User Manual

OUTDOOR DOME IP CAMERA
V2.2.1R_1608
1

Advertisement

Table of Contents
loading

Related Manuals for Yudor YUC-HiA6R

Summary of Contents for Yudor YUC-HiA6R

  • Page 1: User Manual

    User Manual OUTDOOR DOME IP CAMERA V2.2.1R_1608...

  • Page 2: Table Of Contents

    OUTDOOR DOME IP CAMERA This is a 1/2.8 " SONY Starvis CMOS sensor Outdoor IP camera with a built-in web server. The user can view real-time video via IE browser. It supports H.264, M-JPEG and MPEG4 video compression which provides smooth and high video quality.

  • Page 3: Warnings, Cautions And Copyright

    i. Warnings, Cautions and Copyright WARNING TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK, DO NOT EXPOSE THIS PRODUCT TO RAIN OR MISTURE. DO NOT INSERT ANY METALLIC OBJECT THROUGH VENTILATION GRILLS. CAUTION CAUTION RISK OF ELECTRIC SHOCK DO NOT OPEN CAUTION：TO REDUCE THE RISK OF ELECTRIC SHOCK.

  • Page 4: Product Specifications

    ii. Product Specifications Main Features:  Maximum Resolution of 1920 x 1080 Pixels with the SONY Starvis CMOS Sensor  High Frame Rate of 60 Frames Per Second (fps)  Scene Analytics Enhanced by Unique Features Such as Face Detection ...
  • Page 5 35.25 ~ 101.52° (H) Angle of View 20.37 ~ 53.13° (V) Color : 0.001 Lux (AGC ON) Sensitivity B / W: 0.0005 Lux (AGC ON) Mechanism IR cut Filter 1 DI/ 1 DO Video output G.711(64K) and G.726(32K,24K) Audio Input : External Mic in Output: External Line out, Support 2-way Power over Ethernet DC 12V Max: 5.28W(IR On), 3.84W(IR Off)
  • Page 6 Full screen monitoring Privacy Mask Yes, 3 different areas Compression format H.264/ M-JPEG Video bitrates adjust CBR, VBR Motion Detection Yes, 3 different areas Triggered action Mail, FTP, Save to SD card, DO, Samba Pre/ Post alarm Yes, configurable Password protection, IP address filtering, HTTPS Security encrypted data transmission, 802.1X port-based authentication for network protection...

  • Page 7: Product Installation

    iii. Product Installation * Monitor Settings Right-Click on the desktop. Select Properties Change color quality to highest (32bit).

  • Page 8: Hardware Installation

    * Hardware Installation 1. Connector Instruction Open the cover to find the cable connectors inside the Camera. Connect the power adaptor first, then connect the IP Camera to PC or network, and set up the network configurations according to the network environment.
  • Page 9 2. Vandal Dome Installation Tips The Unused cable outlet hole must be closed, and the waterproof connector on the used hole must be locked closely. For keeping the IP, when using separate cables for Power and Internet, please use silicon in the cable gland, around the cables, just as shown in the following picture, indicated in yellow color.
  • Page 10 4. Closing the dome cover When you mount the camera housing on the ceiling or wall, please use the screws with the black rubber o-rings. Without the o-ring, the water may seep into the machine. Make sure there are no cables around the screws, and slowly lock the four corners at the same time, applying equal force in every corner.
  • Page 11 5. PoE ( Power Over Ethernet) (Optional) 802.3af, 15.4W PoE Switch is recommended Power over Ethernet (PoE) is a technology that integrates power into a standard LAN infrastructure. It enables power to be provided to a network device, such as an IP phone or a network camera, using the same cable as that used for network connection.

  • Page 12: Ip Assignment

    *IP assignment Open the software IP Scanner to assign the IP address of the IP Camera. Find this software in the Applications folder in the software CD attached to the product’s package. IP Scanner supports two languages: This manual is for English version. There are 3 kinds of IP configuration.
  • Page 13 IP Scanner configuration: IP Scanner will search for all the IP Cameras connected on the LAN. The user can click Search Device to search again. Click one of the IP Cameras listed on the left side. The network configuration of this IP camera will be shown on the right side once you highlight the device with your mouse.
  • Page 14 Different Subnets: IP Camera IP address: 192.168.2.200 PC IP address: 192.168.1.100 To Change the PC IP address: Control PanelNetwork ConnectionsLocal Area Connection PropertiesInternet Protocol (TCP/IP) Properties Make sure your IP Camera and PC are in the same Subnet. If not, change the IP Camera subnet or the PC IP subnet accordingly below.
  • Page 15 11. Enter admin for both Username and Password to gain access.

  • Page 16: Install Activex Control

    *Install ActiveX control 1. For users of IE 6.0 or above: When viewing the camera video for the first time via IE, the browser will ask you to install the ActiveX component. Choose ‘Allow’, Then choose ‘Install’. Start installing the ActiveX component. If the installation fails, please check the security settings in the IE browser.
  • Page 17 Starting from Internet Properties, proceeding step A and B: A. Security  Custom Level  Security Settings  Download unsigned ActiveX controls  Enable or Prompt (recommended). B. Security  Custom Level  Security Settings  Initialize and script ActiveX controls not marked as safe  Enable or Prompt (recommended).
  • Page 18 When popup the following dialogue box, click Yes. 2. You can choose another way: Go to: IE→Tools → Internet Options… → Security Tab → Trusted sites → Add the IP address and click OK. In the site list you can key one single IP address or a LAN address. For example, if you add 192.168.21.*, all the IP address under 21.* on the LAN will be regarded as trusted sites.
  • Page 19 2. To Non-IE Web Browser Users If you use Firefox or Google chrome to access the IP camera but fails to watch the live video, please follow the steps to install necessary tools: (The following pictures are based on chrome.) a.
  • Page 20 In the pop-up window, please tick the first and the third file as the picture below. Click Next to download both Microsoft .NET Framework 4 Client Profile (Web Installer) and Microsoft Visual C++ 2010 Redistributable Package (x64). After finishing downloading, execute the two files respectively to install them. The windows may ask you to reboot the PC when the installation is finished.
  • Page 21 After finishing downloading, execute the files to install ActiveX. Then restart the browser. c. If you execute the steps above but still cannot see live video normally, please try the following solution: Search for the file np_hoem_x.dll in your system disk. For Windows XP users, please go to Start →...
  • Page 22 Start your web browser, and repeat the step 2-b: Download the installation program which does not support IE browser to download and install ActiveX.

  • Page 23: Live Video

    iv. Live Video Start an IE browser, type the IP address of the IP camera in the address field. It will show the following dialogue box. Key-in the user name: admin and password: admin. When the IP Camera is successfully connected it shows the following interface.
  • Page 24 1. Get into the administration page. 2. Video Snapshot. 3. Show the system time, video resolution, and video refreshing rate. 4. Adjust image: 1/2x, 1x, 2x. 5. Streaming source: If the streaming 2 is closed, this function will not be displayed. 6.
  • Page 25 The video format is AVI. Use Microsoft Media Player to play the recorded file. 3. Mute: Turn-off the audio. Click again to turn on it. 4. Full Screen: Full-screen mode. 5. Zoom: Enable the zoom-in and zoom-out functions. First, select Enable digital zoom option within the pop-up dialogue box and then drag and drop the bar to adjust the zoom factors.

  • Page 26: Camera Configuration

    v. Camera Configuration * System Click to get into the administration page. Click to go back to the live video page. System Information Server Information: Set up the camera name, select language, and set up the camera time. Server Name: This is the Camera name. This name will be shown on the IP Scanner.
  • Page 27 Select language: English, Traditional Chinese, and Simplified Chinese can be selected. When it changes, it will show the following dialogue box to confirm the language changing. OSD Setting: Select a position where the date & time stamp / text are shown on the screen. Moreover, click Text Edit for changing the OSD content, including text size and alpha.
  • Page 28 Server time setting: Select between the options NTP, Synchronize with PC’s time, Manual, The date and time remain the same for setting the time. User Management The IP Camera supports three different users: administrator, general, and anonymous user.
  • Page 29 a. Anonymous User Login: Select Yes for allowing everybody to watch live video without username and password. However, if you try to enter the configuration page the camera will ask you to key-in the username and password. Select No for requiring a username and login to access the camera. b.
  • Page 30 III. System update To update the firmware online, click Browse… to select the firmware. Then click Upgrade to proceed. Reboot system: re-start the IP camera Factory default: delete all the settings of this IP camera. Setting Management: The user can download the current settings to PC, or upgrade from previous saved settings.

  • Page 31: Network

    * Network Click to get into the administration page. Click to go back to the live video page. IP Settings IP Assignment The IP Camera supports DHCP and static IP.
  • Page 32 DHCP: The IP Camera will get all the network parameters automatically. Static IP: Type-in the IP address subnet mask, gateway, and DNS. IPv6 Assignment By enabling DHCPv6 you can configure the following IPv6 address settings:...
  • Page 33  Manually setup the IPv6 address: Key-in the Address, Gateway, and DNS.  DHCPv6: If you have a DHCPv6 server, enable it to assign the IPv6 automatically. The assigned IP address will be displayed beside the column.  Automatically generated IPv6 Address: Indicates a virtual IPv6 address generated automatically by the IP camera.
  • Page 34 UPnP This IP camera supports UPnP, if this service is enabled on your computer, the camera will automatically be detected and a new icon will be added to My Network Places. UPnP Port Forwarding：Enable UPnP Port Forwarding for accessing the IP Camera from the Internet; this option allows the IP Camera to open ports on the router automatically so that video streams can be sent out from a LAN.
  • Page 35 Select Add/Remove Windows Components and open Networking Services section Click Details and select UPnP to setup the service. The IP device icon will be added to My Network Places. The user may double click the IP device icon to access IE browser <Approach 2>...
  • Page 36 4. Now the IP device is displayed under the LAN. Double-click the icon to access the camera via web browser. To disable the UPnP, click Hide icons for networked UPnP devices in the tasks column. RTSP setting If you have a media player that supports RTSP protocol, you can use it to receive video streaming from the IP camera.
  • Page 37 RTSP Server: enable or disable Disable means everyone who knows your camera IP Address can link to your camera via RTSP. No username and password are required. Under Basic and Digest authentication mode, the camera asks for a username and password before allows access. The password is transmitted as a clear text under basic mode, which provides a lower level of security than under digest mode.
  • Page 38 Multicast is a bandwidth conservation technology. This function allows several users to share the same packet sent from the IP camera. For using Multicast, appoint here an IP Address and port. TTL means the life time of packet, the larger the value is, the more users can receive the packet.
  • Page 39 Under ONVIF connection, the video will be transmitted by RTSP. Be sure to enable the RTSP server in IP setting, otherwise the IP Camera will not be able to receive the video via ONVIF. 2. Security By selecting Disable, the username and password are not required for accessing the camera via ONVIF.
  • Page 40 The Bonjour function on Safari browser doesn't support HTTPS protocol. If on the camera you select https, the camera will appear on Safari's bookmarks but it cannot be accessed. Take as a reference the following image: LLTD If your PC supports LLTD, enable this function for allowing checking the connection status, properties, and device location (IP address) in the network map.
  • Page 41 can find LLTD through the path: Control Panel → Network and Internet → Network and Sharing Center → Click See full map. Advanced a. Https (Hypertext Transfer Protocol Secure) When the users access cameras via Https protocol, the transmitted information will be encrypted, increasing the security level.
  • Page 42 Select the connection type: • Http: the user can access the camera via the Http path but cannot access it via the Https path. • Https: the user can access the camera via the Https path but cannot access it via the Http path. •...
  • Page 43 • Remove the existing certificate: Before you generate a new certificate, please remove the installed one. Select the Http connection type and click Remove. If a dialog box pops up to ask you to confirm, click Yes. • Created Request: Fill-in the following form and click apply.
  • Page 44 • After generating a certificate request, if you choose to turn it and verified by a trusted third-party, click Content and copy all the request content. • According to the certificate source, there are two ways to install the certificate: If you had sent the certificate request for signing and receiving a signed certificate, click browse and find the certificate file in your computer.
  • Page 45 After finishing the installation, click on Content to call out and check the certificate content. To use Https to access the camera, open your browser, and key-in https:// (IP address)/ in the address bar. Now your data will be transmitted via encrypted communications. The browser will check your certificate status.
  • Page 46 Meaning that certificate is self-signed or signed by a distrusted institution. Click Proceed anyway for continuing to the camera page. b. SNMP (Simple Network Management Protocol) 1. SNMPv1 or SNMPv2: write the name of both Write Community and Read Community. 2.
  • Page 47 Please set what event needs to be detected. • Cold Start: The camera starts up or reboots. • Setting changed: The SNMP settings have been changed. • Network Disconnected: The network connection was broken down (The camera will send trap messages after the network is connected again).
  • Page 48 d. QoS/DSCP(Quality of Server/Differentiated Services Code- point): DSCP specifies a simple mechanism for classifying and managing network traffic; and provide QoS on IP networks. DSCP is a 6-bit in the IP header for packet classification purpose. Please define it for Live Stream, Event / Alarm and Management.
  • Page 49 e. IEEE 802.1x: IEEE 802.1x is an IEEE standard for port-based Network Access Control. It provides an authentication mechanism to a device on a LAN or WLAN. The EAPOL protocol support service identification and optional point to point encryption over the local LAN segment.
  • Page 50 III. PPPoE & DDNS a. PPPoE: Select Enabled to use PPPoE. Key-in the the Username and password for ADSL connection. Send mail after dialed: When connected to the internet, the camera will send a mail to a specific mail account. b.
  • Page 51 Enable this service Key-in the username. IP schedule update. Default: 5 minutes Click Apply. DDNS Status (1) Updating: Information update (2) Idle: Stop service (3) DDNS registration successful, can now log by http://<username>.ddns.camddns.com: Register successfully. (4) Update Failed, the name is already registered: The user name has already been used.
  • Page 52 Server settings There are three server types available: Email, FTP and SAMBA. Select the item for display detailed configuration options. You can configure either one or all of them. To send out the video via mail of FTP, please set up the configuration first.
  • Page 53 Samba Select this option to send the media files via a neighbor network when an event is triggered. Click Apply to save the setting, then use Test button to test the server connection. A message box will tell you OK! if it works, and a test document will be created in the location.

  • Page 54: A/V Settings

    *A / V Settings Click to get into the administration page. Click to go back to the live video page.
  • Page 55 1. Image Setting IMX140 1080p HD 12bit 60fps For security and privacy purposes, there are three areas that can be set up for privacy. Click the Area button first, then drag an area on the above image. Remember to save your settings.
  • Page 56 c. Shutter Time: Choose the location of your camera or fixed shutter time. The shorter the shutter time is the less light the camera receives and the image becomes darker. d. Sense-Up: This function increases the sensitivity of camera to get brighter image at night.
  • Page 57 i. Denoise: This function is able to filter the noise and blur from the image and show a clearer view. It combines 2D and 3D functions. IMX140 1080p WD2 12bit 30fps j. True WDR: Set up the Bright, Dark and Contrast values for the True WDR Note: When you select a number in "Shutter Time", actually the shutter time varies in a range and controlled by camera...
  • Page 58 Option Shutter Time Range (sec.) Outdoor 1/10000 ~ Selected number in "Sense-up" Indoor NTSC: 1/120 ~ Selected number in "Sense-up" PAL: 1/100 ~ Selected number in "Sense-up" 1/30 1/10000 ~ 1/30 1/50 1/10000 ~ 1/50 1/60 1/10000 ~ 1/60 1/100 1/10000 ~ 1/100 1/125 1/10000 ~ 1/125...
  • Page 59 (Max Video Frame Rate for both streaming combined is 30 FPS) i. Streaming 1 & 2 Basic Mode: Note: When selecting IMX140 1080p HD 12bit 60fps, the Streaming 2 will be closed. 1. Resolution: 1920x1080@60fps, 1280x720@60fps, 640x480@60fps,320x240@60fps, 176x144@60fps 2. Quality: There are 5 levels: Best/ High/ Standard/ Medium/ Low The higher the quality is, the bigger the file size is.
  • Page 60 ii. Streaming 1 & 2 Advanced Mode: Note: When selecting IMX140 1080p HD 12bit 60fps, the Streaming 2 will be closed. 1. Resolution: 1920x1080@60fps, 1280x720@60fps, 640x480@60fps, 320x240@60fps, 176x144@60fps 2. Bitrate Control Mode There are CBR﹝Constant Bit Rate﹞and VBR﹝Variable Bit Rate﹞ CBR: 32Kbps~8Mbps (the higher the CBR is, the better the video quality is) VBR: 1(Low) ~10(High) –...
  • Page 61 3. Video Frame Rate (5~30 FPS): The video refreshing rate per second. 4. GOP Size (1, 1/2, 2) X FPS: "Group of Pictures". The higher the GOP is, the better the quality is. 5. Video Format: H.264 or MPEG4 or MJPEG 6.
  • Page 62 3. Audio The IP CAMERA supports 2-way audio. The user can send audio from the IP Camera built-in mic to the remote PC; the user can also send audio from remote PC to IP Camera’s external speaker. a. Audio from IP camera built-in mic to local PC: select “Enable”...

  • Page 63: Event List

    *Event List Click to get into the administration page. Click to go back to the live video page. The IP Camera provides multiple event settings. 1. Event Setting a. Motion Detection...
  • Page 64 To enable motion detection, tick Area 1/2/3. Click Area 1/2/3 in Area Setting, and draw an area on the preview screen. When motion is detected in the area, the word Motion! will be displayed on the live screen. The camera will send video or snapshot to specific mail addresses, trigger the output device, or save video to FTP/ Micro SD card/ Samba.
  • Page 65 b. Tampering Detection When the camera view is covered, moved, hit by strong light, or out of focus, the tampering detection will be triggered, and send snapshot or video to mail/FTP/Samba/SD card, or trigger the external alarm. For example: • Interval: The tampering detecting interval. Take the diagram below as example.
  • Page 66 When enabled, the action selected will be triggered when a face is detected. d. Digital Image Stabilizer The digital image stabilizer reduces shaking images. The most important situations are when there is no enough light to get a fast shutter speed. e.
  • Page 67 • JPEG File (Single File with Interval Setting): Save a single JPEG picture file when the event occurs. f. Record Time Setting When an event occurs, the IP camera can record a video clip or take a snapshot, and then send it via mail/ FTP/ Samba. Select the video recording length before and after the event is detected.
  • Page 68 h. Network IP check: After enabling IP Check, the IP camera can check if the network server is connecting. If the IP camera checking failed, the image will be recorded into the SD card. 2. Schedule a. Schedule: After complete the schedule setup, the camera data will be recorded according to the schedule setup.
  • Page 69 3. I/O Setting a. Input Setting: The IP Cam supports input and output. When the input condition is triggered, it can trigger the relay; send the video to mail addresses/FTP server / SAMBA. • Interval: For example, if you select "10 sec" here, once the motion is detected and action is triggered, it cannot be triggered again within 10 seconds.
  • Page 70 (i) ON/Off Switch: The camera triggers the external device and lasts for 10 seconds. You can turn off the alarm manually by clicking “off” at the right bottom of the live video page. (ii) Time Switch: The camera triggers the external device and lasts for certain time according internal setting, and the user is not allowed to break off the...
  • Page 71 a. Playback Please Insert t h e Micro SD card before use it. Make sure to push the Micro SD card into the slot completely. Click the date listed on this page, and it shows the list of the video. The video format is AVI. Click the video to start Microsoft Media Player to play it.
  • Page 72 Note ： The use of the SD card will s l i g h t l y affect the operation of the IP Camera, such as affecting the frame rate of the video. c. Copy to PC You can insert the Micro SD card to the PC and read the files directly, or use FlashGet instead to download the files from the IP camera.
  • Page 73 (iii) FlashGet will show you the link list, and you can tick the files you want to copy to your PC. Give the directory path in the new download window, and remember to enable "Login to Server": key in the IP Camera username and password. (iv) Click OK to start download.

  • Page 74: Network Configuration

    vi. Network Configuration Configuration 1: Internet Access: ADSL or Cable Modem IP address: One real IP or one dynamic IP Only the IP Camera is connected to the internet For fixed real IP, set up the IP into IP Camera. For dynamic IP, start PPPoE.
  • Page 75 Internet Access: ADSL or Cable Modem IP address: More than one real IP or one dynamic IP IP Camera and PC connect to the internet Device needed: Switch Hub. For fixed real IP, set up the IP into IP Camera and PC. For dynamic IP, start PPPoE.

  • Page 76: I/O Configuration

    vii. I / O Configuration I/O Connection a. Connect the G (GND) & DO pin to the external relay (buzzer) device. b. Connect the G (GND) & DI pin to the external trigger device. When no event occurs, the DO output is 5V (DO and GND are disconnected).
  • Page 77 If you select N.O on Input sensor setting, when the switch contacts are opened, the camera input alarm will be triggered and will execute the action user has set, for example, send a snapshot to E-mail address. If you select N.C in Input sensor setting, when the switch contacts are closed, the camera input alarm will be triggered and will execute the action user has set, for example, send a snapshot to E-mail address.
  • Page 78 I/O Setup a. Click I/O Setting from the system setup page via IE, and check Out1 to enable I/O signal. b. Output Setting After the external input and output hardware is installed, you can use the Relay Out bottom on the live video page to test if DO / Relay Out works.
  • Page 79 (ii) Time Switch mode: Click Pulse, the camera will trigger the external output device for several seconds; the duration length is according to the interval setting in Output Setting.

  • Page 80: Factory Default

    viii. Factory Default If you forget your password, please follow the steps to set back the IP Camera to its default value. • Remove the power and Ethernet cable. Press and hold the button as shown in the picture below. •...

  • Page 81: Universal Password

    ix. Universal Password If you forgot the password of your IP camera, you can reset the camera to factory default, or follow the procedure below to generate a universal password. Note: Universal password will be valid only when you enable the function in User Management.
  • Page 82 2. Locate the .html file named Universal Password_V1.1 in the Universal Password from the Applications folders in CD-ROM. Open it with a web browser. 3. The camera IP address and MAC address will be displayed automatically both columns. Address After clicking on encoder, a set of username and password will appear. The universal username and password are generated from the IP address and MAC address you key-in, so if you change the camera IP address the universal password changes, too.
  • Page 83 5. Now you can login as administrator. Turn to User Management page. The use of universal password does not affect the previous user setting, so the administrator account password does not change until you edit it. Please click Edit to give a new administrator password.

  • Page 84: Package Contents

    x. Package Contents IP Camera Adaptor Quick Installation Guide Hex Wrench Star Wrench Screws x4 O-ring x4 Wall Plug x4 • The CD includes user manual and software tools...

  • Page 85: Micro Sd Card Compatibility(Optional)

    xi. Micro SD Card Compatibility(Optional) The following are the recommended Micro SD Cards: SDHC class4 16GB SDHC class4 32GB class4 16GB class4 32GB SDHC class6 SDHC class6 SDHC class6 16GB Transcend class6 class6 class6 16GB SDHC class10 SDHC class10 SDHC class10 16GB SDHC...
