Maintenance

For your own benefit maintain the S7 SMART well. It will last longer.
Cleaning
Remove the dirt using a moist cloth and a mild detergent.
Make sure that no dirt is collected between the wheels and the
brake shoes.
Dirt might hazard the braking power.
Flushing the S7 SMART by means of a jet cleaning device or a garden
hose from above is recommended. Wipe dry afterwards.
Doability Limited, Unit I7B, Hornbeam Park Oval, Hornbeam Park, Harrogate, HG2 8RB
10
Lubricating the Wire
1. After the cleaning lubricate the braking wire underneath the
frame. Lift the travelling brake handle and apply a few drops of oil on
the wire.
2. Also lubricate the wire inside the spring at the rear wheel.

Fault Tracing

If the S7 SMART pulls to the right or to the left, check that all wheels
rotate smoothly and that the wheel forks turn easily. Check that
wheels and forks are tightened properly. Make sure that no dirt is
collected between the wheel and the brake shoe.
Check that the adjusting button is clicked back into position after
height adjustment of the handles, see page 4.
frame. Check that the spring at the brake arm is not broken.
When braking check that the brake shoe is pressed equally against
both sides of the wheel.
Adjust the wire, see page 7.
