Summary of Contents for Midea 30G20MA089-GFN
- Page 1 Gas cooktop user manual Model: 30G20MA089-GFN...
- Page 2 Preface Thank you for choosing our gas cooktop. To use this appliance correctly and prevent any potential risk, read these instructions before using the appliance. Keep these instructions in a place where you can find them easily. If you are unsure of any of the information contained in these instructions, please contact our customer care centre.
-
Page 3: Table Of Contents
contents Preface Safety Warning Safety Instructions Installation Child and People Safety During Use Cleaning and Service Environmental Information Instructions for use and maintenance Description of the appliance How to Use the appliance Safety and Energy saving advice Cleaning and Maintenance Technical instructions Using instructions Positioning... -
Page 4: Safety Instructions
Safety Instructions Please take the time to read this Instruction Manual before installing or using the appliance. If the appliance is sold or transferred to another person,ensure the booklet is passed on to the new user. accident caused by misuse in advance, and use the appliance more conveniently. Neglect of this mark may result in severe personal injury Danger/Warning or death. -
Page 5: Installation
Installation Warning This appliance shall be installed in Prior to installation,ensure that the accordance with regulations in force gas and electrical supply complies and only used in a well ventilated with the type stated on the rating space. plate. 220V-240V Where this appliance is installed in The gas pipe and electrical cable marine craft or in caravans, it should... -
Page 6: Child And People Safety
Child and People Safety Warning Do not allow children to play near or with the appliance. The appliance gets hot when it is in use. Children should be kept away until it has cooled. Caution from using the appliance safety without supervision or instruction by a responsible person to ensure that they can use the appliance safety. -
Page 7: During Use
During Use Warning Burner panel is not designed to operate from food. an external timer or separate remote control system. The use of a gas cooking appliance comes results in the production of heat and contact with water. Do not operate moisture in the room in which it is this appliance with wet hands. - Page 8 During Use materials in the storage drawer near this aerosols may be affected by heat and appliance. should not stored above or below the appliance. this appliance while it is in operaiton. ‘ ’ position when not in use. Caution This appliance is intended for domestic cooking only.It is not designed for commercial or industrial purposes.
-
Page 9: Cleaning And Service
Cleaning and Service Warning repaired cleaning agents. or serviced by an authorised Service Engineer and only genuine approved spare parts should be used. Caution and cooled. clean the appliance. Environmental Information with due regard to safety and the environment. unusable, by cutting off the cable. Correct Disposal of This Product (Waste Electrical &... -
Page 10: Description Of The Appliance
Description of the appliance Dimension Ignition Electric Burner Top Plate ΣQn (W*D*H) Connection supply device Feature Rapid (1), 220-240Vac, Continuous G1/2 thread 4.0kW Auxiliary (1) Glass Ignition 50Hz, 300*520*90 Type... -
Page 11: How To Use The Appliance
Description of the appliance ccessories Bracket (2) Sponge (2) Instruction Screw (2) Manual (1) How to Use the appliance Black circle: gas off Large flame: maximum setting Small flame: minimum setting The minimum setting is at the end of the anti-clockwise rotation of the control handle. All operation positions must be selected between the maximum and minimum position. - Page 12 How to Use the appliance Automatic ignition with flame failure safety device The appliance is fitted with a flame failure safety device on each burner, which is designed to stop the flow of gas to the burner head in the event of the flame going out.
-
Page 13: Safety And Energy Saving Advice
Safety and Energy saving advice - The diameter of the bottom of the pan should correspond to that of the burner. PANS BURNERS max. min. ■ Do not use cookware that Triple-Crown 200mm 240mm overlaps the edge of the Rapid 200mm 240mm burner. -
Page 14: Cleaning And Maintenance
Cleaning and Maintenance ■ Cleaning operations must only be carried out when the appliance is completely cool. ■ The appliance should be disconnected from your mains supply before commencing any cleaning process. ■ Clean the appliance regularly, preferably after each use. ■... - Page 15 Cleaning and Maintenance from the top plate. detergent or washing up liqui. cloth and wipe dry with a clean cloth. blocked. 1.Place the flame spreader ( 4 ) on to the burner cup ( 5 ) so that the ignition device and the flame supervision device extend through their respective holes in the flame spreader.The flame spreader must click into place correctly.
-
Page 16: Using Instructions
Using instructions Warnings ■ Do not modify this appliance. ■ This appliance must be installed by an authorised technician or installer. ■ Prior to installation, ensure that the local distribution conditions (nature of the gas and gas pressure) and the adjustment of the appliance are compatible. -
Page 18: Installing The Appliance
Installing the appliance Remove the pan supports, the burner lid and flame spreader and carefully turn the appliance upside down and place it on a cushioned mat. Take care that the Ignition devices and flame supervision devices are not damaged in this operation. -
Page 19: Gas Connection
Gas Connection ■ This appliance must be installed and connected in accordance with installa- tion regulations in force in the country in which the appliance is to be used. ■ This appliance is supplied to run on LPG and natural gas. Conversion for use on LPG and natural gases must only be undertaken by a qualified person. -
Page 20: Gas Specifition
Gas Specification Total Heat input Gas type & pressure Triple-Crow burner Rapid burner Auxiliary-rapid 3.6kW(262g/h) 3.0kW(218g/h) 1.0kW(73g/h) 0.87 G30 29mbar 0.50... -
Page 21: Electrical Connection
Electrical Connection ■ This appliance is designed to be connected to a 220-240V, 50Hz AC electricity supply. - Green/yellow = Earth - Blue = Neutral - Brown = Live The wire which is coloured green and yellow must be connected to the terminal which is marked with the letter E or by the earth symbol. -
Page 22: Gas Adjustment
Gas adjustment ■ Take precautions on the operations and adjustments to be carried out when converting from one gas to another. ■ All work must be carried out by a qualified technician. ■ Before you begin, turn off the gas and electricity supply to the appliance. Change the injector of the burners. -
Page 23: Trouble Shooting
Trouble shooting Repairs should be performed by a licensed technician only.Improper repair may result in considerable danger to you and others. Probable cause Solution Problem No Spark. Check the electricity supply. Not ignited The burner lid is badly assembled. Assemble the lid correctly. Open the gas supply The gas supply is closed.
