USER MANUAL

Online UPS: Avenger Series
Rack Mount (RM)
120 VAC ‒ 220 VAC
Capacity: 1 KVA ~ 1.5 KVA ~ 2 KVA ~ 3 KVA
REVISION
DESCRIPTION
DATE
Rev. 1.3
Formal Release
2017/02/03

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 1 KVA and is the answer not in the manual?

Questions and answers

Related Manuals for Sy-G 1 KVA

Summary of Contents for Sy-G 1 KVA

  • Page 1: User Manual

    USER MANUAL Online UPS: Avenger Series Rack Mount (RM) 120 VAC ‒ 220 VAC Capacity: 1 KVA ~ 1.5 KVA ~ 2 KVA ~ 3 KVA REVISION DESCRIPTION DATE Rev. 1.3 Formal Release 2017/02/03...
  • Page 2 Warning: Caution Unsafe practices that could endanger health, safety and cause financial damage. Important Any important technical and operating information on the equipment, should not neglected. Annotation Sy-G reserves the right to alter the features of its products without prior notice.
  • Page 3 CONTENTS 1. Safety Warning .......................... 2 1.1. Transportation ........................2 1.2. Preparation .......................... 3 1.3. Installation ........................... 3 1.4. Operation ..........................4 1.5. Maintenance, service and faults .................. 4 2. Installation and Setup ......................5 2.1. Rear Panel View ......................... 5 2.2.

  • Page 4: Safety Warning

    1. Safety Warning Please comply with all warnings and operating instructions in this manual strictly. Save this manual properly and read carefully the following instructions before installing the unit. Do not operate this unit before reading through all safety information and operating instructions carefully.
  • Page 5 computer) to connect the UPS system to the building wiring outlet (shockproof outlet). Please only VDE-tested, CE-marked UL-marked 100/110/115/120/127 VAC models) power cables to connect the loads to the UPS system. When installing the equipment, it should ensure that the sum of the leakage current of the UPS and the connected devices does not exceed 3.5mA.

  • Page 6: Installation

    input voltage. Hazardous voltages may occur between the battery terminals and the ground. Before touching, please verify that no voltage is present! Do not dispose of batteries in a fire. The batteries may explode. Do not open or mutilate batteries. Released electrolyte is harmful to the skin and eyes.

  • Page 7: Installation And Setup

    2. Installation and Setup Before installation, please inspect the unit. Be sure that nothing inside the package is damaged. Please keep the original package in a safe place for future use. There are two different types of connector for the UPS (In and Out) online. Please see the following model table.

  • Page 8: Operating Principle

    2.2. Operating principle The operating principle of the UPS is show as below: Output Input Dynamic Bypass The UPS is compos EMI/RFI Rectifier EMI/RFI filters Inverter Filters /PFC inverter, battery converter, battery DC-to-DC Converter UPS o Battery Battery Charger The UPS is composed of mains input, EMI/RFI filters, rectifier/PFC, inverter, battery charger, DC-to-DC convert, battery, dynamic bypass and UPS output.

  • Page 9: Setup The Ups

    Rack mount installation Stand alone installation 2.4. Setup the UPS Before installing the UPS, please read below to select proper location to install UPS. 1. UPS should be placed on the flat and clean surface. Place it in an area away from vibration, dust, humidity, high temperature, flammable liquids, gases, corrosive and conductive contaminants.

  • Page 10: Operation

    2. Maintain an ambient temperature range of 0 ºC to 45 ºC for UPS optimal operation. For every 5ºC above 45ºC, the UPS will derate 12% of nominal capacity at full load. The highest working temperature requirement for UPS operation is 50 ºC. 3.
  • Page 11 The power cord is supplied in the UPS package. 100/110/115/120/127 VAC models: The power cord is attached to the UPS. The input plug is a NEMA 5-15P for 1 KVA and 1.5 KVA models, NEMA 5-20P for 2 model and NEMA 5-30P for 3KVA model.
  • Page 12 200/208/220/230/240 VAC models: 10A for the 1KVA and 1.5KVA models, 16A for the 2KVA and 3KVA models. 100/110/115/120/127 VAC models: 15A for the 1K and 1.5K models, 20A for 2K model and 30A for 3K model. Step 2: UPS input connection There two kinds of outputs: programmable outlets and general outlets.
  • Page 13 Step 5: Disable and enable EPO function This UPS is equipped with EPO function. By default, the UPS is delivered from factory with PIN 1 and PIN 2 closed (a metal plate is connected to PIN 1 and 2) for UPS normal operation. To activate EPO function, remove two screws on EPO port and metal plate will be removed.

  • Page 14: Battery Replacement

    2.5. Battery Replacement NOTICE: This UPS is equipped with internal batteries and user can replace the batteries without shutting down the UPS or connected loads. (Hot-swappable battery design) Replacement is a safe procedure, isolated from electrical hazards. NOTE: Upon battery disconnection, equipment is not protected from power outages. CAUTION!! Consider all warnings, cautions, and notes before replacing batteries.

  • Page 15: Battery Kit Assembly

    2.6. Battery kit Assembly (OPTIONAL) NOTICE: Please assemble battery kit first before installing it inside of UPS. Please select correct battery kit procedure below to assemble it. Battery Kit - 2 Units Battery Kit - 3 Units Page | 13...
  • Page 16 Battery Kit - 4 Units Battery Kit - 6 Units Page | 14...

  • Page 17: Operations

    3. Operations 3.1. Button Operation BUTTON FUNCTION Turn on the UPS: Press and hold ON/Mute button for at least 2 seconds to turn on the UPS. Mute the alarm: After the UPS is turned on in battery mode, press and hold this button for at least 3 seconds to disable or enable the alarm system.

  • Page 18: Lcd Panel

    3.2. LCD Panel DISPLAY FUNCTION Backup time information Indicates the estimated backup time. H: hours, M: minute, S: second. Configuration and fault information Indicates the configuration items, and the configuration items are listed in details in section 3-5. Indicates the warning and fault codes, and the codes are listed in details in section 3-7 and 3-8.

  • Page 19: Audible Alarm

    Indicates the AC to DC circuit is working. Indicates the PFC circuit is working. Indicates the inverter circuit is working. Indicates the UPS is working in converter mode. Indicates the output is working. Battery information Indicates the battery level by 0-24%, 25-49%, 50-74%, and 75-100%.

  • Page 20: Ups Setting

    Over Charge Site wiring fault Temperature Charger Battery Fault Bypass Out Range Bypass frequency unstable Battery Replace EEPROM error 3.5. UPS Setting Parameter 1: It’s for program alternatives. Refer to below table. Parameter 2 is the setting options or values for each program. Parameter 1 Parameter 2 01: Output voltage setting.
  • Page 21 02: Frequency Converter enable/disable. INTERFACE SETTING Parameter 2: Enable or disable converter mode. CF ENA: Converter modes enable. CF DIS: Converter mode disable (Default). 03: Output frequency setting. INTERFACE SETTING Parameter 2: Output frequency setting. You may set the initial frequency on battery mode: BAT 50: presents output frequency is 50Hz.
  • Page 22 100/110/115/120/127 VAC models, the setting range is from +3V to +12V of the nominal voltage (Default: +6V). LLS: Low loss voltage in ECO mode. 200/208/220/230/240 VAC models, the setting range is from -7V to -24V of the nominal voltage. (Default: +12V). 100/110/115/120/127 VAC models, the setting range is from...
  • Page 23 08: Bypass frequency range setting. INTERFACE SETTING Parameter 2: Set the acceptable high frequency point and acceptable low frequency point for Bypass mode. By pressing the Down key or Up key. HLS: Bypass high frequency point 50Hz output frequency models: 51-55Hz: setting the frequency high loss point from 51Hz to 55HZ (Default: 53.0Hz)
  • Page 24 11: Autonomy limitation setting INTERFACE SETTING Parameter 2: Set up backup time on battery mode for general outlets. 0-999: setting the backup time in minutes from 0- 999 for general outlets on battery mode. DIS: Disable the autonomy limitation and the backup time will depend on battery capacity.
  • Page 25 Battery capacity(AH) Total charging current (A) 7~20 20~40 40~60 60~80 80~100 100~150 14: Charger Boost voltage setting INTERFACE SETTING Parameter 2: Set up the charger boost voltage. 2.25-2.40: setting the charger boost voltage from 2.25 V/cell to 2.40V/cell. (Default: 2.36V/cell) 15: Charger Float voltage setting INTERFACE SETTING...
  • Page 26 17: External output isolation transformer connection INTERFACE SETTING Parameter 2: Allow or disallow external output isolation transformer connection. AO: Active Open (Default). ENA: If selected, It’s allowed to connect to an external output isolation transformer. It’s not allowed to DIS: If selected, (Default) connect to external output isolation transformer.

  • Page 27: Operating Mode Description

    00: Exit setting INTERFACE SETTING Exit the setting mode. 3.6. Operating Mode Description OPERATING MODE DESCRIPTION LCD DISPLAY When the input voltage is within acceptable range, UPS will provide pure and stable AC Online mode power to output. The UPS will also charge the battery at online mode.

  • Page 28: Faults Reference Code

    3.7. Faults Reference Code FAULT FAULT FAULT EVENT ICON FAULT EVENT ICON CODE CODE Bus start fail Battery voltage too high Bus over Battery voltage too low Bus under Charger output short Inverter soft start fail Over temperature Inverter voltage high Overload Inverter voltage Low Charger failure...

  • Page 29: Troubleshooting

    4. Troubleshooting If the UPS system does not operate correctly, please solve the problem by using the table below. SYMPTOM POSSIBLE CAUSE REMEDY Check if input power cord The AC input power is not firmly connected to the connected well. No indication and alarm even mains.
  • Page 30 shut down Fault code is shown as 43 and the automatically because of Remove excess loads from icon is lighting on LCD display. overload UPS output and restart it. Alarm is continuously sounding. output. SYMPTOM POSSIBLE CAUSE REMEDY shut down Fault code is shown as 14 on Check output wiring and if automatically...

  • Page 31: Storage And Maintenance

    5. Storage and Maintenance Operation The UPS system contains no user-serviceable parts. If the battery service life (3~5 years at 25°C ambient temperature) has been exceeded, the batteries must be replaced. In this case, please contact your dealer. BE SURE TO DELIVER THE SPENT BATTERY TO A RECYCLING FACILITY OR SHIP IT TO YOUR DEALER IN THE REPLACEMENT BATTERY PACKING MATERIAL.

  • Page 32: Technical Specifications

    [1] - Derate capacity to 80% when the output voltage is adjusted to 100VAC/200VAC/208VAC. SY-G reserves the right to change or modify product design, construction, specifications, or materials without prior notice and without incurring any obligation to make such changes and modifications on SY-G products previously or subsequently sold.

This manual is also suitable for:

1.5 kva2 kva3 kva
