Q U I C K
S T A R T
G U I D E
What's included:
• Drone
• Rechargeable Battery
• Charging Cable
• Memory Card
• Memory Card USB Adapter
• Spare Parts Kit
• Transmitter
BEFO R E YOU S TAR T:
1. Locate the memory card. It is located in the small plastic pouch with your USB Adapter. It may be
inserted into the end of the adapter.
2. Slide the memory card into the back of the camera on the underside of your drone and push until you
hear a click. The card should slide in easily. If you find it is not clicking into place remove the card, turn
it over and try again. Do not force the card. To remove the card, push in until you hear a click.
3. Charge the drone fully by connecting the cable on the battery to the included USB cable. Plug it into
the USB port of a computer or a USB compatible charging block and allow it to charge for at least 90
minutes. During charging, the USB connector will illuminate. When the battery is fully charged the light
on the USB connector will turn off.
4. Put 4 AA batteries into the Transmitter according to the diagram inside the battery compartment.
T U R N I N G O N D R O N E A N D PA I R I N G W I T H T R A N S M I T T E R
1. Unplug the battery from the charging cable.
2. Insert the battery into the compartment on the underside of the drone with the battery cable sticking
out. (Note: the camera does not need to be removed.)
3. Insert the white battery connector into the slot marked power and close the battery compartment.
4. Turn on the power switch on the back of the drone and place the drone on a flat level surface.
5. Turn on the Transmitter using the power switch. The lights on the drone will begin flashing.
6. Start by moving the left stick on the transmitter all the way down. Next, push the left stick on the
transmitter all the way up, then all the way back down again. The lights on the drone should stop
flashing and remain illuminated. This means the drone is paired. If this does not occur, turn off the
remote control and repeat steps 3-5.
7. Once paired, the drone is ready to fly. The rotors will remain locked until Autopilot is activated. It is
STRONGLY recommended that you use the drone outdoors.
Advertisement
Table of Contents
Related Manuals for WORLD TECH ELITE STRIKER-X
Summary of Contents for WORLD TECH ELITE STRIKER-X
- Page 1 Q U I C K S T A R T G U I D E What’s included: • Drone • Rechargeable Battery • Charging Cable • Memory Card • Memory Card USB Adapter • Spare Parts Kit • Transmitter BEFO R E YOU S TAR T: 1.
- Page 2 T RA NSMITTER OVERVIE W Antenna Autopilot Video Record Control Easy Mode Photo Control Speed Control* Flip Stunt Mode Power Indicator Forward/Backward Trim Ascend/Descend Forward/Backward Turn Left/Right Move Left/Right Move Left/Right Trim Turn Left/Right Trim LCD Screen Power Switch 1. Your transmitter has an LCD screen on it that provides basic information including the thrust % usage while flying your drone, battery life, and connection strength between the transmitter and the drone.
- Page 3 F LYING THE D RON E 1. Once the drone and transmitter are paired, press the AUTOPILOT button to start the rotors. The drone will ascend 3-5 feet and hover in place with no other input. 2. Gently push up on the left stick to gain altitude. Use the right stick to move the drone forward, backward, left and right.
- Page 4 NOTES: ITEM NO. 33042...
