Pyle Pro Professional Series PDWM5000 Owner's Manual

PyleAudio.com
718.535.1800 718.236.2400 (fax)
1600 63rd Street, Brooklyn NY 11204

.........SPECIFICATION.........

System Specitications
1) Frequency Range:.................... VHF 160-280MHz
2) Frequency Stability:........................0.005%
3 ) M o d u l a t i o n m o d e : . . . . . . . . . . . . . . . . . . . . . . . . . . V H F
4) Modulation Deviation:.......................20KHz
5) Audio Frequency Response:...................40Hz-20KHz
6 ) S i g n a l t o N o i s e R a t i o : . . . . . . . . . . . . . . . . . . . . . . . . > 6 0 d B
7) Maximum Sound Pressure Level:..................>100dB
8 ) D i s t o r t i o n : . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 0 . 5 %
9) Operating Range:................80m (under typical conditions)
10) Operation Temperature Range:.................10.~+50.
Transmitter
1) RF Output Power: ................ ........100mW MAX
2) Harmonic Suppression:........................40dB
3 ) A n t e n n a : . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . B u i l t i n
4) Power Requirement:........................9V Battery
5) Nominal Current Drain:..................Approximately 15mA
6 ) B a t t e r y L i f e : . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1 2 h o u r s
Transmitter
1) Receive Mode:....................Crystal Frequency Lock
2) Sensitiity:.........................40dBu(S/N=60dB)
3) SignaltoNoise Ratio:.........................>60dB
4) Audio Output Level:....................0~400mV Max
5) Power Supply:.....................AC110V/220V(.10%)
6) Dimension:.....................WxDxH=485x240x52mm
R
- 4 -
R
PROFESSIONAL SERIES WIRELESS MICROPHONE SYSTEM

...........PREFACE...........

Thank you for buying our excellent wireless microphone series products. Before you use our products, please read this Owner's
manual for vour corrective operation, Please keep this manual in a safety place for your future reference.
VHF series professional wireless microphone systems introducesa number of advanced techniques and components, including
the efficient lowconsumption RF transmission, impact elimination, slowcontrolled output, superiorssensitivity VHF narrowband HF
and MF filters and 15ppm Crystal Frequency Lock etc. Online simulation EDA and strict quality control are applied to ensure
each system withexcellent function.

FEATURES:

Introducing a special ALC circuit to ensure nondistortion;
lntroducing frequency compressingexpanding technique to lower the
noise and enlarge the dynamic range.
Superior squelch and high signaltonoise ratio.
Aimost zero noise output when standby.
Broad frequency response range, super low distortion.
Perfect operation status indications.

SYSTEM SETUP

1) Plug the provided audio cable into the receiver's ALL output connector, and the other end into a mixer or power amplifier system.
Extend the two antennas fully to the vertical position.Switch on the receiver, the POWER ON light will glow indicating the machine
standby. (Better keep distances between the receiver and floor to ensure good receiving signals).
2) Open the battery cover of microphone and install the batteries inside the compartment properly, then replace the cover.
3) Position the transmitter power switch to ON, indicator light will glow (wid position is MUTE ). Now the receiver's corresponding
channel light will also glow, indicating that the receiver has already received the effective signals from the transmitter. Adjust the
volume knobs of the receiver and power amplifier to ensure the suitable volume for the system. Speak with microphone to check the sound.
4) When the transmitter power indicator dardens, it indicates low battery power. Please change with new batterles in time. (Note to not
mix new and old batteries together)
5) When using multiple systems at the same time, it is necessary to use machines of different frequency.
System Tumon Process: Receiver .Mixer or Pre Amplifier .Power Amplifier (Opposite when Tumoff)
OWNER S MANUAL
PDWM5000
Introducing multiple HF and MF narrowband filters to eliminate
interfering signal.
Introducing low power consumption components to ensure the longer
battery life.
Special impact wave eliminating circuit for handheld microphone switches.
Long practical distance. Over 80m in ideal circumstances; practiacal
20m radius incomplex circumstances;
Multiple frequency design. Be able to use two microphones at the
same time withoutmutual interference;
Applicable for medium & small stages, karaoke halls, and home
entertainment etc.
- 1 -
.
