Pyle Pro PDWM94 Operating Instructions

WIRELESS MICROPHONE AND RECEIVER
It is very happy that you have this professional wireless microphone
of good quality which will bring you into a world where you can sing
happily and freely to your heart's content so that you enjoy it
admiringly

HOW DO YOU OPERATE IT?

Screw off the housing, insert a battery (size AA) with the correct polarity and
1.
screw on the housing before inserting the telescopic antenna and set the
switch to the ON position. The pilot lamp is on at this time. Insert another
battery (size AAA) into the receiver with the correct polarity. Set the switch
of receiver to ON position, then the pilot lamp is on that indicate a good
condition. After that, plug the receiver into the input socket for microphone of
amplifier and it is ready for operation.
When you need temporary stop during singing and you don't want the
2.
microphone to pick up any other sound, you may set the switch to the middle
(MIC) position. Now, the lamp is still on but your microphone doesn't transmit
any sound.
Use it as wired microphone:
3.
Take out the battery from the microphone, connect the wire to the
microphone and set the switch to MIC position.

ATTENTIONS:

If acoustic quality and volume are abnormal or receiving distance is shorted,
1.
the batteries in wireless microphone and receiver should be replaced, If
thereafter still not in normal operation, you can carefully trim the frequency of
receiver with a screwdriver to become normal operation.
If your microphone isn't used for a long period, the battery should be taken
2.
out to avoid its deterioration and the damage of components.
If two wireless microphones are used at the same time, you must use them
3.

SPECIFICATIONS:

Microphone sensitivity
Directivity
Frequency response
Out put impedance
Operating voltage
Effective distance

ACCESSORIES:

1 Receiver
www.pyleaudio.com
PDWM94
OPERATING INSTRUCTIONS
-72dB
Undirectional
100 to 10,000Hz
600 ohm
1.5 V DC
15 to 30 m
1 Wireless antenna 1 Wire for wired microphone
