Control monitor for temperature sensors

Advertisement

Quick Links

Operating instructions
Control monitor for temperature sensors
UK
TR2439

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the efector600 TR2439 and is the answer not in the manual?

Questions and answers

Summary of Contents for IFM Electronic efector600 TR2439

  • Page 1 Operating instructions Control monitor for temperature sensors TR2439...
  • Page 2: Table Of Contents

    Contents 1 Safety instructions �����������������������������������������������������������������������������������������������3 2 Functions and features ����������������������������������������������������������������������������������������3 3 Function ���������������������������������������������������������������������������������������������������������������4 3�1 Switching function ������������������������������������������������������������������������������������������4 3�2 Analogue function ������������������������������������������������������������������������������������������5 3�2�1 Current output ���������������������������������������������������������������������������������������5 3�2�2 Voltage output ���������������������������������������������������������������������������������������6 3�3 Display colour change �����������������������������������������������������������������������������������7 3�3�1 Parameter r1ou, G1ou ��������������������������������������������������������������������������7 3�3�2 Parameter r-cF, G-cF ����������������������������������������������������������������������������8 3�4 IO-Link �����������������������������������������������������������������������������������������������������������8 3�4�1 General information ������������������������������������������������������������������������������8 3�4�2 Device-specific information �������������������������������������������������������������������8...
  • Page 3: Safety Instructions

    9 Operation �����������������������������������������������������������������������������������������������������������17 9�1 Reading of the set parameters ��������������������������������������������������������������������17 9�2 Error indications / self-diagnostics ���������������������������������������������������������������18 10 Technical data ��������������������������������������������������������������������������������������������������18 11 Factory setting �������������������������������������������������������������������������������������������������19 1 Safety instructions • Please read this document prior to set-up of the unit� Ensure that the product is suitable for your application without any restrictions�...
  • Page 4: Function

    3 Function • The unit displays the current system temperature� • It features an IO-Link interface and is designed for full bidirectional communi- cation� • The unit generates 2 output signals according to the parameter setting: - OUT1/IO-Link: Switching signal, limit values for temperature - OUT2: Analogue signal for temperature 3.1 Switching function OUT1 changes its switching status if it is above or below the set switching limits�...
  • Page 5: 3�2 Analogue Function

    When set to the window function the upper limit value (FH1) and the lower limit value (FL1) have a fixed hysteresis of 0�25 % of the final value of the measuring range� This keeps the switching state of the output stable if the temperature varies slightly�...
  • Page 6: 3�2�2 Voltage Output

    [ou2] = I [ou2] = I T < MAW (ASP2) 3�8���4 mA 20�5���20 mA T > MEW (AEP2) 20���20�5 mA 4���3�8 mA In case of internal fault, the output signal behaves according to the parameter set in [FOU2]: [FOU2] = On [FOU2] = OFF [ou2] = I 21 mA...
  • Page 7: 3�3 Display Colour Change

    In case of internal fault, the output signal behaves according to the parameter set in [FOU2]: [FOU2] = On [FOU2] = OFF [ou2] = U 10�6 V [ou2] = U 10�6 V 3.3 Display colour change The colour of the characters in the display can be set via the parameter [colr]� With the parameters rED (red) and GrEn (green), the display is permanently set to one colour�...
  • Page 8: 3�3�2 Parameter R-Cf, G

    3.3.2 Parameter r-cF, G-cF Colour change if the measured value is within definable limits� MAW = initial value of the measuring range, MEW = final value of the measuring range 3.4 IO-Link 3.4.1 General information This unit has an IO-Link communication interface which requires an IO-Link-capa- ble module (IO-Link master) for operation�...
  • Page 9: Installation

    4 Installation ► Connect the unit to a temperature sensor and fix it with the help of mounting accessories� Mounting set for direct connection of temperature sensors TT: E30017� Further information of mounting accessories at www�ifm�com� 5 Electrical connection The unit must be connected by a qualified electrician� The national and international regulations for the installation of electrical equipment must be adhered to�...
  • Page 10: 5�1 Sample Circuits For Connection Of Tr2439

    5.1 Sample circuits for connection of TR2439 1 x positive switching / 1 x analogue 1 x negative switching / 1 x analogue 1 BN 1 BN 2 WH 4 BK 4 BK 2 WH 3 BU 3 BU Pin 1 Pin 3 Pin 4 •...
  • Page 11: Operating And Display Elements

    6 Operating and display elements 1, 2, 3: Indicator LEDs • LED 1 = switching status OUT1 (lights if output 1 is switched) • LED 2 = temperature in the indicated unit of measurement • LED 3 = no function 4: Alphanumeric display, 4 digits •...
  • Page 12: Menu

    7 Menu 7.1 Process value display (RUN) and menu structure - - - - °C °F Hno Hnc Fno Fnc Ineg Uneg 0,0...50 s 0,0...50 s FOU1 OFF On ASP2 FOU2 OFF On AEP2 °C °F Mmod PnP nPn 0,0 °C 0,0 °C -10...10 °C GrEn r1ou G1ou...
  • Page 13: 7�2 Explanation Of The Menu

    7.2 Explanation of the menu Set point (upper limit value) with hysteresis function Reset point (lower limit value) with hysteresis function Set point (upper limit value) with window function Set point (lower limit value) with window function ASP2 Analogue start point AEP2 Analogue end point Mmod...
  • Page 14: Parameter Setting

    Zero-point calibration� The internal measured value 0 is shifted by this value� coLr Colour configuration of the display: = Process value always red� GrEn = Process value always green� r1ou = Process value red in case of switched output OUT1� G1ou = Process value green in case of switched output OUT1�...
  • Page 15: 8�1 Parameter Setting In General

    8.1 Parameter setting in general 1� Change from the RUN mode to the main menu [●] 2� Select the requested parameter [▲] or [▼] 3� Change to the setting mode [●] 4� Modification of the parameter value [▲] or [▼] > 1 s 5�...
  • Page 16: 8�1�3 Locking / Unlocking

    8.1.3 Locking / Unlocking The unit can be locked electronically to prevent unintentional settings� On delivery: not locked� Locking ► Make sure that the unit is in the normal operating mode� ► Press [▲] and [▼] simultaneously for 10 s until [Loc] is displayed. During operation: [Loc] is briefly displayed if you try to change parameter values�...
  • Page 17: 8�1�7 Read The Min/Max Values

    8.1.7 Read the min/max values ► Select [Hi] or [Lo] and read the value� [Hi] [Lo] [Hi] = max� value, [Lo] = min� value� Delete memory: ► Select [Hi�T] or [Lo�T]� ► Briefly press [●]. ► Keep [▲] or [▼] pressed. >...
  • Page 18: 9�2 Error Indications / Self-Diagnostics

    9.2 Error indications / self-diagnostics Diplay Warning message [SC1] Excessive current at OUT1� LED1 for OUT1 flashing� [OL] Detection zone exceeded� [UL] Below the detection zone� [C�Loc] Setting pushbuttons locked, parameter change rejected� Active IO-Link communication� [S�Loc] Setting pushbuttons locked, parameter change rejected� Unlock using parameter setting software�...
  • Page 19: Factory Setting

    11 Factory setting Factory setting User setting 60 °C 50 °C ASP2 -40 °C AEP2 300 °C Mmod FOU1 FOU2 °C coLr Further information at www�ifm�com...
