Page 3
To register your equipment and activate your warranty, please go to www.ultraplay.com within 30 days of delivery. This will allow UltraPlay to have a record of your purchase in case of warranty claims. For more information on Discovery Centers and UltraPlay products, please do not hesitate to give us a call or visit ultraplay.com.
Page 4
Maintaining your playground equipment and its surrounding area is essential to minimizing the risk of injury to users as well as maximizing its useful lifespan. UltraPlay STRONGLY recommends that you follow these Safety Guidelines in conjunction with conducting periodic maintenance inspections using the accompanying Playground Maintenance Checklist.
Page 5
-Check and re-tighten all fasteners after the first few days of use and again after three weeks of use. Thereafter, exercise normal maintenance procedures. Use of a thread-locking compound on the threads of bolts can prevent persistent loosening. Issued/Revised: 02/02/16 www.ultraplay.com 800.458.5872...
Page 6
-Debris, broken glass, trash, or other foreign objects within or on the play area/equipment should be removed. -Check for poor drainage areas and repair. -Check concrete footings to see if they are exposed, cracked, or loose in the ground and repair as necessary. Continued on next page Issued/Revised: 02/02/16 www.ultraplay.com 800.458.5872...
Page 7
-Check for accessible sharp edges or points. Check for protruding bars, bolts, nuts, etc. Eliminate these conditions. -Check for exposed ends of tubing that should be covered with plugs or caps. -Check for loose bolts, nuts, etc. and tighten. Issued/Revised: 02/02/16 www.ultraplay.com 800.458.5872...
Page 11
1-year from the date of shipment to the original purchaser. In the event of a claim under this warranty, UltraPlay will replace the component at no cost within the first 12 months from date of shipment to the original customer. Equipment not specifically addressed in the following paragraphs is also subject to this limited 1 year warranty against defects in materials and/or workmanship.
Page 12
Or Contact a Customer Service Representative at: 1-800-458-5872 Within 60 days of notice of claim under warranty, UltraPlay will make arrangements to replace the damaged product. UltraPlay will cover freight costs within the continental United States. UltraPlay is not responsible for freight costs associated with products located outside the continental United States.
Page 13
Refer to the Tools Required page for a detailed list. INSTALLATION GUIDELINES: 1. Compare all parts received to the packing list. Notify UltraPlay immediately of any missing parts. We are not responsible for parts discovered missing over 10 days after receipt of the shipment.
Page 14
Also locate any freestanding play equipment in the same way, providing the necessary clearance between the equipment as well as any fences, trees, etc. Ensure at this time you have enough total space for the equipment to be installed. Issued/Revised: 02/02/16 www.ultraplay.com 800.458.5872...
Page 17
It is the predicted that a user would land when owner's responsibility to ensure the "minimum area required" contains an appropriate amount of resilient materal to cushion falling from or exiting the equipment. accidental falls. Issued/Revised: 02/02/16 www.ultraplay.com 800.458.5872...
Page 18
ELEVATION VIEW 162 1/4 in 109 1/2 in ELEVATION VIEW Issued/Revised: 02/02/16 www.ultraplay.com 800.458.5872...
Page 19
NOTE: All remaining dimensions are based off of the Placement for Deck Post placement. 12" Diameter x 12" Deep Holes 3. Measure from the center of a Deck Post using the for In-ground installation dimensions provided for each remaining hole. Issued/Revised: 02/02/16 www.ultraplay.com 800.458.5872...
It is the owner's responsibility to ensure the "minimum area required" contains an appropriate amount of resilient material to cushion accidental falls. SITE PREPARATION Clear area of any debris and level surface. Equipment is designed to be installed on a level surface Issued/Revised: 02/02/16 www.ultraplay.com 800.458.5872...
It is the owner's responsibility to ensure the "minimum area required" contains an appropriate amount of resilient material to cushion accidental falls. SITE PREPARATION Clear area of any debris and level surface. Equipment is designed to be installed on a level surface Issued/Revised: 02/02/16 www.ultraplay.com 800.458.5872...
It is the owner's responsibility to ensure the "minimum area required" contains an appropriate amount of resilient material to cushion accidental falls. SITE PREPARATION Clear area of any debris and level surface. Equipment is designed to be installed on a level surface Issued/Revised: 02/02/16 www.ultraplay.com 800.458.5872...
Page 27
Promptly cut-off flush, file smooth, and treat to prevent corrosion. Note: Peen Tee-Nuts and Flatwashers to match radius of pipe after assembly is complete. Note: Loctite (supplied by others) should be used on any non-patch hardware. Issued/Revised: 02/02/16 www.ultraplay.com 800.458.5872...
Page 31
LOWER POST, 22 11/16" LG. (02-08-0152) PLATFORM (02-08-0022) LOWER POST, 22 11/16" LG. (02-08-0152) LOWER POST COVER, 7 3/16" LG. (02-08-0050) PLATFORM LOWER POST, 22 11/16" LG. (02-08-0022) (02-08-0152) UPRIGHT POST, 51 7/8" LG. (02-08-0141) PLATFORM MOUNTING BRACKET UNDERNEATH (02-08-0120) Issued/Revised: 02/02/16 www.ultraplay.com 800.458.5872...
Page 32
LOWER POST, 22 11/16" LG. (02-08-0152) IMPORTANT: ORIENTATION OF DRILLED HOLES IN DECK IS CRITICAL UPRIGHT POST, 51 7/8" LG. (02-08-0141) DC-SAP DECK A w/2 INSERTS (02-08-0083) LOWER POST, 22 11/16" LG. (02-08-0152) SPROUT DECK w/8 INSERTS (02-08-0142) Issued/Revised: 02/02/16 www.ultraplay.com 800.458.5872...
Page 33
1. Slide Seedling Deck B onto Lower Posts. IMPORTANT: Orientation of squares in deck is critical. LOWER POST, 22 11/16" LG (02-08-0152) IMPORTANT: ORIENTATION OF SQUARES IN DECK IS CRITICAL. SEEDLING DECK B w/6 INSERTS (02-08-0006) Issued/Revised: 02/02/16 www.ultraplay.com 800.458.5872...
Page 34
STEP 5 1. Slide Handhold Brackets over Upright Posts. Align the pipe on the Handhold Bracket with the hole in the Deck. UPRIGHT POST, 51 7/8" LG. (02-08-0141) SPROUT DECK w/8 INSERTS (02-08-0142) HANDHOLD BRACKET (02-08-0140) Issued/Revised: 02/02/16 www.ultraplay.com 800.458.5872...
Page 35
1. Slide Shapes Panel and Handhold-Even onto the Upright Posts, making sure that the pipes on the Handhold Brackets are inserted into the bottom holes of the Handholds correctly. IMPORTANT: Panels and Handholds must slide over Upright Post simultaneously. UPRIGHT POST, 51 7/8" LG. (02-08-0141) HANDHOLD-EVEN (02-08-0143) SHAPES PANEL w/INSERT (02-08-0174) Issued/Revised: 02/02/16 www.ultraplay.com 800.458.5872...
Page 36
Handholds correctly. IMPORTANT: Panels and Handholds must slide over post simultaneously. Warning label must be positioned outwards. CLOCK PANEL (02-08-0011) UPRIGHT POST, 51 7/8" LG. (02-08-0141) HANDHOLD-EVEN (02-08-0143) WARNING LABEL IMPORTANT: WARNING LABEL MUST BE POSITIONED OUTWARDS Issued/Revised: 02/02/16 www.ultraplay.com 800.458.5872...
Page 42
STEP 12 1. Slide Handhold Bracket over the Lower Post. Align pipe of the Handhold Bracket with the hole in the Deck. LOWER POST, 21 11/16" LG. (02-08-0152) DC-SAP DECK A w/2 INSERTS (02-08-0083) HANDHOLD BRACKET (02-08-0140) Issued/Revised: 02/02/16 www.ultraplay.com 800.458.5872...
Page 43
STEP 13 1. Slide Climber Handhold-Odd over Lower Post, making sure the pipe of the Handhold Bracket is inserted into bottom hole of the Climber Handhold-Odd correctly. CLIMBER HANDHOLD-ODD (02-08-0004) LOWER POST, 22 11/16" LG. (02-08-0152) Issued/Revised: 02/02/16 www.ultraplay.com 800.458.5872...
Page 44
STEP 14 1. Slide Play Ramp and Upper Post Covers into place. UPPER POST COVER, 7 3/8" LG. (02-08-0033) UPPER POST COVER, 14 1/2" LG. (02-08-0039) UPPER POST COVER, 7 3/8" LG. (02-08-0033) PLAY RAMP (02-08-0059) Issued/Revised: 02/02/16 www.ultraplay.com 800.458.5872...
Page 45
UPPER POST, 29 1/8" LG. (02-08-0189) UPPER POST, 60 LG. SEE FIGURE 1 (02-08-0160) UPPER POST COVER, 7 3/8" LG. (02-08-0033) CLOCK PANEL (02-08-0011) PLAY RAMP (02-08-0059) REVERSED GEAR PANEL (02-08-0172) SLIDE HOOD w/6 INSERTS (02-08-0173) SHAPES PANEL w/INSERT (02-08-0174) Issued/Revised: 02/02/16 www.ultraplay.com 800.458.5872...
Page 51
2. Centered horizontally with Upright Post, measure 1" up from bottom of Roof and drill 1/8" pilot hole through Roof and Post Cover. See Detail 023. M10 x 50mm (2") BHCS BOLT (33-11-0010) POST CAP (02-08-0027) UPRIGHT POST PANEL M5 x 76mm (3") SELF-TAPPING SCREW (33-11-0600) 1 in ROOF [2.58 cm] POST COVER Issued/Revised: 02/02/16 www.ultraplay.com 800.458.5872...
Page 52
3. Attach Roof to Upright Posts and Upper Post Covers using M5 x 76mm Self-Tapping Screw. See Detail 024. ROOF DRILL Ø1/8" PILOT HOLE ROOF (02-08-0001) M5 x 76mm (3") SELF-TAPPING UPRIGHT SCREW (33-11-0600) POST POST COVER POST CAP (02-08-0027) UNDERNEATH Issued/Revised: 02/02/16 www.ultraplay.com 800.458.5872...
Page 53
2. Refer back to your Footing Detail options on pages 19 to 24 to finish assembly. M8 FLATWASHER (33-11-0300) FOOTER COVER M8 x 40mm (1 9/16") (02-08-0009) BHCS BOLT (33-11-0106) M10 LOCKWASHER (33-11-0201) LOWER POST COVER M8 BARREL NUT (33-11-0501) FOOTER COVER (02-08-0009) Issued/Revised: 02/02/16 www.ultraplay.com 800.458.5872...
