PASTA COOKER
Model : AX-SPG & AX-DPG
USER AND TECHNICAL MANUAL
GAS TYPE/PRESSURE
Natural gas
Propane gas
PRODUCTION YEAR:
SERIAL NR:
MVP GROUP CORPORATION 5659 ROYALMOUNT MONTREAL, QC. CANADA H4P 2P9
Tel: (514)737-9701
Fax: (514)342-3854
www.mvpgroupcorp.com
www.axis-equipment.com
PUBLISHED ON :
VERSION .
Advertisement
Table of Contents
Related Manuals for Axis AX-DPG
Summary of Contents for Axis AX-DPG
- Page 1 PASTA COOKER Model : AX-SPG & AX-DPG USER AND TECHNICAL MANUAL GAS TYPE/PRESSURE Natural gas Propane gas PRODUCTION YEAR: SERIAL NR: MVP GROUP CORPORATION 5659 ROYALMOUNT MONTREAL, QC. CANADA H4P 2P9 Tel: (514)737-9701 Fax: (514)342-3854 www.mvpgroupcorp.com www.axis-equipment.com PUBLISHED ON :...
-
Page 2: Table Of Contents
TABLE OF CONTENTS TOPICS PAGE COVER PAGE TABLE OF CONTENTS INTRODUCTION TECHNICAL SPECIFICATIONS (TECHNICAL MANUAL) DIMENSIONS SAMPLE DATA PLATE AND WARNING NOTICES TRANSPORTING AND MOVING 8-9-10 INSTALLATION OF THE APPLIANCE SETTING AIR ADJUSTER AND MINIMUM GAS RATE POSSIBLE FAILURES AND WAYS OF ELIMINATING 13-14-15-16 OPERATION OF THE APPLIANCE (USER MANUAL) CLEAN-UP AND MAINTENANCE... - Page 3 Dear User, Thank you for purchasing our appliance and for your reliance upon our company. Our appliances are used in professional kitchens in 90 countries. Important: Please read this user’s manual in order to achieve the desired performance in line with your expectations and to use your appliance for many years.
-
Page 4: Technical Specifications (Technical Manual)
TECHNICAL SPECIFICATIONS AX-SPG AX-DPG MODEL NAME APPLIED STANDARD ANSI Z83.11a-2004, ANSI Z83.11a-2004, CSA 1.8a-2004; CSA 1.8a-2004; Addenda A:2004, Addenda A:2004, Issue 2002/07/01 Issue 2002/07/01 Btu/h) 61416 122832 Qn (HEAT INPUT H BURNERS CONSUMPTION Natural gas:1,615 m³/h Natural gas:3,23 m³/h Propane:1,482 kg/h... -
Page 5: Dimensions
MAIN DIMENSIONS AND WARNING NOTICES ☞ MODELS AX-SPG & AX-DPG HOT SURFACE SAMPLE LABEL Figure 1 : Main dimensions... -
Page 6: Sample Data Plate And Warning Notices
SAMPLE DATA PLATE & WARNING NOTICES Figure 2: Sample data plate Figure 2: Sample data plate These appliances shall be installed in conformity with the current regulations and used only in a well ventilated location. Consult the instruction before installing and using this appliance... -
Page 7: Transporting And Moving
TRANSPORTING AND MOVING Figure 3: Transportation Figure 3: Transportation CHANGING THE LOCATION; Appliances installed by an authorized technician CANNOT BE MOVED ELSEWHERE, CONNECTION HOSES CANNOT BE EXTENDED OR REPLACED except by an authorized technician. ☞ The appliances can be moved with supplementary vehicles like fork lift ☞... -
Page 8: Installation Of The Appliance
INSTALLATION OF THE APPLIANCE If this appliance is located near any wall, separation, kitchen furniture, decorative coating etc. the distance in between should be at least 8 in. If those are coated with fireproof heat insulating material, the distance should be also at least 5 in. It is strongly recommended that local fire safety protection instructions are observed. - Page 9 INSTALLATION OF THE APPLIANCES ☞ Remove the appliance from the packaging. ☞ Remove all plastic adhesive film from parts before installing the appliance. Clean parts thoroughly to remove all adhesive residue.(Do not use abrasive substances) GAS LEAKAGE CHECKING ☞ Before putting into service, ensure that there are no gas leakages from the gas system of appliance.
- Page 10 INSTALLATION OF THE APPLIANCES gas inlet Figure 4: Gas pressure checking ☞ Nominal power of the device cannot be changed upon customers request. Any modifications made on valves and injectors are very dangerous and, leaves the appliance out of warranty coverage. ☞...
-
Page 11: Setting Air Adjuster And Minimum Gas Rate
SETTING AIR ADJUSTER AND MINIMUM GAS RATE There are adjustable primary air unit and minimum gas rate srews on every gas value THE ADJUSTABLE PART OF THE PRIMARY AIR UNIT , AND MINUMUM GAS ADJUSTER FIXED (B), PLEASE KEEP THIS SETTING DURING OPERATION. -
Page 12: Possible Failures And Ways Of Eliminating
POSSIBLE FAILURES AND WAYS OF ELIMINATING POSSIBLE FAILURES METHOD OF ELIMINATION 1. Check the main valve that may be Appliance valve is open, but no gas is closed. running. 2. Main valve or appliance valve can be damaged, call service. 1. -
Page 13: Operation Of The Appliance (User Manual)
OPERATION OF THE APPLIANCE A. GENERAL Pasta cooker is used to cook pasta, rice, vegetables, and very useful for rethermalization.. 2. Clean the instrument exterior and the water container before use for the first 2. Clean the instrument exterior and the water container before use for the first time using a wet cloth. - Page 14 OPERATION OF THE APPLIANCE 6. After the completion of the cooking cycle,(approx 4-11 min) the baskets are placed above the water level for excess dripping. 7. After dripping, the baskets are taken out of the cooker and pasta is served. 8.
- Page 15 OPERATION OF THE APPLIANCE ☞ AX-SPG/DPG SERIES A- FRESH WATER INPUT VALVE B- FRESH WATER CONTROL KNOB C- SAFETY VALVE CONTROL KNOB D- FLAME MONITOR PANEL E- WATER DISCHARGE CONTROL KNOB FIGURE 6...
- Page 16 OPERATION OF THE APPLIANCE FIGURE 7 FIGURE 8 SAFETY GAS VALVE OFF POSITION SAFETY GAS VALVE ON POSITION FIGURE 9 FIGURE 10 SAFETY GAS VALVE ON - MAX POSITION SAFETY GAS VALVE ON - MIN POSITION FLAME CONTROL SETUP If the pilot flame extinguishes for any reason when the appliances is on, the system will close itself down automatically to avoid dangerous gas accumulation.
-
Page 17: Clean-Up And Maintenance
CLEAN-UP AND MAINTENANCE CLEAN-UP: Before first use of the appliance, and before and after subsequent uses, complete outer surface with a sponge and liquid detergent. Do not use any abrasive CHEMICAL CLEANING AGENT or hydrochloric acid etc. during cleaning. 2. MAINTENANCE (Can be done by authorized service personel) 2. -
Page 18: Summary Of Safety Details
SUMMARY OF SAFETY DETAILS ☞ If the appliance is operated from a propane gas tank, the distance between the appliance and tank must be at least 20 in. ☞ Any kind of flammable solid and liquid material (cloths, alcohol and derivatives, petrochemical products, wooden and plastic materials, cutting blocks, curtains etc.) should never be stored near the appliance. -
Page 19: Terms Of Warranty
MVP, the service work was performed by an authorized MVP service agency; and that this agency installed an original and a genuine AXIS part in agency; and that this agency installed an original and a genuine AXIS part in the machine.
