1
重点
项目
校对项
库
A
文件名
1.版面尺寸
2.材质标注
3.物料编码
B
4.颜色标注
5.客户型号
6.产品名称
C
7.重量标注
8.电压功率
D
E
F
G
标记 处数 更改文件号
H
制 图
设 计
校 对
会 签
1
2
技术要求（版本号：2016）
1.本页仅示意，图纸从第2页开始；
2.印刷字体需清晰可见，文字不能粘到一起；
3.材质：105g铜版纸；
4.印刷颜色：单黑 Pantone Black C；
5.尺寸：145*210mm；
6.装订方式：钉装；
7.客户名称出口国家：马来西亚 MIDEA。
签 字
日 期
审 核
张奇慧
贾晓慧
标 准 化
古广君
古广君
审 定
20170731
日 期
2
4
3
封面
电磁炉
C16-RTY1619/C16-RTY1619-GL
说明书
K
1
3
4
5
16166000A17097
MIDEA-C16-RTY1619(C16-RTY1619-GL)-0501
105g铜版纸
1:1
广东美的生活电器制造有限公司
5
6
A
B
C
D
E
F
G
H
6
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Midea C16-RTY1619-GL
Summary of Contents for Midea C16-RTY1619-GL
- Page 1 3.物料编码 4.颜色标注 5.客户型号 6.产品名称 7.重量标注 8.电压功率 封面 技术要求（版本号：2016） 1.本页仅示意，图纸从第2页开始； 2.印刷字体需清晰可见，文字不能粘到一起； 3.材质：105g铜版纸； 4.印刷颜色：单黑 Pantone Black C； 5.尺寸：145*210mm； 6.装订方式：钉装； 7.客户名称出口国家：马来西亚 MIDEA。 16166000A17097 电磁炉 MIDEA-C16-RTY1619(C16-RTY1619-GL)-0501 C16-RTY1619/C16-RTY1619-GL 说明书 105g铜版纸 标记 处数 更改文件号 签 字 日 期 制 图 审 核 张奇慧 贾晓慧 设 计...
- Page 2 User’s Manual Model: C16-RTY1619-GL C16-RTY1619-BK Thank you for purchasing this Midea induction cooker. Please thoroughly read through this instruction manual before use and store it carefully for future use. The pictures are only for reference, please keep the real product as a...
-
Page 3: Safety Instructions
I.SAFETY INSTRUCTIONS For safety reasons and to avoid damage to the appliance or injuries to people, please abide by all the safety instructions below. Ignoring safety warnings may result in injuries. This appliance does not take into consideration the following situations: --- use by children or disabled people without supervision;... - Page 4 I.SAFETY INSTRUCTIONS Do not heat iron items on the The utensils provided for the induction cooker heating induction cooker can only be plate to avoid danger caused used for cooking with it. by high temperatures. These cooking utensils cannot be used on both induction cooker and gas stove.
- Page 5 I.SAFETY INSTRUCTIONS To avoid damage, avoid To avoid danger, do not place causing impacts on the paper, aluminium foil, cloth or heating plate. other unsuitable articles onto WARNING: If the surfaceis the induction cooker heating cracked, switch off the plate for indirect heating. appliance to avoid the possibility of electric shock.
- Page 6 I.SAFETY INSTRUCTIONS Do not touch the cooker plate When using the induction cooker or after use, please with sharp tools to avoid keep it clean. Protect the cracking or damaging the induction cooker from bugs, plate. If cracking is found on dust and humidity.
- Page 7 I.SAFETY INSTRUCTIONS Always clean the induction When operating the appliance cooker to prevent mess from or after moving the pot, the Danger of Danger of scalding scalding getting into the fan, which cooking area will remain hot could influence the normal for a period of time.
-
Page 8: Product Introduction
Performance Parameters Applied Rated Dimension Weight Model voltage/frequency power (mm) (kg) C16-RTY1619-GL 220-240V~ 50/60Hz 1600W 280x280x65 C16-RTY1619-BK Product Sketch Map Ceramic plate Air vent Cooking zone indicator Power cord Air entry... - Page 9 II.PRODUCT INTRODUCTION Before using New Induction cooker Read this guide, taking special note of the “Safety Instructions” section. Remove any protective film that may still be on your ceramic plate. Put the pot on the ceramic plate Make sure the air vents are not blocked and keep utensils away from the immediate surrounds of the ceramic plate.
- Page 10 III. OPERATION INSTRUCTIONS Plug in After the power supply is connected, a beep will be heard. The LED flash, indicating that the induction cooker is in standby mode. Heating Turn the control knob clockwise, a deep will be heard, the LED will light, the power setting from 1 to 5 level, the induction cooker starts heating.
-
Page 11: Compatible Cookware
IV. COMPATIBLE COOKWARE Iron oil frying Stainless steel pot Iron pan Iron kettle Enamel stainless Enamel cooking Iron plate steel kettle utensil Requirement for pot materials: containing magnetic inducting materials. Shape requirement: plat bottom, with the diameter more than 14.5 cm and less than 18 cm. After the first use, some white spots would appear at the bottom of the pot. -
Page 12: Troubleshooting
V. CLEANING AND MAINTENANCE For oil spots on the cooker plate, wipe the cooker plate by using a soft moist cloth with a little tooth paste or mild detergent. And then use a soft moist cloth to wipe it until no stain remains.
