Operating instructions Static Control Digital Ident number: HAUG GmbH & Co. KG 12.7206.000 Friedrich-List-Straße 18 D-70771 Leinfelden-Echterdingen Phone: +49 711 / 94 98-0 Telefax: +49 711 / 94 98-298 www.haug.de E-Mail: info@haug.de HAUG Biel AG Johann-Renfer Strasse 60 CH-2500 Biel-Bienne 6... - Page 2 Fig. 1 Fig. 2 Fig. 3...
-
Page 3: Table Of Contents
Table of contents Introduction ........4 Scope of delivery....... 5 Operator instructions ......6 General safety instructions....8 Intended use ........9 Description of unit ......10 Measuring ........11 Maintenance ........14 Spare parts ........15 10 Technical data ......... 16 11 Decommissioning...... -
Page 4: Introduction
In particular, electrostatic charges occur in areas where highly insulating materials are used. The Static Control Digital enables you to measure such electrostatic charges. Where electrostatic charges are present, targeted counter-measures for their elimination can be considered. -
Page 5: Scope Of Delivery
Scope of delivery Scope of delivery Before using the Static Control Digital for the first time, make sure to check whether your delivery is complete. The following parts are included in the delivery: Carrying case Static Control Digital ... -
Page 6: Operator Instructions
Notes on operating instructions Please keep these operating instructions for later use or future users. They form part of the Static Control Digital. The term “Static Control Digital“ is abbreviated SCD in these operating instructions. General notes regarding your Static Control Digital... - Page 7 Operator instructions Symbols used If this safety information is not observed, severe injuries or death may result. NOTE: Important notes and additional information. Do not dispose of with household garbage.
-
Page 8: General Safety Instructions
SCD. Do not use the SCD in the event of visible damage and suspected electrical defects. Contact HAUG GmbH & Co. KG. in this case (see cover sheet). The SCD housing is not protected against moisture. Moisture and wetness may therefore enter the SCD. -
Page 9: Intended Use
Intended use Intended use Risk of explosion in areas with potentially explosive atmospheres. During the measurement of electrostatic charges using the SCD, ignitable sparks may form. These may ignite gases, dust or similar substances. Do not use the SCD in areas with potentially explosive atmospheres. -
Page 10: Description Of Unit
Description of unit Description of unit You will find images (Figs.) of the SCD on the inside cover page. Front view Spacer pin Display Start button Ground button Fig. 1 Rear view Battery compartment lid Fig. 2 Narrow side view Sensor plate Fig. -
Page 11: Measuring
Measuring Measuring Before measuring Before measuring, check the SCD. Check the function of the display and the state of the battery. Press and hold the start button. The display will show all segments briefly (Fig. 5). Fig. 5 The LOBAT indicator will flash to alert you to a low voltage of the block battery. - Page 12 Measuring Preparing a measurement Plug one end of the grounding cable into the ground socket of the SCD. Fig. 6 Connect the other end of the grounding cable to a protective ground, e.g. by using the pick-off clip. Fig. 7 NOTE: The SCD is calibrated when connected to ground.
- Page 13 Measuring Carrying out a measurement 1. Hold the SCD vertically with its two spacer pins against a grounded surface. 2. Press and hold the start button. The SCD will calibrate itself and show a value of "000" on the display. Fig.
-
Page 14: Maintenance
Maintenance Maintenance Replacing the block battery 1. Open the battery compartment lid at the rear of the SCD. 2. Remove the block battery from the compartment and separate from the connection clip. 3. Connect a new block battery to the connection clip, and insert battery into compartment. -
Page 15: Spare Parts
Spare parts Spare parts Article Ident number Carrying case X - 4568 Spacer pin X - 8308 Grounding cable X - 6350 Pick-off clip X - 6349 9 V monobloc battery X - 0071 Special cleaning fluid 10.7220.000 SRM1 Operating instructions D –... -
Page 16: Technical Data
Technical data Technical data Characteristics and specification Voltage supply 9 V monobloc battery Measuring range ±1999 kV/m Measuring accuracy ±20 % Weight 220 g Ambient conditions The meter must not be used in areas with potentially explosive atmospheres or power plants. -
Page 17: Decommissioning
If you are unable to find an appropriate disposal facility, please feel free to return the electrical unit to HAUG GmbH & Co. KG for environmentally responsible disposal (for address, refer to cover sheet). - Page 18 Decommissioning Disposal of batteries Do not dispose of batteries with your household garbage. You are obliged to dispose of batteries properly. Batteries can be taken to the recycling points in your community or returned to shops selling batteries.
- Page 20 made by D – 0327 – GB 2011-06-10...
