EXPLODED VIEW: FUEL SYSTEM LP VAPOR 4.6L 80KW
DRAWING #:0H3919
APPLICABLE TO:
ITEM PART#
1 0G9239D
2 057822
3 0H3894
4 082121A
5 0H3921
6 0H4537
7 026915
8 0A8064
9 064346
10 031015
11 030131
12 039130
13 065908
16 022304
17 052645
18 0G3167
19 0F3691C
20 0H39430ST03
21 059057
22 022195
23 045773
24 0F3885
25 086133E
26 0F0960
27 086133D
28 0G7104
29 0E4392
30 0E4390
31 0H3766B
32 097962
33 022097
34 042568
35 049811
36 0D3700
37 063831
REVISION: K-2798-D
DATE: 5/13/15
QTY. DESCRIPTION
1 REG ASSY 4.6L 80KW LPV 2009CPL
4 CLAMP HOSE #8 .53-1.00
1 INTAKE ELBOW 4.6L G3
1 CLIP-J VINYL COAT .375 ID
1 GASKET AIR INTAKE 4.6L G3
1 HARN FUEL JUMPER DUAL REG
2 NIPPLE CLOSE 3/4 X 1.375
2 BSHG RDCR HEX 1-1/4-3/4
1 PIPE TEE 1-1/4 NPT
1 NIPPLE PIPE 1-1/4 NPT X 3
1 ELBOW 90D 1-1/4 NPT
1 NIPPLE CLOSE 1.25 NPT X 1.625
1 SUPPORT NAT GAS SOLENOID
4 WASHER FLAT 1/2 ZINC
2 SCREW HHC M12-1.75 X 30 C8.8
2 O-RING 2-3/4 X 3/32 X 2-15/16
1 VENTURI THROTTLE 38MM
1 BRACKET INTAKE MANIFOLD UPPER
2 HOSE 3/4 ID SAE-30R2 (47.5" LG)
2 WASHER LOCK ½
2 NUT HEX M12-1.75 G8 YEL CHR
1 MIXER 40/60MM ACTUATOR ASSY
1 CLAMP HI TORQUE 2.75 - 3.625
1 REDUCER 3.0" TO 2.75" TURBO
1 CLAMP HI TORQUE 2.25 - 3.125
4 SCREW SHC M6-1.0 X 60 C12.9
1 ACTUATOR BOSCH 60 GOVERNOR
2 GASKET GOVERNOR ACTUATOR
1 RESTRICTOR INTAKE 4.6L G3 LPV
4 SCREW SHC M6-1.0 X 25 C12.9 ZP
4 WASHER LOCK M6-1/4
2 SCREW HHC M6-1.0 X 20 C8.8
2 WASHER FLAT M6
6 NUT FLANGE M6-1.0 NYLOK
1 PLUG PIPE 1.25 SQ HD ZINC
GROUP E
PAGE 2 OF 2
