- Page 1 IPCB42500 / IPCB42550 User manual Software IPCB42500 IPCB42550 Version 11/2015 English translation of the original German user manual. Retain for future reference.
- Page 2 This user manual has been produced with the greatest of care. Should you discover any missing information or inaccuracies, please let us know about them. ABUS Security-Center GmbH & Co. KG does not accept any liability for technical and typographical errors, and reserves the right to make changes to the product and user manuals at any time and without prior warning.
- Page 3 Important safety information All guarantee claims are invalid in the event of damage caused by non-compliance with this user manual. We cannot be held liable for resulting damage. We cannot be held liable for material or personal damage caused by improper operation or non-compliance with the safety information.
-
Page 4: Table Of Contents
) ..................... 67 OMEPAGE LOGIN PAGE 4.6 U ..................68 SER ACCOUNTS AND PASSWORDS 4.7 L ABUS VMS/ABUS VMS E ......... 69 INKING UP THE CAMERA WITH XPRESS 4.8 L ABUS NVR/ABUS H DVR ..........69 INKING UP THE CAMERA WITH YBRID 4.9 L... - Page 5 7.5.6.2 F ......................96 IRMWARE ESET 7.5.6.3 L ........................96 OG FILE 7.5.7 E ..........................97 VENTS 7.5.7.1 M ......................97 OTION DETECTION 7.5.7.2 A IPCB42550) ................... 98 LARM INPUT ONLY 7.5.7.3 A IPCB42550) ................98 LARM OUTPUT ONLY 7.5.8 A .......................
-
Page 6: Intended Use
You can download a PDF version of the user manuals in your language at www.abus.com via the product search. -
Page 7: Features And Functions
3. Features and functions DWDR IR, infrared WLAN IPCB42500 √ √ IPCB42550 √ √ √... -
Page 8: Initial Start-Up
4. Initial start-up 4.1 Using the ABUS IP Installer for camera search Install and start up the ABUS IP Installer using the enclosed software CD (or alternatively using the ABUS website www.abus.com, available for each respective product). The IP camera should now appear in the selection list without the relevant IP address for the target network, where appropriate. -
Page 9: Accessing The Network Camera Using A Web Browser
4.2 Accessing the network camera using a web browser Enter the camera IP address into the address bar in the browser (if a different HTTP Port is used in Internet Explorer you must also enter "http://“ before the IP address.) 4.3. - Page 10 Mozilla Firefox A plugin is used to display videos in Mozilla Firefox. You will be asked to confirm the installation directly after entering your username and password (default: master/master or installer/installer). Google Chrome Note relating to Google Chrome (older versions up to Version 42): the video plugin is only supported by the Windows version of the Google Chrome browser.
-
Page 11: Homepage (Login Page)
4.5 Homepage (login page) After entering the IP address in the browser's address bar and opening up the page, the home page will appear in the language set in the Internet Explorer options (Windows setting). Each respective user account (installer, master or user) can set their language individually. For example, the settings pages can be set to English for the "installer"... -
Page 12: User Accounts And Passwords
4.6 User accounts and passwords Overview of the types of user with the username descriptions, the default passwords and corresponding privileges. User types Username Default password Privileges Installer Installer installer Video display on web browser Instant image Local video recording on PC <can be modified by <can be modified by installer>... -
Page 13: Linking Up The Camera With Abus Vms/Abus Vms Express
4.7 Linking up the camera with ABUS VMS/ABUS VMS Express The following information is required to link up the camera with ABUS VMS/ABUS VMS Express: IP address/domain name http port (default 80) rtsp port (default 554, can be changed, is detected automatically) Installer ... -
Page 14: User Menu "User
5. User menu "user" Button/display on screen Function Information bar Live display Help page Log out as user Button/display Function on screen Instant image function This function saves an instant image from the current video stream in JPEG format. The picture is stored in the following folder: (Save location, see local configuration) - Page 15 Video function This function saves a video from the current video stream in AVI format. The video is stored in the following folder: (Save location, see local configuration) Activate switching output This button can be used to manually activate or deactivate the switching output (e.g.
-
Page 16: View And Configuration Menu User "Master
6. View and configuration menu user "master" Button/display Function on screen Instant image function This function saves an instant image from the current video stream in JPEG format (see Local Configuration for save location). Video function This function saves a video from the current video stream in AVI format (see Local Configuration for save location). - Page 17 Full screen mode Switching the video picture on the monitor to full screen mode (you can also do this by double clicking within the video frame). You can exit full screen mode by double clicking within the video frame again or pressing the ESC button.
-
Page 18: Add/Change/Delete Users
6.1 Add/change/delete users Add/edit/delete: Users with the type "User" can be added. The "Master" user can only be modified. It cannot be added. User name: Enter the user names here (max. 32 characters, not allowed: \ : "). Language: Select the language to be displayed for the user here. Use a secure password: In order to become active, the password must meet the following requirements: 8-16 characters, 2x numbers,... -
Page 19: Local Configuration
6.3 Local configuration Protocol: Setting the transmission protocol (default: TCP) Live view performance: Select the priority for display in the browser here (priority on image stream or image quality). Live indicator: Display of all event animations in the live image (e.g. frame for motion detection). -
Page 20: Displaying/Downloading Video From The Internal Memory
6.4 Displaying/downloading video from the internal memory Symbol Explanation Selection of the date when searching for a recording. If data are found on the SD card, they are displayed in the playback bar by record type. First select a date and then click "SEARCH". Stop playback Slow playback (forwards) Fast playback (forwards) - Page 21 Playback volume (if recording contains audio data) Enable digital zoom. Then hold down the left mouse button to draw a rectangle in the video area. The digital zoom is applied to this area. Pressing this button a second time closes the digital zoom mode. Save single frame (save location, see local configuration) Start/stop the video cutting function.
-
Page 22: View And Configuration Menus User "Installer
7. View and configuration menus user "installer" 7.1 Live view The live view display for the installer user is similar to that of the master user. However, the installer user has extended options for settings such as the set up wizard or extended configuration. - Page 23 In the area to the upper left, the general status of the system is represented by a symbol. System is running correctly All parameters such as system temperature and processor usage are fine. All functions in use are working correctly. System is faulty Errors have occurred in the system.
-
Page 24: Setup Wizard
Number of HDDs: display of the number of installed storage media (e.g. microSD card) Number of Alarm Input: number of switching inputs on the camera Number of alarm outputs: number of switching outputs on the camera Memory usage: internal memory status Data throughput: total video and audio bit rate over the network interface (outgoing) CPU usage:... -
Page 25: Advanced Camera Settings
7.5 Advanced camera settings 7.5.1 Video 7.5.1.1 Image Brightness, contrast, saturation, hue: Adjust these values to suit the ambient conditions. Sharpness: set the electronic oversharpening for the image (edge overdraw) Iris mode: choose between manual and automatic iris control, depending on your model. -
Page 26: Privacy Masking
WDR: wide dynamic function for improved display of high contrasts. The WDR level should be reduced if the image displayed is too bright. Wide dynamic level: select the WDR level. A higher level may increase image noise. White balance: you can select between different variants of white balance. Digital Noise reduction: function to reduce noise in the image. -
Page 27: Video Stream
7.5.1.3 Video stream Stream Type: Select the first, second or – if it is available for your camera model – the third video stream for configuration. Video type: Select whether video or video and audio should be transmitted. Resolution: choose the resolution for the video stream. Bitrate type: select the streaming method: Constant bitrate: keeps the bitrate constant at the set value, regardless of the quality. -
Page 28: Network
7.5.2 Network 7.5.2.1 IPv4/IPv6 settings... -
Page 29: Ports
Select NIC: choose whether the LAN or WLAN interface (if available) should be configured. NIC type: selection of the speed for the LAN adapter. DHCP: the IP address, subnet mask, gateway (default router) and address for the DNS server are obtained automatically from a DHCP server. An activated DHCP server must be present in the network in this case. -
Page 30: Ddns
User name: user account identification with the DDNS service provider Password: account password with the DDNS service provider Further information on the "ABUS SERVER" can be found on the help page at the following address: https://www.abus-server.com/faq.html 7.5.2.4 PPPoE The PPPoE protocol makes it possible to connect the camera to a provider modem directly. An additional router is not required. -
Page 31: Snmp
7.5.2.5 SNMP SNMP (Simple Network Management Protocol) The SNMP protocol enables central network management of network components. Enable SNMPv1: enable the SNMPv1 function Enable SNMPv2: enable the SNMPv2 function Write SNMP Community: SNMP Community string for writing Read SNMP Community: SNMP Community string for reading Trap Address: IP address of the TRAP server... -
Page 32: Ftp
7.5.2.7 FTP Server Address: IP address of the FTP server Port: FTP server port User name: user name for the FTP server account Anonymous: anonymous access to the FTP server (server must support this) Password: password for the FTP server account Confirm: Password confirmation Directory Structure:... -
Page 33: Wi-Fi (Only Ipcb42550)
7.5.2.8 Wi-Fi (only IPCB42550) Wi-Fi list: Available Wi-Fi networks are displayed here. Click in a row to select a network. SSID: (Service Set Identifier) Enter the name of the wireless network here. Network mode: Infrastructure Describes a network in which a central instance (wireless access point/router) carries out the coordination and data transmission for all network components. -
Page 34: Upnp
7.5.2.9 UPnP Enable UPnP: For enabling or disabling the UPnP function. Friendly name: assigning a UPnP name, which the camera uses to appear on the network via UPnP. 7.5.2.10 SMTP/Email The SMTP/email function must be configured beforehand, so that the camera is able to send emails if certain events occur. -
Page 35: Nat
Enable SSL: enable if the email server uses SSL or TLS. The SMTP port may have to be changed. Interval/attached image: Choose an image interval for attached images. /Option must be enabled for attached images. Authentication/ User name/ Password: Enable this option if the SMTP email server requires authentication. -
Page 36: Security
7.5.3 Security 7.5.3.1 IP address filter Enable IP address filter: enables the IP address filter function for IPv4 addresses. Only IP addresses are allowed when inputting the addresses (no domain names). IP address filter type: choice between forbidden and allowed addresses. Add/ Modify/ Delete:... -
Page 37: Osd
7.5.4 OSD Display name: superimposes the configurable camera name on the live image. Display date: superimposes the date on the live image. Camera name: enter the camera name here (max. 32 characters). Time format: select a display format (24-hour or 12-hour) for the time. Date format: select a display format for the date. -
Page 38: Date & Time
7.5.5 Date & time Time zone: here, select the time zone in which the camera is located. NTP: tick the box to synchronise the date and time of the camera with an NTP time server. Server address/NTP port: enter the server address or the IP address for the NTP server here. -
Page 39: System
7.5.6 System 7.5.6.1 General Camera name: enter a name here (max. 32 characters). Forbidden characters are: / \ : * ? ' " < > | % Export configuration: exports the entire camera configuration into a file. Import configuration: imports a previously exported configuration of the same camera type. -
Page 40: Firmware/Reset
Firmware/remote upgrade: This function can be used to update the camera's firmware. First, download the current firmware from the ABUS website. The "Search" button can be used to select this file for updating. Press the "Upload" button to start the update. -
Page 41: Events
7.5.7 Events 7.5.7.1 Motion detection Enable motion detection: enables motion detection. Enable dynamic analysis for motion: if enabled, changes to the video image content are displayed graphically in the preview. NOTE: The LIVE INDICATOR function decides whether this should also be displayed in the live image. -
Page 42: Alarm Input (Only Ipcb42550)
7.5.7.2 Alarm input (only IPCB42550) Alarm input: Select the alarm input to be configured here (number depends on camera model). Alarm name: enter the name here. Alarm type: the alarm type determines the idle and triggered statuses. NO: normally open (normal status open) NC: normally closed (normal status closed) 7.5.7.3 Alarm output (only IPCB42550) Alarm output:... -
Page 43: Alarm Manager
7.5.8 Alarm manager Trigger: an alarm rule consists of a trigger, a schedule for applying the rule and an action. Select a trigger for the alarm rule from the list. Only one trigger can be configured for each rule. Schedule: an alarm rule can be enabled in 30 minute intervals. -
Page 44: Recording Schedule
7.5.9.1 Recording schedule Post-record: determine how long a video should be saved for after an event. Overwrite: determine the behaviour if an SD card is full (end recording or replace oldest data with new data = cycle recording function). Video stream: Select the video stream for recording. -
Page 45: Snapshot
7.5.9.4 Snapshot... -
Page 46: Audio
After enabling and configuration, single frames can be saved on the SD card. The single frames can be saved in a time-controlled and/or event-controlled manner. Enable snapshot timing: enables time-controlled storage. Format: available image formats for the single frames: JPEG Resolution: available resolutions for the single frames: 1920x1080 Quality:... -
Page 47: Installer
(without passwords) and the log file to ABUS support. This confirmation must be confirmed before sending. Enable service account: after enabling and password submission, an additional account is enabled, which can be sent out for ABUS support. -
Page 48: Local Configuration
7.5.13 Local configuration Protocol: Setting the transmission protocol (default: TCP) Live view performance: Select the priority for display in the browser here (priority on image stream or image quality). Live indicator: Display of all event animations in the live image (e.g. frame for motion detection). -
Page 49: Maintenance And Cleaning
8. Maintenance and cleaning 8.1 Function test Regularly check the technical safety of the product, e.g. check the housing for damage. If it appears to no longer be possible to operate the product safely, stop using it and secure it to prevent unintentional use.
