- Page 1 OWNER’S MANUAL DIGITAL AUDIO OUT MULTI-SUBTITLE LANGUAGES FUNCTION ELECTRONIC SHOCKPROOF (ESP) FUNCTION A/V INPUT FM MODULATOR TV TUNER REMOTE CONTROL...
-
Page 2: Table Of Contents
CONTENTS Page Contents Safety Information Installation Electric Connection Operation Using The Remote Control General Operation CD/MP3 Operation DVD/VCD Operation Data Disc Play Operation Memory Card Play Operation USB Device Operation AV In Operation FM Modulator Operation TV Operation Additional Information Setup System Setup Language Setup... -
Page 3: Safety Information
Safety Information CAUTION: This mobile DVD player is a class 1 laser product. However this mobile DVD player uses a visible/invisible laser beam which could cause hazardous radiation exposure if directed. Be sure to operate the mobile DVD player correctly as instructed. -
Page 4: Installation
Label side Do not bend Wipe the disc from center toward the outside edge Preparing New Discs with Rough Spots A new disc may have rough edges on its inside and outside edges. If a disc with rough edges is used, the proper setting will not be performed and the player will not play the disc. - Page 5 The unit is designed for home-use and car-use. When installed on the car, please follow the installation instruction below. Notes: 1. First remove the two screws that lock the DVD mechanism, then attach the brackets on both sides of unit with screws (m4X5), last install the unit with screws (m5X25).
-
Page 6: Electric Connection
IR Sensor If you need to mount the DVD player in a location which is inaccessible, or where the line-of- sight between the remote control and the face of the player is interrupted, connect the remote sensor as shown in the diagram above. -
Page 7: Operation
OPERATION LOCATION AND FUNCTION OF KEYS Front panel Remote Control User’s Manual - page 6... - Page 8 POWER Press it to turn the unit on/off. Pause playback a disc, press it again to resume playback. 3 MODE Change between DVD, TV and AV mode. Press the button to skip back one track. Press the button to skip to the next track. 6.
-
Page 9: Using The Remote Control
USING THE REMOTE CONTROL Preparing and Using The Remote Control * Before using the remote control, please take the transparent insulator strip off the bottom of remote control. * Point the remote control at the remote sensor (11) from no more than 6 feet away. -
Page 10: General Operation
GENERAL OPERATION Initial System Start-Up Be sure to press the RESET When using the unit for the first time, after all connections are completed correctly. 1. Turn off the unit power. 2. Press RESET with a ballpoint pen or similar pointed object. Turning Power On and Off Press button (1) or insert a disc to... -
Page 11: Cd/Mp3 Operation
CD/MP3 Operation Playback Insert a disc with the label side facing up. The disc will be drawn into the player automatically. The information for the current disc will be shown on the screen . For CD: 3 For MP3 Press ◄... -
Page 12: Dvd/Vcd Operation
Note: REP 1: Only a track (file) is played repeatedly. REP DIR: Only tracks (files) in a folder are repeatedly playing. REP ALL: An entire disc is played repeatedly. REP OFF: The mode returns to normal playback. - Paragraph Repeat Play: A-B repeat allows a selected passage to be repeat continuously. - Page 13 Fast-Forward / Fast-Reverse 1. Fast-forward Press button (28) during playback. Each time the button is pressed, the speed of fast-forward increases as follows: Æ Æ FORWARD 2X In fast-forward mode, press to return to normal playback. 2. Fast-Reverse Press button (29) during playback. Each time the button is pressed, the speed of fast-reverse increases as follows:...
- Page 14 2. Waiting for a moment for the player locate the track. Playback starts from the selected chapter or track. This function is only available for discs on which chapter numbers are recorded. Playing In Random Order Press button (33) to switch the random mode on/off.
- Page 15 Press the SUB-T button (23) during playback. The following information will be shown on the screen. Each time you press the button, the subtitle cycles between the different languages recorded on the disc. Notes: - Not all discs will allow changing the subtitle during playback.
-
Page 16: Data Disc Play Operation
DVD players and discs all have “REGION CODES”. If the region code number on the DVD disc does not correspond to the region number of this DVD player, the unit cannot play the disc. - When I insert a DVD disc, there is a... -
Page 17: Memory Card Play Operation
(10). Using the SD/MMC card: When you insert a SD/MMC card into the Memory card slot (10), the DVD player will read the SD/MMC card automatically. The unit gives first priority to the card in the slot. If you insert a disc into the disc slot (7) while reading the SD/MMC card, the unit will play the disc. -
Page 18: Tv Operation
87.7-88.9MHz (adjustment unit is 0.2 MHz/step). 3) To tune radio to the corresponding frequency, you can listen to the audio of the DVD player by radio equipment. TV Operation Press MODE to switch to TV mode. In TV mode, the function of the buttons served in DVD mode is locked. -
Page 19: System Setup
About MP3 What is MP3? MP3, whose official name is “MPEG-1 Audio Layer 3,” is a compression standard prescribed by the ISO, the International standardization organization and MPEG which is a joint activity institution of the IEC. MP3 files contain compressed audio data. MP3 encoding is capable of compressing audio data at extremely high ratios, reducing the size of music files to as much... -
Page 20: Screen Saver
You can either choose AUTO SELECT, which will sense the type of monitor attached to the output and select NTSC or PAL as needed. If you know the type of monitor, you should choose the type in this menu rather than letting AUTO SELECT do it for you. -
Page 21: Language Setup
EXIT SETUP There are many choices for the menu, DVD and subtitle languages. You set the languages for the DVD player in different menus than the languages for playback and subtitling on the discs. Of course, options vary from disc to disc so some settings may not be available. -
Page 22: Specifications
Specification 1. Supply voltage: Power Supply Requirements 12V DC (11~15V), test voltage 14.4V, negative ground Current consumption: Less than 2 A 2. Signal system: Compositive video 1.0 + - 0.2Vp-p 75 3. Discs played: (1) DVD-VIDEO disc] ( 2 ) C o m p a c t d i s c ( C D - D A / C D - R / C D - RW/MP3) (3) VIDEO CD 4. - Page 23 No Sound Check the audio connections. The Player Does Not Respond To the Remote Control Aim the remote control directly at the sensor on the front of the player. Remove any obstacles which may interfere with the signal path. Inspect or replace the remote control battery.
