1: Icon function Table 7.1 Icon Functional description Icon Functional description Create group Delete group Modify the group name Add group Remove the channel Move up Move down 7.5.2 Cruise Preview Cruise preview setting is similar to above organizational structure settings, also be grouped...

  • Page 38: Chapter 8 Disk Management

    Network Video Recorder User Manual Chapter 8 Disk Management Click icon, entering into the disk backup interface, there are three modules in this interface, the following instructions, respectively. 8.1 Storage Management The information on the page explains in detail the situation of the current NVR receive the hard disk, as shown in figure 8.1, the device connects 1 hard disk, and is in normal state video recording.

  • Page 39: Advanced Configuration

    Network Video Recorder User Manual Note that, when the channel of device video is more than 32CH and connect multiple hard disk, to ensure the efficiency and performance of hard disk，default to video in 2 hard disk, video in one hard disk first 32CH of the video channel, the remaining channel video in another hard disk video.

  • Page 40: Disk Location Map

    Network Video Recorder User Manual 8.4 Disk Location Map This page shows the product main board picture, as shown in figure 8.4, it identified the corresponding physical serial number of sata port, if certain hard dis need to replace, just compare the image to find corresponding sata hard drive.

  • Page 41: Chapter 9 System Maintenance

    Network Video Recorder User Manual Chapter 9 System Maintenance icon ， can enter the system maintenance interface ， this part includes six parts Click altogether，note the following instructions: 9.1 System Information Can view the device information，stream info and online users. 9.1.1 Device Information Device information interface，as shown in figure 9.1, can view the versions of hardware and software.

  • Page 42: Online Users

    Network Video Recorder User Manual 9.1.3 Online Users View the information of current logged in user，as shown in figure 9.3, including: user name, login time, login IP, login method, and so on. Figure 9.3 Online Users 9.2 Log Information Click icon, the interface is shown in figure 9.4, can view the system log.

  • Page 43: Configuration Management

    Network Video Recorder User Manual 9.3 Configuration Management As shown in figure 9.5, can export the configuration, import configuration and restore the default operation. Figure 9.5 Configuration Management 9.4 System Upgrade As shown in figure 9.6, it can be divided into “NVR upgrade” and “IPC upgrade”. Figure 9.6 System Upgrade NVR upgrade: Click “browse”, select to upgrade the file ，and then, the system will （1）...

  • Page 44: Auto Maintenance

    Network Video Recorder User Manual 9.5 Auto Maintenance Can set the maintenance mode, as shown in figure 9.7.You can select the maintenance mode in this interface.(The default mode is disable) Figure 9.7 Auto Maintenance 9.6 Network Monitoring 9.6.1 Network Flow As shown in figure 9.8, can monitor the network traffic of the current device.

  • Page 45: Network Test

    Network Video Recorder User Manual 9.6.2 Network Test The network test interface, as shown in figure 9.9. Figure 9.9 Network Test （1） NIC Select:Select the network card，the default is network card 1; （2） Dest Address：Input the network address that needs to be tested; （3）...

  • Page 46: Chapter 10 System Configuration

    Network Video Recorder User Manual Chapter 10 System Configuration Click icon, enter the system configuration interface, the interface has seven modules, the following description respectively. 10.1 Time Setting 10.1.1 Device Time Time settings interface, as shown in figure 10.1, can set the device time, time zone selection. Figure 10.1 Time Setting （1）...

  • Page 47: Channel Zero Setting

    Network Video Recorder User Manual Figure 10.2 IPC Time （ 1 ） ） Manual Timing:Click Manual Timing button,adjust the IPC time as same as device time. （ 2 ） Auto Timing：Enable the auto timing, the IPC will be timing when it is different to the device time.

  • Page 48: Channel Setting

    Network Video Recorder User Manual 10.2.2 Channel Setting The Channel setting Interface, is shown in figure 10.4. Figure 10.4 Channel Configuration 10.3 Network Parameter The module has 5 pages, the following description respectively. 10.3.1 Basic Setting The network Setting interface is shown in figure 10.5, then can set the IP parameters. Figure10.5 Basic Setting （1）...

  • Page 49: Ddns Setting

    Network Video Recorder User Manual （5） Mask：Set the mask; （6） Gateway：Set the gateway address. 10.3.2 DDNS Setting The default is "disable DNS" status，Each set column can not be set，it needs to switch to the "enable DNS" status，as shown in figure 10.6, note that，this function need to ensure that device can normal access network when using.

  • Page 50: Advanced Setting

    Network Video Recorder User Manual Figure 10.7 Email Setting （ 1 ） Fill in the multiple recipient mailbox, the sender email address will send E-mail to multiple recipients mailbox at the same time ; （ 2 ） Check function, the mail the recipient received in his mailbox is with attachments, the attachment content is linkage capture file of the corresponding channel （...

  • Page 51: Management Platform

    Network Video Recorder User Manual 1935、80、8081 and 8082, port numbers can be modified（modifying the internal port need to restart the device to take effect ）, UPnP status is defaulted to ineffective state, it will obtain the external IP address after take effect. 10.3.5 Management Platform This page is the enable interface of the platform agreement, as shown in figure 10.9, defaulted to enable Fseye and Web Server protocol（Support the device remotely login）, other...

  • Page 52: Alarm Management

    Network Video Recorder User Manual Figure 10.11 QR Code 10.4 Alarm Management There are 4 pages of this module , the following instructions respectively. 10.4.1 Alarm Input The Alarm input interface, as shown in figure 10.12. Figure 10.12 Alarm Input （1）...

  • Page 53: Alarm Output

    Network Video Recorder User Manual Figure10.13 Arming schedule （5） Linkage Way：choose the type of alarm linkage,as shown in figure 10.14; Figure 10.14 Linkage mode （6） Copy to：copy the above configuration to other channels; 10.4.2 Alarm Output The Alarm Output interface, as shown in figure 10.15. Figure 10.15 Alarm Output...

  • Page 54: Exception

    Network Video Recorder User Manual （1） Alarm Output：Choose the channel number that needs to set; （2） Alarm Output Name：Set the alarm output name; （2） Alarm output delay：choose the alarm output delay time or custom settings; ） Planning ： choose the time interval that needs arming schedule, as shown in （3）...
  • Page 55 Network Video Recorder User Manual Figure10.18 Linkage Setting Alarm Mode：set the alarm type, including “alarm input”, “motion detection”, “video （1） mask”; （2） Alarm CH：choose the alarm channel; （3） Search：click icon，then it can show alarm information; （4） Add：click to open the linkage configuration, as shown in figure 10.19; Figure10.19 Alarm Linkage （5）...

  • Page 56: User Management

    Network Video Recorder User Manual Figure 10.20 Modify （6） Delete information：select a set of alarm information，click icon，delete the information. 10.5 User Management User management interface is shown in figure 10.21, you can modify the user information and users permission. Figure 10.21 User Management （1）...
  • Page 57 Network Video Recorder User Manual Figure 10.22 Modify users Add User ： add a new user, as shown in figure 10.23, fill in the user name and （2） password; Figure 10.23 Add User （3） Delete users：can delete the selected users（except admin and default users）; （4）...

  • Page 58: Ptz Setting

    Network Video Recorder User Manual 10.6 PTZ Setting This page is PTZ parameter setting interface, as shown in figure 10.25, only when the parameter is set correctly, can the PTZ run normally. Figure10.25 PTZ Setting （1） RS485 device：show the accessed 485 devices; （2）...
  • Page 59 Network Video Recorder User Manual （1） Device ID：Namely device number，default to 0; （2） Device name：Can edit the device name，default to blank; （3） Product Serial No：Show the product serial number; Total Channels ： Show the max preview channel number, different model support （4）...

  • Page 60: Chapter 11 Smart Analysis

    Network Video Recorder User Manual Chapter 11 Smart Analysis Smart analysis is the vital function of 2.0NVR, and this chapter will give clear and specific instructions in terms of intelligent performance, process and parameter configuration. 11.1 Brief Introduction The current Smart performance of NVR2.0 includes: （1）...

  • Page 61: Behavior Analysis

    Network Video Recorder User Manual 11.3.2 Behavior Analysis Behavior analysis includes the following functions: target counting, object detection, area detection, virtual warning line. The target triggering rule is based on the center of the target's lower edge (except height limit detection), which is generally the position of the human foot.
  • Page 62 Network Video Recorder User Manual （1） Channel: Select the channel; （2） Detect Mode: Divided into front-end and local, the two models to the actual capacity of the product subject, selecting the front-end mode requires front-end access to IPC support, selecting the local model requires equipment support; （3）...
  • Page 63 Network Video Recorder User Manual Figure 11.5 Alarming  Goods detection The purpose of this page is to configure the relevant parameters, so that more than the proportion of objects in the set detection area lost / left over time detection time that goods detection alarm.
  • Page 64 Network Video Recorder User Manual as "items"; （8） Detect Tme: detected items lost / left more than this time to trigger the alarm; In accordance with the above settings, in the channel screen, the proportion of more than 150 items in the detection area disappeared more than 30s, triggered object detection alarm, alarm before and after the real-time preview screen, respectively, as shown in figure 11.7 and figure 11.8.
  • Page 65 Network Video Recorder User Manual Figure 11.9 Area Detection （1） Channel: Select the channel; （2） Detect Mode: divided into front-end and local, the two models to the actual capacity of the product subject, select the front-end mode requires front-end access to IPC support, select the local mode requires the device support;...
  • Page 66 Network Video Recorder User Manual  Line Crossing The purpose of this page is to configure the relevant parameters, so that more than the proportion of moving objects, across the set of test lines, the virtual alarm immediately alarm line. The following describes the main parameters of the page setting method.

  • Page 67: Scene Change

    Network Video Recorder User Manual 11.3.3 Scene Change Figure 11.13 shows the situation where the front-end IPC detects a change in the screen caused by human or environmental factors, such as the camera being deflected, the camera being blocked, and the camera's angle or position being changed. Figure 11.13 Scene Change （1）...

  • Page 68: Alarm Linkage Setting

    Network Video Recorder User Manual 11.4.2 Alarm Linkage Setting Click the linkage setting button, and select the alarm linkage in the pop-up linkage configuration interface, as shown in Figure 11.15. Figure 11.15 Alarming Linkage Setting （1） Linkage: select mail linkage, sound alarm, monitor alarm, upload center in four ways; The following four ways: a) Mail linkage: this method needs to set a valid mail box in the Email parameter of the device, and fill in a valid mail sending and receiving server and port number.
  • Page 69 Network Video Recorder User Manual...
