Table of Contents
Advertisement
Quick Links
전자
김경기
04-04-M13
Full HD 20x
Auto-Focus
ZOOM CAMERA
Please read this manual thoroughly before use, and keep it handy for future reference.
Design and specifications are subject to change without notice.
105(+/-5)mm
PRODUCTION RELEASE & REVISION
REV
DESCRIPT'N/BUYER
DWG No
A
INITIAL
-------------------
50303467
B
INITIAL
-------------------
50303467
REV.B - 1p protocol 수정
(재고 폐기 즉시적용)
2p 케이블라벨수정.
15p protocol&power input 수정
NOTES
1.MODEL: HSUI-H75DxZ2U8 /NO BRAND (SDI 88pi AIO)
2.MATERIAL: 모조지
WHITE
BIND
: STAPLES-2
3.COLOR: BLACK
4.SIZE: 105(+/-5)mm x 148(+/-5)mm
50303467
ITEM
UNLESS OTHERWISE SPECIFIED
APPROVALS
DATE
ALL DIMENSIONS ARE IN MM.
- TOLERANCE
LABEL
+/- 3
MANUAL
+/- 5
W.S.OH
04-04-M13
GUIDE
+/- 5
MATERIAL
CHKED
2
M.J.KWON
04-04-M13
COLOR
DRAWN
3
J.Y.LIU
04-04-M13
CHK
DATE
PARTS No. BY
J.Y.LIU
M.J.KWON 02-26-M13
J.Y.LIU
M.J.KWON 04-04-M13
DESCRIPTION/MATERIAL
QTY
PARTS LIST
TITLE
MANUAL INSTRUCTION
SIZE
REV.
B
A4
SCALE
DO NOT SCALE
Advertisement
Table of Contents
Related Manuals for Hitron HSUI-H75DxZ2U8
Summary of Contents for Hitron HSUI-H75DxZ2U8
- Page 1 Auto-Focus ZOOM CAMERA NOTES Please read this manual thoroughly before use, and keep it handy for future reference. Design and specifications are subject to change without notice. 1.MODEL: HSUI-H75DxZ2U8 /NO BRAND (SDI 88pi AIO) 2.MATERIAL: 모조지 WHITE BIND : STAPLES-2 3.COLOR: BLACK...
-
Page 2: Zoom Camera
Full HD 20x Auto-Focus ZOOM CAMERA Please read this manual thoroughly before use, and keep it handy for future reference. Design and specifications are subject to change without notice. -
Page 3: Explanation Of Graphical Symbols
WARNING TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK, DO NOT EXPOSE THIS PRODUCT TO RAIN OR MOISTURE. DO NOT INSERT ANY METALLIC OBJECTS THROUGH THE VENTILATION GRILLS OR OTHER OPENINGS ON THE EQUIPMENT. CAUTION CAUTION CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT REMOVE COVER(OR BACK). -
Page 4: Ce Compliance Statement
FCC COMPLIANCE STATEMENT FCC INFORMATION : THIS EQUIPMENT HAS BEEN TESTED AND FOUND TO COMPLY WITH THE LIMITS FOR A CLASS A DIGITAL DEVICE, PURSUANT TO PART 15 OF THE FCC RULES. THESE LIMITS ARE DESIGNED TO PROVIDE REASONABLE PROTECTION AGAINST HARMFUL INTERFERENCE WHEN THE EQUIPMENT IS OPERATED IN A COMMERCIAL ENVIRONMENT. -
Page 5: Important Safety Instructions
IMPORTANT SAFETY INSTRUCTIONS... - Page 6 INTRODUCTION The 1/2.9” 2M full HD CMOS X20 ZOOM camera, especially for closed circuit television CCTV and security surveillance application. THE CAMERA FEATURES High performance SONY 1/2.9” Exmor CMOS. 2.2M 1080p Full HD, Excellent picture quality. 1920x1080p / 30fps, 1280x720p / 60fps. 20x Optical zoom.
-
Page 7: Camera Connections
CAMERA CONNECTIONS 1. Lens : 20x Optical Zoom( f=4.7~94mm) Lens for wide area monitoring. 2. Video(CVBS) : BNC connector used to connect the camera to a monitor, switcher, etc. 3. Video(HD-SDI) : BNC connector used to connect the camera to a HD-SDI monitor, HD-SDI convertor, etc. -
Page 8: Package Contents
PACKAGE CONTENTS SUNSHIELD CAMERA SUNSHIELD-BOLT SCREWS REMOTE CONTROLLER Screw Firmly attach the bracket to the wall or ceiling DIMENSIONS (3.4) (6.5) (10.9) UNIT : mm (inches) WATER INGRESS PREVENTION After using the Remote Control cable, disconnect it and insert the Remote Control Port Cap. Secure it tightly. -
Page 9: Camera Adjustment
CAMERA FIXING CAMERA ADJUSTMENT... -
Page 10: Camera Connection
Connect the remote control using the 6 pin din connector end to the socket within the camera: Connect the BNC to a set up monitor to view the picture and On Screen Menus. To Enter the menus press the button on the remote control. To Navigate the menus, move the button left/Right/Up and Down, press the button to Enter. -
Page 11: Structure Of The Setup Menu
STRUCTURE OF THE SETUP MENU <SETUP> LENS EXPOSURE <ZOOM LENS> <EXPOSURE> WDR/BLC FOCUS MODE IRIS DAY & NIGHT ZOOM SPEED SHUTTER IMAGE FOCUS SPEED BRIGHTNESS FUNCTION DISTANCE SYSTEM DZOOM COMBI EXIT ZOOM DISP LENS INIT DEFOG RETURN RETURN < > <... - Page 12 LENS The LENS menu is used to set the AF lens control and initialization. It provides the ability to adjust zoom speed, focus speed, distance and lens initialization functions of the camera. 1) FOCUS MODESelect the FOCUS MODE. ▶AUTO, PUSHAF, MANUAL 2) ZOOM SPEEDSelect the ZOOM SPEED.
- Page 13 <IRIS> <EXPOSURE> ► IRIS AUTO SHUTTER AUTO <EXPOSURE> BRIGHTNESS IIIIII F NO IIIIII F1.8 RETURN DEFOG RETURN The screen color can be adjusted by using the Auto White Balance function. It compensates for deviations in the white color caused by changes in the color temmperature of the light source so that the colors are reproduced correctly.
- Page 14 < WDR/BLC> <WDR> <SETUP> GAIN IIIIII LENS WEIGHT EXPOSURE RETURN AUTO ► WDR/BLC <BLC> DAY&NIGHT X-POS IIIIII IMAGE Y-POS FUNCTION X-SIZ SYSTEM Y-SIZ EXIT RETURN DAY&NIGHT The DAY&NIGHT menu is used to configure the day and night related setting for the camera. 1) D&N AUTO - Input Method SENSOR...
- Page 15 IMAGE The IMAGE menu provides the ability to adjust the CHROMA, SHARPNESS, EFFECT, STILL, SHADING, HLMASK, DZOOM and GAMMA functions of the camera. Adjust the CHROMA level. ▶ 0 ~ 20 1) CHROMA Adjust the SHARPNESS level. ▶ 0 ~ 10 2) SHARPNESS 3) EFFECT OFF, MIRROR, FLIP, ROTATE...
- Page 16 FUNCTION The IMAGE menu provides the ability to adjust the DNR, MOTION DET, PRIVACY, SHADING DET, DEFECT DET and PRESET functions of the camera. 1) DNR Select Digital Noise Reduction.▶ OFF, LOW, MIDDLE, HIGH Detects the Motioned Object in the image. ▶ ON, OFF 2) MOTION RESOLUTION SENSITIVITY...
- Page 17 FUNCTION <MOTION> <FUNCTION> <MOTION> MIDDLE RESOLUTION SENSITIVITY ► MOTION PRIVACY WINDOW USE SHADING DET X-POS IIIII DEFECT DET Y-POS IIIII X-SIZ RETURN IIIII Y-SIZ ALARM RETURN <ALARM> <MOTION> RESOLUTION SENSITIVITY <ALARM> WINDOW USE X-POS IIIII 3 SEC DWELL TIME Y-POS IIIII RETURN X-SIZ...
- Page 18 SYSTEM The IMAGE menu provides the ability to adjust the RS485, CAM TITLE, DISPLAY, OUT MODE, LANGUAGE, VERSION and RESET functions of the camera. 1) RS485 Select the CAMERA ID. ▶ 1 - 255 CAM ID Select RS485 PROTOCOL. ▶ FASTRAX, PELCO-P, PELCO-D,COMMAND PROTOCOL BAUD RATE Select serial communication speed.▶2400, 4800, 9600, 19200, 38400 BPS...
- Page 19 SYSTEM <CAM TITLE> <SYSTEM> <CAM TITLE> RS485 ^ ^ ^ ^ ^ ^ ^ ^ ^ ^ ► CAM TITLE DISPLAY 0 1 2 3 4 5 6 7 8 9 OUT MODE A B C D E F G H I J ENGLISH LANGUAGE KLMNOPQRST...
-
Page 20: Specifications
SPECIFICATIONS MODEL HSUI-H75DxZ2U8 AC24V / DC12V ± 10% Power Source POWER Power Consumption 10.0Watts (700mA) 1080p@30fps, 720p@60fps Resolution VIDEO Composite Out NTSC/PAL Selectable Optical Zoom 20x(f=4.7mm ~ 94.0mm) F1.6(wide)~ F3.5(tele) Lens Scanning system Progressive Image Sensor 1/2.9” CMOS 2.1M Scanning Mode Progressive Scan Optical WIDE to Optical TELE: 2.0 sec (Variable) - Page 21 50303467B...
