Table of Contents Important Safety Instructions…………………………………….…………….….2 Safety hints…………………………………………………….……………….……5 Introduction……………………………………………….………... …………….…6 Specifications…………………………………………….…………………….…….6 Assembly Pack Check List…...………………………………………………….…7 Assembly Instructions…………………………………………………………….…8 Operation of Your Treadmill…………………………………………………..……11 Programmable Features……………………………………………………………15 General Maintenance…………………………………………………………..…...22 Service Checklist-Diagnosis Guide…………………………………………..……25 Exploded View Diagram…………………………………………... ……………….26 Parts List….………………………………..……………………..…………………..27 XT96-NT17CEGS_1403(XL)A... -
Page 3: Important Safety Instructions
IMPORTANT SAFETY INSTRUCTIONS WARNING - Read all instructions before using this appliance. DANGER - To reduce the risk of electric shock disconnect your treadmill from the electrical outlet prior to cleaning and/or service work. WARNING-To reduce the risk of burns, fire, electric shock, or injury to persons, install the treadmill on a flat level surface with access to a 220~240-volt, 10-amp grounded outlet with only the treadmill plugged into the circuit. -
Page 4: Important Electrical Instructions
IMPORTANT ELECTRICAL INSTRUCTIONS WARNING! NEVER use a ground fault circuit interrupt (GFCI) wall outlet with this treadmill. As with any ap- pliance with a large motor, the GFCI will trip often. Route the power cord away from any moving part of the treadmill including the elevation mechanism and transport wheels. -
Page 5: Important Operation Instructions
IMPORTANT OPERATION INSTRUCTIONS NEVER operate this treadmill without reading and completely understanding the results of any operational change you request from the computer. Understand that changes in speed and incline do not occur immediately. Set your desired speed on the computer console and release the adjustment key. The computer will obey the command gradually. -
Page 6: Safety Hints
Safety hints IMPORTANT: THIS UNIT IS INTENDED FOR HOUSEHOLD USE ONLY SAFETY PRECAUTIONS Thank you for purchasing our product. Even though we go to great efforts to ensure the quality of each product, occasional errors and/or omissions do occur. In any event should you find this product to be defective or missing a part please contact our Customer Service Department. -
Page 7: Introduction
Introduction The treadmill has been designed and constructed to provide trouble free usage and enjoyable exercise. You can greatly improve your understanding and benefits of exercising by carefully reading the instructions given in this manual. Please familiarize yourself with the maintenance advice provided for you. Specifications •... -
Page 8: Assembly Pack Check List
Assembly Pack Check List # 148. Ø8 × 1.5T Ø5/16" × 19 × 1.5T # 88. 5 × 16m/m Split Washer (4pcs) Curved Washer (2pcs) Tapping Screw (4pcs) # 95. M5 × 10m/m # 90. 5/16" × 3/4" # 93. 5/16" × 15m/m Phillips Head Screw (2pcs) Button Head Socket Bolt (4pcs) Button Head Socket Bolt (8pcs) -
Page 9: Assembly Instructions
Assembly Instructions Step 1. Take out the treadmill from the carton and lay it aside on the smooth ground. Step 2. Connect the Computer Cable (Lower) (39) and Computer Cable (Middle) (38). Step3. Insert Right and Left Uprights (4) and (5) into the Frame Base (2) with 4pcs of Speed Nut Clips (132) and use Combination M5 Allen Wrench &... - Page 10 Step4. Use Combination M5 Allen Wrench & Phillips Head Screw Drive (96) to tighten four 5 × 16m/m Tapping Screws (88) and two M5 × 10m/m Phillips Head Screws (95) to secure right and left Frame Base Covers (42 , 43) on the mainframe. Step5.
-
Page 11: Folding Instructions
FOLDING INSTRUCTIONS UNFOLDING Pull locking knob and hold running deck and lower down to the floor. (As shown Figure 1_2.) FOLDING Pull the locking knob with right hand, left hand lift the running deck up to 30cm then two hands lift it until it is locked by the locking knob. -
Page 12: Operation Of Your Treadmill
Operation of Your Treadmill Getting familiar with the control panel ■ Console GETTING STARTED : Power the treadmill on by plugging it into an appropriate wall outlet, then turn on the power switch located at the front of the treadmill below the motor hood. Ensure that the Safety Key is installed, as the treadmill will not power on without it. -
Page 13: Incline Feature
QUICK-START OPERATION 1. Attach the Safety Key to wake the display up (if not already on). 2. Press the Start key to begin belt movement. Then adjust to the desired speed using the keys (console or handgrip). You may also use the rapid speed keys 2 through 10 to adjust the speed. 3. -
Page 14: Pulse Grip Feature
0.4 km Track 0.4km track will be displayed around the dot matrix window.The flashing dot indicates your progress. Once the 0.4km is complete this feature will begin again. The number of completed laps is displayed in the Laps window. Pulse Grip Feature The Pulse (Heart Rate) readout will display your current heart rate in beats per minute during the workout. - Page 15 PRESET PROGRAM PROFILES -14-...
-
Page 16: Programmable Features
PROGRAMMABLE FEATURES To Select and Start a Preset Program 1. Press the desired Program key to select desired program. Press Enter to select the program. The display will prompt you through the programming or you can just press Start to begin the program with default values. -
Page 17: User Programs
User Programs 1. Select User 1 or User 2 via the Program key then press Enter. Note that the dot matrix display portion will have a single row of dots at the bottom (Unless there is a previously stored program). If ther is a program stored under the button that is pressed,it will be retrieved. - Page 18 Fitness Program 1. Press the Fitness key. Press Enter to select the program. The display will prompt you through the programming. 2. If Enter was pressed, the Message Center will now be blinking a value, indicating your Age (default is 35).
-
Page 19: Heart Rate
HEART RATE The heart rate grips are located on the left and right handlebars that are positioned parallel to the walking deck. You can periodically grasp both of these (palms over the steel sensors) until you see your current heart rate. This readout is for reference only and should not be used medically in any way. It is not recommended to use the heart rate grips if the treadmill belt is moving faster than 4 mph.This may cause you to lose your balance. -
Page 20: Rate Of Perceived Exertion
RATE OF PERCEIVED EXERTION Heart rate is important but listening to your body also has a lot of advantages. There are more variables involved in how hard you should workout than just heart rate. Your stress level, physical health, emotional health, temperature, humidity, the time of day, the last time you ate and what you ate, all contribute to the intensity at which you should workout. - Page 21 WEARING THE CHEST STRAP How to wear your wireless chest strap transmitter: Attach the transmitter to the elastic strap using the locking parts. Adjust the strap as tightly as possible as long as the strap is not too tight to remain comfortable. Position the transmitter with the logo centered in the middle of your body facing away from your chest (some people must position the transmitter slightly left of center).
-
Page 22: Heart Rate Program Operation
Heart Rate Program Operation The Heart Rate Programs use your treadmill’s incline system to adjust your heart rate. Increases and decreases in elevation affect heart rate much more efficiently than changes in speed. Additionally, changes in incline keep you in control of the machine’s speed instead of the machine controlling you. Selecting A Heart Rate Program You have the option, during the setup mode, to choose either the Weight Control (HR-1) program or the Cardiovascular (HR-2) program. -
Page 23: General Maintenance
GENERAL MAINTENANCE BELT & DECK Your treadmill uses a very high-efficient low-friction deck. Performance is maximized when the deck is kept as clean as possible. Use a soft,damp cloth,or paper towel,wipe the edge of the belt and the area between the belt edge and the frame. Also reach as far as practical directly under the belt edge. - Page 24 TREAD-BELT TRACKING ADJUSTMENT The treadmill is designed so that the tread-belt remains reasonably centered while in use. It is normal for some belts to drift near one side while in use, depending on a user’s gait and if they favor one leg. But if during use the belt continues to move toward one side, adjustments arenecessary. SETTING TREAD-BELT TRACKING A 6 mm Allen wrench (132)is provided for this adjustment.
- Page 25 Do not lubricate with anything other than XTERRA Fitness approved lubricant. Your treadmill comes with one tube of “Lube” and extra tubes can be ordered directly from XTERRA Fitness or your authorized XTERRA Fitness dealer. You may also use a Lube-n-Walk kit that can be purchased through both aforementioned sellers.
-
Page 26: Service Checklist-Diagnosis Guide
SERVICE CHECKLIST – DIAGNOSIS GUIDE Before contacting your dealer for aid, please review the following information. It may save you both time and expense. This list includes common problems that may not be covered under the treadmill’s warranty. PROBLEM SOLUTION/CAUSE Display does not light 1.Tether cord not in position. -
Page 27: Exploded View Diagram
EXPLODED VIEW DIAGRAM -26-... -
Page 28: Parts List
PARTS LIST Part Number Part Description Qty per unit Main Frame Frame Base Incline Bracket Right Upright Left Upright Console Support Outer Slide Inner Slide Locking Knob Running Deck Running Belt Drive Belt Front Roller W/Pulley Magnet 21~2 Rear Roller Wheel Sleeve Cylinder PVC Handgrip... - Page 29 Part Number Part Description Qty per unit 40~15 Speaker Grill Anchor (Optional) 600m/m_Speaker W/Cable (Optional) 40~16 40~17 0.5W Amplifier Controller (Optional) 40~18 500m/m_Amplifier Cable (Optional) 40~22 500m/m_Sound Board W/Cable (Optional) 40~24 Ø3.0 × 10L_Sheet Metal Screw (Optional) 40~25 Ø3.5 × 12L_Sheet Metal Screw 40~26 FAN Key 40~27...
- Page 30 Part Number Part Description Qty per unit 3/8" × UNC16 × 7.0T_Nyloc Nut 5/16" × UNC18 × 7T_Nyloc Nut M8 × P1.25 × 7.0T_Nyloc Nut 3/8" × UNC16 × 7.0T_Nut Ø3 × 75L_Sheet Metal Screw Ø10 × Ø25 × 2.0T_Flat Washer Ø10 ×...
- Page 31 Part Number Part Description Qty per unit Choke 650m/m_Connecting Cable Of Motor M8 × P1.25 × 12L_Hex Head Bolt M8_Split Washer 21.4 × 25.4m/m_Square End Cap 1000m/m_Connecting Cable (Upper) (Optional) 500m/m_Connecting Cable (Lower) (Optional) Rubber Foot Foot Rail Back Plate Non-Slip Rubber(L) Non-Slip Rubber(R) Ø13m/m_Bolt Cap...
