  • Page 1 MedizinTechnik English ATMOS HL 21 LED ® 507.4506.B 507.4505.B 507.4760.B 506.7551.B 530.4020.B 507.4507.B 507.4500.B 2015-05 Index: 09 Please store this document near the device for later use!

  • Page 2: Table Of Contents

    4.1 Individual components of the headlight ..........7 4.2 Adjustment to head measurement ..........8 - 9 4.3 Functionality of rechargeable LED battery ........10 5.0 Operation ................11 - 12 5.1 Variants of the headlight ATMOS HL 21 LED ....... 11 ® 5.2 Switching on ...................12 5.3 Focusing the headlight ATMOS...

  • Page 3: Introduction

     The ATMOS HL 21 LED bears the CE identifi cation symbol CE in accordance with ® the EU Medical Devices Directive (MDD) - Directive 93/42/EEC and meets the basic requirements of Annex I to this Directive.

  • Page 4: Explanation Of Symbols

    Introduction Explanation of symbols The following symbols are on the ATMOS HL 21 LED, on the rechargeable ® LED battery or on the charging power pack. Please remember their meaning Symbol "Pay attention to operating instructions". This symbol shall draw your attention to the safety information contained in the operating instructions.

  • Page 5: Notes On Safety

     Prior to each application, check the device's functions and its proper condition. Damaged cables must be replaced immediately!  During each application, pay attention to proper fi t of the headlight ATMOS HL 21 LED. ®...

  • Page 6: Intended Use

    Specifi cation of the main function: Due to the long-life light source with power-white light LED (service life approx. 50.000h) in combination with a high-end-battery system the ATMOS HL 21 LED enables a homogenous illumination of the ® examination resp. operating fi eld. Application organ:...

  • Page 7: Setting Up And Starting Up

     Adjusting instruments on the headlight rack.   Prior to dispatch, this ATMOS device was subjected to an extensive functional test and has been carefully packed. Nevertheless, please compare the contents of the shipment on completeness immediately upon receipt (see following extent of supply).

  • Page 8: Adjustment To Head Measurement

    4.0 Setting up and starting up    Fig. 2. Headlight ATMOS HL 21 LED ® Headlight rack  Turning knob for adjusting the measurement  Strap for adjusting the level  Prior to fi rst operation, pay attention to the safety information in chapter 2.0.

  • Page 9: Adjustment To Head Measurement

     Use the enclosed cable clip (, fi g. 3) to fi x the long cable to your clothes.  Join the other end of the connecting cable with the socket on the rechargeable LED battery (fi g. 4) or with the current source in your ATMOS ENT examination unit.

  • Page 10: Functionality Of Rechargeable Led Battery

    4.3.2 Charging the LED battery  Use the primary adapter fi tting for your power supply (Euro/US/ UK/Aus). See information enclosed to the charging power pack.  To charge the LED battery, separate it from the headlight ATMOS HL 21 LED. ®...

  • Page 11: Operation

    Different variants of the headlight ATMOS HL 21 LED ®  Fig. 7: Headlight ATMOS HL 21 LED with long cable, supply from the LED battery in the ® coat pocket or from a suitable ATMOS current source in an ENT examination unit.

  • Page 12: Switching On

    5.0 Operation   Fig. 9. Focusing Headlight rack  Focusing ring  Switching on  Adjust the lateral switch on the LED battery to the desired position:  ECO mode: operation for about 4 hours.  POWER mode: operation for about 2 hours. Focusing the headlight ...

  • Page 13: Notes On Cleaning And Care

    • Disinfectants containing chloramines, phenol derivatives or anionic tensides since these may cause stress cracks in the plastics used. When the headlight ATMOS When the headlight ATMOS HL 21 LED is applied by several users, regular ® cleaning and disinfection is necessary. cleaning and disinfection is necessary.

  • Page 14: Maintenance And Servicing

    • Assembly, resetting, alterations, extensions and repairs are not carried out by people authorised by ATMOS.  No warranty rights shall exist in the event of damage or failure caused by the use of non-ATMOS accessories or non-ATMOS consumables. ●...

  • Page 15: Accessories, Spare Parts, Consumables

    Accessories, spare parts, consumables Accessories Description Connecting cable for LED battery, 40 cm....507.4542.0 Connecting cable for LED battery, 140 cm....507.4541.0 Connecting cable for LED battery, 200 cm....507.4545.0 Clip - for fixing the cable to clothes ......507.4543.0 Spare parts Description Light body complete..........

  • Page 16: Technical Specifi Cations

    10.0 Technical Data Charging power pack 100...240 V~ 50/60 Hz; exchangeable primary adapters (Euro/ UK/US/Aus); secondary 12 V DC; 0.8 A via non-medical 1.8 m cable with DC plug 5.5 x 2.5 mm; protection class II; only for dry rooms Rechargeable battery Charging with 12 V DC;...

  • Page 17: Disposal

    11.0 Disposal  The headlight ATMOS HL 21 LED does not contain any hazardous goods. ®  The LED battery (lithium-ionic) must be disposed of correctly.  Prior to disposal, device and accessories must be de-contaminated.  Make sure that materials are separated carefully.

  • Page 18: Notes On Electromagnetic Compatibility (Emc)

    Guidelines and Manufacturer's Declaration - Emissions The headlight ATMOS HL 21 LED is intended for use in the electromagnetic environment specifi ed ® below. The customer or user of the ATMOS HL 21 LED should ensure that it is used in such an envi- ®...
  • Page 19 Guidelines and Manufacturer's Declaration - Immunity The headlight ATMOS HL 21 LED is intended for use in the electromagnetic environment specifi ed ® below. The customer or user of the ATMOS HL 21 LED should ensure that it is used in such an ®...
  • Page 20 12.0 Notes on EMC Guidelines and Manufacturer's Declaration - Immunity The headlight ATMOS HL 21 LED is intended for use in the electromagnetic environment specifi ed ® below. The customer or user of the ATMOS HL 21 LED should ensure that it is used in such an ®...
  • Page 21 12.0 Notes on EMC Guidelines and Manufacturer's Declaration - Immunity The headlight ATMOS HL 21 LED is intended for use in the electromagnetic environment specifi ed below. ® The customer or user of the ATMOS HL 21 LED should ensure that it is used in such an environment.
  • Page 22 TV stations cannot be predestined exactly. To determine the electromagnetic environment in regard to stationary transmitters, a study of the location is to be considered. If the measured fi eld strength at the location where the ATMOS HL 21 ®...
  • Page 23 ATMOS HL 21 LED ® The headlight ATMOS HL 21 LED is intended for use in electromagnetic environment in which ® ratiated disturbances are controlled. The customer or user of the ATMOS HL 21 LED can help ®...
