- Page 1 Operating instructions Control monitor for temperature sensors TR7432...
-
Page 2: Table Of Contents
Contents 1 Preliminary note3 11 Symbols used 3 2 Safety instructions 3 3 Functions and features 4 4 Function 4 41 Communication, parameter setting and evaluation 4 42 Switching function 5 5 Installation 5 6 Electrical connection6 7 Operating and display elements 7 8 Menu8 81 Menu structure 8 82 Explanation of the menu 9... -
Page 3: Preliminary Note3
11 Scale drawing ....................15 12 Technical data ....................16 12.1 Setting ranges ....................17 13 Factory setting ....................17 1 Preliminary note 1.1 Symbols used ► Instruction > Reaction, result […] Designation of pushbuttons, buttons or indications → Cross-reference Important note Non-compliance can result in malfunctions or interference. 2 Safety instructions •... -
Page 4: Functions And Features 4
3 Functions and features With temperature sensors connected the unit monitors the system temperature in machinery and plant Connectable temperature sensors: • Temperature sensors TS or TT • Resistance thermometer RTD (Pt 100 or Pt 1000) The unit automatically detects the connected sensor type and configures itself ac- cordingly The electrical measuring method (3-wire or 4-wire sensor) is determined via the menu setting (→ 9.5.1). -
Page 5: Installation 5
4.2 Switching function OUTx changes its switching state if it is above or below the set switching limits (SPx, rPx) The following switching functions can be selected: • Hysteresis function / normally open: [OUx] = [Hno] (→ fig. 1). • Hysteresis function / normally closed: [OUx] = [Hnc] (→ fig. 1). First the set point (SPx) is set, then the reset point (rPx) with the requested differ- ence •... -
Page 6: Electrical Connection
6 Electrical connection The unit must be connected by a qualified electrician The national and international regulations for the installation of electrical equipment must be adhered to Voltage supply to EN 50178, SELV, PELV ► Disconnect power ► Connect the unit as follows: �... -
Page 7: Operating And Display Elements 7
Menu setting: Mmod = 4w, links between 1 / 2 and 3 2-wire sensor / 4 A wiring fault can be corrected in the menu COF connection for Menu setting: Mmod = 3w, link between 1 / 2 temperature The maximum cable resistance of 10 Ω per core must sensor 3-wire sensor not be exceeded (this corresponds to a cable length of... -
Page 8: Menu8
8 Menu 8.1 Menu structure ��� � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � �... - Page 9 8.2 Explanation of the menu SP1/rP1 Upper / lower limit value for system temperature at which OUT1 switches SP2/rP2 Upper / lower limit value for system temperature at which OUT2 switches Output function for OUT1: Switching signal for the temperature limit values: Hysteresis function [H ] or window function [F ], either normally open [ no] or normally closed [ nc] Output function for OUT2: Switching signal for the temperature limit values: Hysteresis function [H ] or...
-
Page 10: Parameter Setting 10
9 Parameter setting During parameter setting the unit remains in the operating mode It continues its monitoring function with the existing parameters until the parameter setting has been completed 9.1 General parameter setting 3 steps must be taken for each parameter setting: Selection of the parameter ►... - Page 11 ► Press [Set] and keep it pressed until ���������� ��� the valid code no is displayed ► Press [Mode/Enter] briefly On delivery by ifm electronic: no access restriction ► Press [Set] briefly > The first parameter of the sub-menu ���������� ���...
- Page 12 9.2 Configuration of the display (optional) ► Select [Uni] and set the unit of measurement: [°C] or [°F] ► Select [diS] and set the update rate and orientation of the display: [d1]: Update of the measured values every 50 ms [d2]: Update of the measured values every 200 ms [d3]: Update of the measured values every 600 ms [rd1], [rd2], [rd3]: Display as for d1, d2, d3;...
- Page 13 9.4.2 Zero point calibration ► Select [COF] and enter value Setting range: -100100 °C in steps of 01 °C -180 180 °F in steps of 01° F The internal measured value "0" is shifted by this value 9.4.3 Setting the switching delays [dS1] / [dS2] = switch-on delay for OUT1 / OUT2 [dr1] / [dr2] = switch-off delay for OUT1 / OUT2 ►...
-
Page 14: Operation 14
10 Operation After power on, the unit is in the Run mode (= normal operating mode) It carries out its measurement and evaluation functions and provides output signals accord- ing to the set parameters Operating indications → Chapter 7 Operating and display elements. 10.1 Reading of the set parameters ►... - Page 15 Response of the outputs in case of a parameter setting fault [PARA]: OUT1 OUT2 Invalid setting [OU1] / [OU2] Invalid setting [FOU1] / [FOU2] Invalid setting [P-n] Invalid setting of other parameters acc to setting [FOU1] acc to setting [FOU2] 11 Scale drawing �...
-
Page 16: Technical Data
12 Technical data Measuring range [°C / °F] ..............-40...300 / -40...572 Communication interface ................... IO-Link 1.0 Baud rate [kBAUD] ......................38.4 Operating voltage [V] ................... 18...32 DC Current rating [mA] ......................250 Short-circuit protection (pulsed); protected against reverse polarity and overload Integrated watchdog Voltage drop [V] .......................<... -
Page 17: Factory Setting
12.1 Setting ranges SP1 / SP2 rP1 / rP2 ∆T °C -39.8 300.0 -40.0 299.8 °F -39.6 572.0 -40.0 571.6 ∆T = step increment 13 Factory setting Factory setting User setting 60.0 50.0 120.0 100.0 Mmod FOU1 FOU2 °C Technical data and further information at www.ifm.com...
