50 AMP Smart Energy Management System Model 900
6
DANGER:
SMARTENERGYMANAGEMENTSYSTEM
ENCLOSED ENERGY MANAGEMENT EQUIPMENT
The 50 AMP SMART EMS Model 900 is a centralized power switching, fusing and distribuition center.
Power from the 120/240 volt power source is fed into the box. The potential of lethal electrical shock is
present in this box. Inadvertent shorts at this box could result in damage and/or injury. All servicing of
this box should be done only by a qualified Service Technician
Diagnostic tools required: Low current Test Light, Accurate Voltmeter (digital readout preferred)
Intellitec
www.Intellitecsve.com
Installation & SERVICE MANUAL
50 Amp EMS Display Panel
