  • Page 1 UPS WEB/SNMP MANAGER CS121 Series User Manual – English Rel.51...
  • Page 2 Copyright of the European Union is effective (Copyright EU). Copyright (c) 1994-2007 GENEREX GmbH, Hamburg, Germany. All rights reserved. WEEE & RoHS: This product is compliant to the EU Directive WEEE 2002/96/EC, RoHS 2002/95/EC and the German implementation of the Electrical and Electronic Equipment Law.

  • Page 3: Table Of Contents

    3.2.5.5 UPS shutdown 3.2.5.6 AUX-Port Dieses Handbuch ist auch in Deutsch verfügbar! 3.2.5.7 Wake on LAN (WOL) Eine aktuelle Kopie erhalten Sie unter download bei www.generex.de. 3.2.6 Scheduled Actions 3.2.7 SNMP This manual is also available in German! 3.2.8 COM2 & AUX To obtain an actual copy please see the download-page of 3.2.8.1...

  • Page 4: The Cs121 Family - Introduction

    • SNMP Adapter CS121/CS121 Slot: The SNMP adapter is a compact unit requiring minimal workspace (ca. 28x69x126 mm for the external adapter CS121L). The slot card versions of the adapter (CS111 and CS121SC) get inserted into the extension slots of UPS models supporting its card type.

  • Page 5: About The Communication With The Cs121-Adapter

    UPS RS-232 protocol on COM1 directly to COM2. This allows the use of manual. additional monitoring software on COM2 while making extra hardware (RS-232 multiplexer) to For the CS121-SNMP MIB Implementation, please refer to the GENEREX download-page multiply the UPS comport unnecessary. http://www.generex.de/e/download/cs12x/download_p.html •...

  • Page 6: Comparison

    MODELS OPTIONS UPS models MODELS * (Slot FUJI) configuration via Terminalsoftware - and for connection of optional CS121L Second mini din 9 All 1400 UPS All CS121 devices are capable of managing devices for your CS121. external COM port for...

  • Page 7: Cs121 Overview

    Network connection RJ45 10/100 Base T Connector (with Status LED, green=link, yellow=activity) Figure 2: DIP-Switches: CS121L (left) in configuration mode (IP 10.10.10.10) and CS121SC (right) in normal mode Serial com-port (COM2) for configuration or connection of optional devices. (not Switch 1...

  • Page 8: Connect Your Cs121

    configuration of the SNMP adapter please ensure that the DIP switches are in the correct position. Please also refer to the section 1.5 CS121 overview in this manual. 1.7.2 ... via LAN Connect the CS121 with RJ45 cable (not included) to your LAN. Verifying the CS121 connectivity After the CS121-adapter is connected to the UPS and to the Computer via serial port or via LAN, please verify the connectivity before you start to configure the CS121.

  • Page 9: Quickstart

    2.1.1 Using HTTP/Webbrowser Quickstart The entire configuration can be done via Webbrowser. Please use the default IP-address The Quickstart manual gives you a short instruction into the main features and how to make 10.10.10.10 and the TELNET password (default: “cs121-snmp”). The username is always some basic settings and guides you in connecting the SNMP-adapter to the network and UPS.

  • Page 10: Using Telnet / Ms-Hyperterminal

    Apply your settings with the button at the right side. 2.1.2.2 Main menu & IP-Settings Change to menu “Network & Security” and specify IP-address, Gateway and Subnet mask to the CS121-adapter. Figure 8: Telnet - Main Menu To select any option in the main menu enter the number of the option at the Enter command =>...

  • Page 11: Ups Settings

    Enter Command => 6 USV 1 minutes, ensure you start (configure) the shutdown (or other event action) 3 minutes before the UPS is switched off, so that more than enough time is available to complete the corresponding To assign the UPS location SysLocation, type 6 and enter the location name: event action.

  • Page 12: About Same Basic Events

    to several client stations. In addition, it is possible to specify when and how often an action is For example to configure a job, which initiates a shutdown-signal to a client-workstation, to be released. please enter the event “System shutdown” in the menu “Events / Alarms”. The following “Event Editor”...

  • Page 13: Configuration Of The Cs121

    Configuration of the CS121 Note: After you have finished the basic network configuration you should have set DIP-switch 1 in position ON and rebooted the adapter. At the SC slot cards you have to remove the card from its slot and change the DIP Switch 1 to position ON.

  • Page 14: Network & Security

    3.2.2 Network & Security Figure 17: HTTP - UPS Model & System With the parameters UPS ID, system-name, -location, -contact you can describe the UPS and CS121. This is useful e.g. to locate the UPS physically and can be used among others for event settings.

  • Page 15: Email

    PC clock. For this you may choose any freeware from the internet or download from here: SMTP to ESMTP and a password is required. http://www.generex.de/wwwfiles/timeserver/atcs22.zip The length of the password should be a minimum 3 and a maximum of 63 characters.

  • Page 16: Events / Alarms

    Figure 21: MS-Timeservices Figure 22: HTTP - Event Configuration with tool tip To turn your Windows computer into a timeserver, double-click on the clock in the lower right Choose the event you wish to configure to enter the event editor. taskbar and open the following example.

  • Page 17: Treshold Events

    RCCMD clients are listening to an RCCMD server which is usually logfiles can also be watched with the GENEREX monitor-tools UPSMON or JAVAMON resp. an UPSMAN software, CS121 or any third-party UPS manager which has a license to use via the Webbrowser.

  • Page 18: Rccmd Shutdown

    Note: RCCMD clients are optional and not freeware. Most CS121 are Note: All network components, such as routers, hubs etc. need to be fully equipped today with a single RCCMD standard license, some UPS UPS-supported, as it is otherwise not possible to reach all clients during makers add more licenses, other do not deliver any license at all with a the network shutdown.

  • Page 19: Rccmd Execute/Command

    => switch off This RCCMD signal will cause any RCCMD receiver (e.g. another CS121, RCCMD client or “20000” is the command to switch outputs. (for other commands please contact GENEREX SITEMANAGER, SITESWITCH4) to execute a command or program. support)

  • Page 20: Ups Shutdown

    3.2.7 SNMP SM_BUZZ Alarmbeeper, etc. For a complete overview of “add-ons” for the AUX please see the Within this menu you can define access controls for SNMP-communities. This concern e.g. according datasheet, downloadable from www.generex.de. SNMP-Management tools, Trap receivers etc.

  • Page 21: Snmp

    Figure 38: HTTP - SNMP Figure 39: HTTP - COM2 Mode overview • Network Server Settings • Configuration Mode: The user may activate or deactivate different options from this menu. Telnet and or SNMP may This sets the normal configuration mode for using the provided cable (CS121-TEMP be switched on or off and the UPSMON access can be blocked.

  • Page 22: Aux And Siteswitch4 Settings

    The following describes the configuration of the AUX ports using the HTML interface. All of the AUX ports 1 – 4 can be manually set to „Output“ so that in the event of an alarm, the CS121 can be preconfigured in the “Events” menu to switch the ports individually. When all ports are set to “Output”, this is equivalent to activating the „SS4 Mode“.

  • Page 23: Ras Configuration

    3.2.11 Save Configuration / Reboot If you are satisfied with your configuration select “Save, Exit & Reboot” and wait until the adapter informs you about the reboot-process. Please notice that a reboot of the CS121 may take up to 3 minutes. During the boot phase the CS121 is compiling the user settings and waits for timeserver response.

  • Page 24: Adapter Software-Updates (Firmware)

    There are two ways to update your firmware-version, by using the Setup-tool or via FTP. Firmwareupdate via Setup-tool Firmware updates are available for free at www.generex.de. Download the specified version (mind your OEM ID) and follow up the setup-procedure. If necessary, consult your UPS dealer for further information.

  • Page 25: Firmware Flash Renewal And Recovery

    00-03-05-02-XX-XX Instructions for recovery procedure: Where XX-XX represents the HEX code of the last 4 digits of the GENEREX CS121 Board In case the CS121 is not running, has any defect or other problem, please put dip switch 1 to OFF (Dip 2 should be always OFF) and follow the procedure below: serialnumber (decimal).

  • Page 26: Additional Software

    Please start the installation of the RCCMD-client with the download of the latest version from www.generex.de. (If included, use also the CD from the adapter package) Uncompress the files, execute setup.exe and a wizard guides you through the installation. (Note: Some older versions (using InstallShield5) sometimes stop the installation process with a window, which shows you a completion of 99%.

  • Page 27: Rccmd Client As Relay Station

    RCCMD relays (see above). gChart gChart is a GENEREX plug-in for the MS Internet Explorer available as a free download from the GENEREX web site. Quickly and easily visualise all of the CS121-adapter logfiles using Generex's ActiveX graphical log controller GChart when using the Internet Explorer. Discover UPS problems more easily and optimise system tuning more rapidly.

  • Page 28: Ups Monitor (Upsmon)

    CS121 or any other RCCMD compliant sender like SITEMANAGER, SITEMONITOR. Figure 50: gchart plug-in for the internet explorer Get the GChart experience now by visiting our online CS121 at: http://q01.generex.de/ and be sure to follow the GChart logfile links. UPS Monitor (UPSMON) UPS-Monitor (UPSMON) is the graphical monitoring and command inferface application for UPSMAN and is available in standard and custom interfaces.

  • Page 29: Ss4 Feature Overview

    • Power socket status indicator via HTML, UPSMON, UNMS or SNMP The SMTCOM is a temperature sensor for the use with a GENEREX CS121. It has a range • Control via the internal CS121 or via remote CS121 or RCCMD compatible devices from -25°...

  • Page 30: Sensormanager (Sensorman)

    CS121 is available for download at: Channel Inputs as described above. http://www.generex.de/e/contact/cs12x-flash-links_p2.html If you use the sensor type SM, you may connect a second SM sensor to the input of the first SM. You can not connect more than 2 SM sensors in line.

  • Page 31: Configuration Of The Sensormanager

    A combination of CS121 – SITESWITCH 4 SENSORMANAGER in a compact chassis is the SITEMANAGER – for more information about this Rackmonitoring and management device please refer to GENEREX website. Figure 60: LED-Matrix display network integration • Startup the Sensor Manager: Any device operating as an RCCMD Sender like a computer running UPSMAN software, Connect the sensors to the SensorMan.

  • Page 32: Unms (Ups-Network Management System)

    (2006) in use worldwide. PROFIBUS was defined in 1991/1993 as DIN 19245, moved in 1996 to EN 50170 and is since 1999 included in IEC 61158/IEC 61784 Standards. To integrate the CS121 in a Profibus environment, GENEREX offers a Profibus gateway, which converts the MODBUS output of the CS121 into PROFIBUS environment.

  • Page 33: Troubleshooting - Faq

    US and Canada with the power supply 12 V DC, 300 mA. As well, for both hardware specifications 121 and 131 of CS121-Adapter a certification of Conformity has been drawn up. Please see the download page at www.generex.de to get a copy of the certifications and documents.
  • Page 34 Pin4: -> RxD Pin9: -> GND Pin8 connected with Pin 10 Figure 64: Cable configuration COM2 Figure 68: Pin COM2 Mini-DIN 8 pol Mini DIN 8 socket RS-232: Pin1: -> DCD Pin2: -> RxD Pin3: -> TxD Pin4: -> DTR Pin5: ->...

  • Page 35: Modbus Interface

    Pin5: -> Input/Output 4 Pin6: -> GND The maximum input voltage is 3,3V. The input signals may be fed from external power sources or feed directly from Pin 1. If the external power supply delivers more than 5V a pre-resistor has to be fitted.

  • Page 36: D.4.Modbus Modes In The Cs121 M (Ascii And Rtu)

    If the slave receives the query without a communication error, but cannot handle it (for example, if the request is to read a non existent register the slave will return an exception HEX: Hexadecimal values of the data response informing the master of the nature of the error. The word at address contains the value 1234h = 4660 decimal.
  • Page 37 3 / 4 CNT_PF Powerfail Counter 3 / 4 Alarm Battery Bad 1 = active; 0 = not active 3 / 4 xid645 Bits 16-31 Alarmbit, for details please contact NEWAVE 3 / 4 Alarm: On Battery 1 = active; 0 = not active 3 / 4 xid645 Bits 32-47 Alarmbit, for details please 3 / 4 Alarm: Battery Low...

  • Page 38: D.9.Modbus Cables

    word 4 Output frequency 0.1Hz D.6. Bus termination word 4 Battery voltage 0.1 Volt word 4 0.1A It is necessary to set the last bus device on the RS-485 Bus jumper for the bus termination. word 4 Battery temperature#1 0.1deg C The jumper is already set in newly delivered adapters.

  • Page 39: Pin Layout Of Input-Sockets Of The Sensormanager Unit

    …, Variable Meaning CUSTOM6TEXT OUTPUT_VOLT Output voltage - only supported from specified USV manufactures Pin layout of Input-sockets of the SENSORMANAGER unit OUTPUT_CURRENT Output currency INPUT 1: SECSONBATT Seconds, since the event power outage has been released Pin 1 Input Voltage 9-24Volt + STATUS Actual UPS state Pin 2 Analog Channel 1 (0-10V+)

  • Page 40: Table Of Figures

    Figure 1: Connectors of the CS121 ..................11 Figure 57: CS121-Installation with SENSORMANAGER.............58 Figure 2: DIP-Switches: CS121L (left) in configuration mode (IP 10.10.10.10) and Figure 58: HTTP - SENSORMANAGER Settings ..............59 CS121SC (right) in normal mode ................12 Figure 59: RASMANAGER network integration ..............60 Figure 3: CS121 in a network environment ................13...
