- Page 1 MHCCW (115) Rev. 1.2...
- Page 2 Read the entire contents of this manual enclosure assembly. The enclosure assembly before beginning installation. Multiaqua can be ordered separately or field fabricated assumes no responsibility for equipment by the installing contractor. See Figure 2...
- Page 3 INSTALLATION & OPERATING MANUAL MHCCW Fan Coils 1- 3 Tons FAN COIL DIMENSIONS Fan Coil Model Number MHCCW04-XX 37.72 34.56 31.41 10.23 5.51 21.65 MHCCW06-XX 37.72 34.56 31.41 10.23 5.51 21.65 MHCCW08-XX 37.72 34.56 31.41 10.23 5.51 21.65 MHCCW10-XX 43.70 40.55 37.40 10.23...
- Page 4 INSTALLATION & OPERATING MANUAL MHCCW Fan Coils 1- 3 Tons -------- CAUTION ------- Care must be taken when handling sheet metal. Sheet metal parts have sharp edges and could cause injury. INSTRUCTIONS FOR CONVERTING COIL HAND CONNECTION (Left or Right) Figure 4 &...
- Page 5 INSTALLATION & OPERATING MANUAL MHCCW Fan Coils 1- 3 Tons INSTRUCTIONS FOR INSTALLING FAN COIL UNIT INTO ENCLOSURE ASSEMBLY 1. Remove the ten screws that attach the electrical assembly to the fan coil unit. Do not separate the electrical assembly from the Figure 7 blower assembly.
- Page 6 INSTALLATION & OPERATING MANUAL MHCCW Fan Coils 1- 3 Tons 4. Align the fan coil mounting bolts up with the four fan coil mounting notches provided in the coil assembly top. Secure the coil assembly to the enclosure with two mounting bolts per side. Ensure that the coil assembly is level in both directions to allow proper drainage and operation.
-
Page 7: Water Coil Connections
INSTALLATION & OPERATING MANUAL MHCCW Fan Coils 1- 3 Tons ELECTRICAL & CONDENSATE DRAIN 8. There are four termination points for the electrical wiring. There are two on each side of the electrical box. See Wiring Diagrams for electrical drawings. Wiring must be installed according to prevailing codes and regulations. - Page 8 INSTALLATION & OPERATING MANUAL MHCCW Fan Coils 1- 3 Tons RETURN AND SUPPLY AIR CONNECTIONS 10. When mounting the service access panel, louvered or non-louvered, the installing contractor must provide a frame in order to connect the enclosure assembly to the service access panel. This is required to obtain an airtight seal for the return air.
- Page 9 INSTALLATION & OPERATING MANUAL MHCCW Fan Coils 1- 3 Tons SERVICE ACCESS PANEL DIMENSIONS Louvered & Non-Louvered Panel Model Number Coil Size (in) (in) (in) MAP468L(NL) 43.25 27.5 MAP468L(NL) 43.25 27.5 MAP468L(NL) 43.25 27.5 MAP10L(NL) 49.25 27.5 MAP12L(NL) 55.25 27.5 Figure 17 (type) RECOMMENDED FILTER...
- Page 10 INSTALLATION & OPERATING MANUAL MHCCW Fan Coils 1- 3 Tons 12. The fan coil enclosure assembly has a supply air duct flange to allow the attachment of ductwork. Ensure when attaching ductwork to the flange, that the screws are at least one and half inches away from the front of the enclosure.
-
Page 11: Maintenance
INSTALLATION & OPERATING MANUAL MHCCW Fan Coils 1- 3 Tons and/or replacements in the event the MAINTENANCE unit fails to operate or is being serviced. If fuses are used, ensure 1. Air Filter(s): that the replacement fuses are of the Filters are an essential part of same size and type as the ones you the quality of air that is...
