- Page 1 Unico Series REMOTE RADIO CONTROLLER Manuale d'uso - User manual - EN Ver. 1.0...
- Page 2 IMPORTANT SAFETY INSTRUCTIONS WARNING: READ THIS FIRST! WARNING RISK OF ELECTRIC SHOCK DO NOT OPEN AVIS RISQUE DE CHOC ÉLECTRIQUE NE PAS OUVRIR This symbol is intended to alert the user to the This symbol is intended to alert the user to presence of uninsulated “dangerous voltage”...
-
Page 3: Table Of Contents
Viscount Radio Remote Control UNICO INDEX Important notes ..........................19 Guide to the remote control ......................21 Control panel .............................22 Main screen ............................23 How to select and play a MIDI sequence ..................24 How to select and play a Songlist ....................25 The Repeat button..........................26 Alternative funcionts of the Register buttons ................27... - Page 4 Viscount Radio Remote Control UNICO BATTERIES • Use only batteries AA type, alkaline or rechargeable. • Do not place batteries near or in direct flame. • Do not let batteries come into contact with water (e.g. sea water) or other liquids.
-
Page 5: Guide To The Remote Control
Viscount Radio Remote Control UNICO GUIDE TO THE REMOTE CONTROL The Unico Radio Remote Control commands the internal sequencer of the Unico organs, to easily play MIDI tracks from distance. The remote control has a maximum range of 50 metres, when batteries are fully charged. It only works with four alkaline batteries AA type, 1.5 V. -
Page 6: Control Panel
Viscount Radio Remote Control UNICO CONTROL PANEL 1. Backlit display 2. Digit buttons: use to dial the code of the MIDI file or songlist you wish to play. 3. [LIST] button: enables sonsglists selection. 4. [SONG PREV.] and [SONG NEXT] buttons: select the previous or next song 5. -
Page 7: Main Screen
Viscount Radio Remote Control UNICO MAIN SCREEN Activate the remote control by pressing one of the buttons. The following screen will show: ú-26 óg16 ý _CONCERT1 Ý Containing these fields: 1. File list indicator: shows the file list currently selected (the first three digits of the .LST file name). -
Page 8: How To Select And Play A Midi Sequence
Viscount Radio Remote Control UNICO HOW TO SELECT AND PLAY A MIDI SEQUENCE In order to play a MIDI sequence, first load the desired .MID file. Please remember that these files are saved in an USB drive or inside the internal memory of the organ, in the nnn_songname.mid format;... -
Page 9: How To Select And Play A Songlist
Viscount Radio Remote Control UNICO To start playing the selected piece, press the [PLAY] button. Press it again to pause the song; a third pressure will resume the song. To stop playing press [STOP]. New MIDI files can be loaded whether in play, pause or stop condition. -
Page 10: The Repeat Button
Viscount Radio Remote Control UNICO îî£ ú-26 óg5 ý îî _MENUET î To start playing the selected piece, press the [PLAY] button. Press it again to pause the song; a third pressure will resume the song. To stop playing press [STOP]. -
Page 11: Alternative Funcionts Of The Register Buttons
Viscount Radio Remote Control UNICO ALTERNATIVE FUNCTIONS OF REGISTER BUTTONS The Register button usually control the active stops while playing a MIDI track, but they can also adjust the speed or transposition of a song. To switch to the alternative functions, press and hold the [REPEAT] button. The display will show what function the stops button are now allocated to. -
Page 12: Firmware Update
UNICO FIRMWARE UPDATE Whenever a firmware update is necessary, Viscount will release an update pack, to load on the organ via USB drive. This procedure is described in the organ user manual. After the organ has been updated, the new system has to be loaded on the remote control as well. - Page 13 - Should critical verifying/ writing memory errors occur when updating the firmware, the display will show the following message: UPLOADING SFTW SEVERE ERROR The remote control will reboot in a few seconds. Repeat the update procedure. Should the same error occur again, please contact our customer service by e-mail at service@viscount.it.
-
Page 14: How To Install The Remote Receiver Inside The Organ
Viscount Radio Remote Control UNICO HOW TO INSTALL THE REMOTE RECEIVER INSIDE THE ORGAN Unscrew the screws of the back panel. On Unico 500 first remove the upper lid shown in the picture, holding it as indicated by the arrows. Carefully lift the lid by holding it on both sides. - Page 15 Viscount Radio Remote Control UNICO Once the panel is free from the Velcro tape, lift it slightly to pull it off from the trail. Pull the panel until it comes out of the instrument. N.B. We strongly advice to perform these action with help from another person.
- Page 16 Viscount Radio Remote Control UNICO 5. Place the receiver inside the organ as shown in figure, then fix it to the wooden panel using two screws [1] included in the kit. 6. Insert the antenna cable [2] of the receiver in the adhesive support [3]. Fix the support to...
- Page 17 Viscount Radio Remote Control UNICO Link the flat cable to the CN1 connector of the remote receiver and to the CN28 RF MODULE connector of the organ CPU. Before you insert the connectors, place the flat cable together all the other electric wires between the CPU board and the circuits on the right side of the organ (looking the organ from behind).
- Page 18 Disposal of old Electrical & Electronic Equipment (Applìcable throughout the European Union and other European countries with separate collection programs) Dir. 2002/95/CE, 2002/96/CE e 2003/108/CE This syrnbol, found on your product or on its packaging, indicates that this product should not be treated as household waste when you wish to dispose of it.
- Page 20 Viscount International S.p.A. Via Belvedere Fogliense 154 – 47836 Mondaino (RN), ITALY Tel: +39-0541-981700 Fax: +39-0541-981052 Website: www.viscount.it - www.physisorgans.com Distribuito in Italia da TITAN MUSIC S.A. Strada Genghe di Atto, 80 47892 Acquaviva - Repubblica di San Marino Tel.
