Zmachine Insight & Insight+ Specifications
The Zmachine is a Class II, type BF, internally powered, medical device and is rated for
continuous operation.
Input Characteristics
Type
Coupling
Voltage (non-distorted)
Voltage (maximum)
Highpass Filter Cutoff
Lowpass Filter Cutoff
Impedance
Analog-to-Digital Conversion
Sampling frequency
Sampling resolution
Linearity
Architecture
Battery
Nominal Voltage
Chemistry / Cell type
Capacity
Runtime
Charge time
Current Consumption (Nominal)
Running
Charging
Sleeping
Data Storage
Type
Capacity
Data capacity
Mechanical
Length
Width
Height
Weight
Enclosure material
Window material
Standards
Electrical Safety
Electromagnetics
FCC
Troubleshooting and Specifications
Fully differential
AC
±500 μV
±40 V
0.5 Hz
380 Hz
10GΩ || 800pF
2.5 kHz
16 bit
± 1.5 LSB
SAR
3.7 VDC
Lithium Ion / Secondary
900 mAh @ C/5 Rate @ 23 degC (standard)
1800mAh @ C/5 Rate @ 23 degC (extended)
12-18.5 hrs (standard battery)
24-29.5 hrs (extended battery)
≤ 5 Hr (standard battery)
≤ 8 Hr (extended battery)
~70 mADC
~600 mADC
≤ 0.5 µADC
microSDHC
4 GB (Standard)
200 Hr
116 mm
68 mm
21 mm
102 g (standard battery)
122 g (extended battery)
ABS Plastic
Lexan
IEC/UL 60601-1
IEC/UL 60601-1-2
47 CFR 15, Subpart B
