Generac Power Systems 4.6L Owner's Manual page 146

(2) 1 0F58730ST01
(2) 2 0F58680ST01
(2) 3 0F58720ST01
(3) 4 0F58710AL01
(2) 5 0F58690ST01
(2) 6 0F58700ST01
(3) 7 0F58670AL01
11 0C2454
12 0F2766
13 0F3181
14 0F3185
15 0F3416
16 0F3949
17 0F4487A
18 022473
19 022097
20 022127
21 0F3072
22 078115
23 0F3949B
24 0F3949A
25 0F5048D
26 0E5968
27 0F5049
28 0F3949L
29 0F3949E
30 0F3890A
31 087233
32 0F3949C
33 0F3949D
34 0F3949G
35 0F3949J
36 0F3949K
37 0F3949F
38 0F3890B
39 0F3890
40 042568
42 022447
43 049813
(1) 44 077992
45 0912970094
46 0F2766A
47 0F3949M
48 0F8869D
49 0E3257
50 078115A
51 066760
(1) ALUMINUM ENCLOSURE NOTE: ALL ENCLOSURE PANELS THAT FASTEN TO
THE BASE FRAME MUST BE SECURED USING ITEM 11 & 49 THREAD FORMING
FASTENER AND ITEM 44 LOCK NUT. LOCK NUT IS TO BE INSTALLED AFTER THREAD
FORMING FASTENER HAS PENETRATED THROUGH EXTRUSIONS IN ENCLOSURE PANELS. ALL ROOF PANELS
ARE TO BE SECURED IN THE SAME MANNER.
(2) NOTE: PART NUMBER SHOWN IS FOR TAN / STEEL. REFER TO THE SAMPLE
GUIDE BELOW FOR AVAILABLE COLOR AND/OR ALUMINUM PART NUMBER FORMAT.
0FXXXX0ST01 = TAN / STEEL
0FXXXX0AL01 = TAN / ALUMINUM
0FXXXX0ST08 = T- GRAY / STEEL
0FXXXX0AL08 = T- GRAY / ALUMINUM
0FXXXX0ST05 = WHITE / STEEL
0FXXXX0AL05 = WHITE / ALUMINUM
(3) PART NUMBER SHOWN IS FOR TAN. SEE GUIDE BELOW FOR AVAILABLE COLOR AND PART NUMBER
FORMAT.
0FXXXX0AL08 = T- GRAY / ALUMINUM
0FXXXX0AL05 = WHITE / ALUMINUM
1 REAR WRAP C5
4 DOOR C5
2 CENTER SUPPORT C5
2 DISCHARGE DUCT LH & RH SIDE C5
2 FRONT CORNERS C5
1 DISCHARGE CENTER DUCT C5
1 ROOF C5 ALUM
86 SCREW THF M6-1 X 16 N WA Z/JS
2 SPLITTER
4 SPLITTER SHORT
2 STRINGER SPLITTER C3
2 SUPPORT SPLITTER C5 130KW
2 INSULATION CORNER POST
1 ASSEMBLY COVER ACCESS
5 WASHER FLAT 1/4-M6 ZINC
1 WASHER LOCK M6-1/4
1 NUT HEX 1/4-20 STEEL
20 INSULATION RETAINMENT HANGER
58 WASHER SELF LOCKING DOME #4-40
3 INSULATION SPLITTER
4 INSULATION SHORT LOUVER
4 VISE-ACTION LATCH SLOTTED CIR
1 GASKET EXTRUDED TRIM (566" LG)
4 TAB PULL
2 INSULATION SPLITTER SML
1 INSULATION ROOF TOP REAR
9 RETAINER INSULATION (740)
2 RIVET POP .1875 X .450 SS
1 INSULATION ROOF TOP
4 INSULATION DOOR
1 INSULATION DISCHARGE DUCT
2 INSULATION CENTER SUPPORT
1 INSULATION DISCHARGE DUCT TOP
2 INSULATION INNER DUCT SIDE
4 RETAINER INSULATION (820)
14 RETAINER INSULATION (450)
4 SCREW HHC M6-1.0 X 20 G8.8
4 WASHER SHAKEPROOF INT 1/4
4 NUT HEX M6 X 1.0 G8 YEL CHR
28 NUT HEX LOCK M6-1.0 SS NY INS
4 ASSY WIRE 14 AWG 34.8" GRN/YEL
1 SPLITTER C5
1 INSULATION SPLITTER SHRT MPS
1 KEY VISE-ACTION LATCH SLOT CIR
6 SCREW TH-FRM M6 W/CAP SHKPRF W
12 WASHER SELF LOCKING DOME #8-32
1 STRIP SEALANT 1/8 X 1 (44.52"LG)
0FXXXX0ST13 = BISQUE / STEEL
0FXXXXALT13 = BISQUE / ALUMINUM
0FXXXX0ST14 = GRAY / STEEL
0FXXXXALT14 = GRAY / ALUMINUM
0FXXXXALT13 = BISQUE / ALUMINUM
0FXXXXALT14 = GRAY / ALUMINUM
