nBOOT1 nBOOT0
(OPTR[23]) (OPTR[27])
0
1
1
0
Table 3. Boot settings (continued)
BOOT0 pin
(PH3)
X 1
1 X
0 X
0 X
BOOT0 SW
Main Flash
configuration
empty
OPTR[26])
1 X
0 X
0 X
0 X
UM2322 Rev 2
Hardware layout and configuration
Boot memory space alias
Embedded SRAM is aliased at
address 0x0000_0000
User FLASH memory is aliased
at address 0x0000_0000
Test FLASH memory is aliased
at address 0x0000_0000
Embedded SRAM is aliased at
address 0x0000_0000
