Page 1: User Manual
USER MANUAL Online UPS Challenger Series Stand Alone (SA) Rack Mount (RM) Low Voltage & High Voltage Models: SA1P1LVW/SA1P1HVW SA1P2LVW/SA1P2HVW SA1P3LVW/SA1P3HVW Capacity: 1 KVA - 2 KVA - 3 KVA REVISION DESCRIPTION Date Rev. 1.0 Formal Release 2015/11/25... - Page 2 Danger-For your safety Indicate an imminently hazardous situation that, if not avoided, will result in death or serious injury. Warning-Caution Indicate that any unsafe practices must be avoided which could prejudice health and safety and cause financial damage. Important Indicate any important technical information that must not be neglected.
-
Page 3: Table Of Contents
Contents 1. IMPORTANT SAFETY WARNING ..............1 1.1. Transportation ..................1 1.2. Preparation ....................1 1.3. Installation ....................1 1.4. Operation ....................2 1.5. Maintenance, service and faults ............2 2. INSTALLATION AND SETUP ................4 2.1. Rear Panel View..................4 2.2. -
Page 4: Important Safety Warning
1. Important Safety Warning Please comply with all warnings and operating instructions in this manual strictly. Save this manual properly and read carefully the following instructions before installing the unit. Do not operate this unit before reading through all safety information and operating instructions carefully. -
Page 5: Operation
outlet). Please use only VDE-tested, CE-marked power cables to connect the loads to the UPS system. When installing the equipment, it should ensure that the sum of the leakage current of the UPS and the connected devices does not exceed 3.5mA. 1.4. - Page 6 Please take the precautionary measures specified below and any other measures necessary when working with batteries: －remove wristwatches, rings and other metal objects －use only tools with insulated grips and handles. o When changing batteries, install the same number and same type of batteries. o Do not attempt to dispose of batteries by burning them.
-
Page 7: Installation And Setup
2. Installation and Setup Before installation, please inspect the unit. Be sure that nothing inside the package is damaged. Please keep the original package in a safe place for future use. 2.1. Rear Panel View. - Page 9 AC input Input circuit breaker USB communication port RS-232 communication port SNMP intelligent slot (option) External battery connection (only available for L model) Output receptacles Output terminal Output circuit breaker...
-
Page 10: Setup The Ups
2.2. Install the UPS Rack-mount Installation This UPS can be mounted in the 19” rack chassis. Please follow below steps to position this UPS. Tower Installation 2.3. Setup the UPS Step 1: Connect battery wires If using rack UPS, the UPS is shipped out from factory without connecting battery wires for safety consideration. - Page 11 Step 2: UPS input connection Plug the UPS into a two-pole, three-wire, grounded receptacle only. Avoid using extension cords. For 208/220/230/240VAC models: The power cord is supplied in the UPS package. For 110/115/120/127VAC models: The power cord is attached to the UPS. The input plug is a NEMA 5-15P for 1K model and NEMA 5-20P for 2K model.
- Page 12 installing either SNMP or AS400 card in the UPS, it will provide advanced communication and monitoring options. Step 5: Turn on the UPS Press the ON/Mute button on the front panel for two seconds to power on the UPS. NOTE: The battery charges fully during the first five hours of normal operation. Do not expect full battery run capability during this initial charge period.
- Page 13 2.5. Battery Kit Assembly (OPTIONAL for rack UPS) NOTICE: Please assemble battery kit first before installing it inside of UPS. Please select correct battery kit procedure below to assemble it. Batter Kit 2u...
- Page 14 Batter Kit 3u Batter Kit 4u...
- Page 15 Batter Kit 6u...
-
Page 16: Operations
3. Operations 3.1. Button Operation BUTTON FUNCTION Turn on the UPS: Press and hold ON/Mute button for at least 2 seconds to turn on the UPS. Mute the alarm: After the UPS is turned on in battery mode, press and hold this button for at least 3 seconds to disable or enable the alarm system. - Page 17 DISPLAY FUNCTION REMAINING BACKUP TIME INFORMATION Indicates the remaining backup time in pie chart. Indicates the remaining backup time in numbers. H: hours, M: minute, S: second FAULT INFORMATION Indicates that the warning and fault occurs. Indicates the warning and fault codes, and the codes are listed in details in 3-5 section.
-
Page 18: Audible Alarm
3.3. Audible Alarm Battery Mode Sounding every 4 seconds Low Battery Sounding every seconds Overload Sounding twice every second Fault Continuously sounding Bypass Mode Sounding every 10 seconds 3.4. LCD display wordings index ABBREVIATION DISPLAY CONTENT MEANING Enable Disable Escape High loss Low loss Battery... - Page 19 01: Output voltage setting. INTERFACE SETTING Parameter 3: Output voltage For 208/220/230/240 VAC models, you may choose the following output voltage: 208: presents output voltage is 208Vac. 220: presents output voltage is 220Vac. 230: presents output voltage is 230Vac (Default). 240: presents output voltage is 240Vac.
- Page 20 04: ECO enable/disable. INTERFACE SETTING Parameter 3: Enable or disable ECO function. ENA: ECO mode enable. DIS: ECO mode disable (Default). 05: ECO voltage range setting. INTERFACE SETTING Parameter 2 & 3: Set the acceptable high voltage point and low voltage point for ECO mode. Press the Down key or Up key.
- Page 21 INTERFACE SETTING Parameter 3: Enable or disable Bypass function. ENA: Bypass mode enable. DIS: Bypass mode disable (Default). 07: Bypass voltage range setting. INTERFACE SETTING Parameter 2 & 3: Set the acceptable high voltage point and acceptable low voltage. Press the Down key or Up key to set. HLS: Bypass high voltage point.
-
Page 22: Operating Mode Description
Parameter 3: Set up backup time on battery mode for general outlets. 0-999: setting the backup time in minutes from 0-999 for general outlets on battery mode. 0: When setting as “0”, the backup time will be only 10 seconds. 999: When setting as “999”, the backup time setting will be disabled. -
Page 23: Faults Reference Code
UPS is powered off and no output supply power, Standby mode but still can charge batteries. 3.7. Faults Reference Code FAULT EVENT FAULT ICON FAULT EVENT FAULT ICON CODE CODE Bus start fail Inverter output short Bus over Battery voltage too high Bus under Battery voltage too low Bus unbalance... -
Page 24: Trouble Shooting
4. Trouble Shooting If the UPS system does not operate correctly, please solve the problem by using the table below. SYMPTOM POSSIBLE CAUSE REMEDY Check if input power cord The AC input power is not firmly connected to the connected well. mains. -
Page 25: Storage And Maintenance
A UPS internal fault has occurred. There are two Fault code is shown as 01, 02, 03, possible results: 04, 11, 12, 13, 41 and 45 on LCD 1. The load is still supplied, Contact your dealer display and alarm is continuously but directly from AC power sounding. - Page 26 STORAGE TEMPERATURE RECHARGE FREQUENCY CHARGING DURATION -25°C - 40°C Every 3 months 1-2 hours 40°C - 45°C Every 2 months 1-2 hours 6. Technical Specifications – Stand Alone.
- Page 27 Derate to 80% of capacity in Frequency converter mode and to 80% when the output voltage is adjusted to 100/200/208 VAC SY-G reserves the right to change or modify product design, construction, specifications, or materials without prior notice and without incurring any obligation to make such...
-
Page 28: Technical Specifications
Derate to 80% of capacity in Frequency converter mode and to 80% when the output voltage is adjusted to 100/200/208 VAC SY-G reserves the right to change or modify product design, construction, specifications, or materials without prior notice and without incurring any obligation to make such... - Page 29 ANNOTATION: Sy-G reserves the right to alter the features of its products without prior notice. ® Sy-G Corporation 100 SE 2 St., Suite 2600. Miami, FL 33131 Office + (1-786) 837-5016 info@sy-g.com www.sy-g.com...
