UM2322
1

Features

• STM32L496AGI6 Arm
320 Kbytes of RAM in a UFBGA169 package
• USB OTG HS
• On-board current measurement
• SAI Audio CODEC
• ST-MEMS digital microphones
• 8-Mbit PSRAM
• 2 user LEDs
• 1 user and 1 reset push-buttons
• 4-direction joystick with selection button
• Board connectors:
– Camera 8 bit
– USB with Micro-AB
– Stereo headset jack including analog microphone input
– microSD™ card
• Board expansion connectors:
– Arduino™ Uno V3
– STMod+
• Board expansion features:
– Quectel UG96 worldwide cellular modem penta-band 2G/3G module, 7.2 Mbps
downlink, 5.76 Mbps uplink.
– Modem reset red LED and modem signaling green LED
– Switchable SIM interface, eSIM and micro SIM
– Pulse 2G/3G SMA antenna for frequency ranges: 824 / 900 / 1800 / 1900 / 2100 MHz
• Flexible power-supply options: ST-LINK, USB V
• On-board ST-LINK/V2-1 SWD,TAG debugger/programmer with USB re-enumeration
capability: mass storage, virtual COM port and debug port
• Comprehensive free software libraries and examples available with the STM32Cube
package
• Support of a wide choice of integrated development environments (IDEs) including IAR™,
®
Keil , GCC-based IDEs
®
-based microcontroller featuring 1 Mbyte of Flash memory and
UM2322 Rev 2
, or external sources
