Operation manual
Daikin room air conditioner
CTXA15A2V1BW
FTXA20A2V1BW
FTXA25A2V1BW
FTXA35A2V1BW
FTXA42A2V1BW
FTXA50A2V1BW
CTXA15A2V1BS
FTXA20A2V1BS
FTXA25A2V1BS
FTXA35A2V1BS
FTXA42A2V1BS
FTXA50A2V1BS
CTXA15A2V1BT
FTXA20A2V1BT
FTXA25A2V1BT
FTXA35A2V1BT
Operation manual
FTXA42A2V1BT
English
Daikin room air conditioner
FTXA50A2V1BT
Advertisement
Table of Contents
Related Manuals for Daikin CTXA15A2V1BW
Summary of Contents for Daikin CTXA15A2V1BW
-
Page 1: Operation Manual
Operation manual Daikin room air conditioner CTXA15A2V1BW FTXA20A2V1BW FTXA25A2V1BW FTXA35A2V1BW FTXA42A2V1BW FTXA50A2V1BW CTXA15A2V1BS FTXA20A2V1BS FTXA25A2V1BS FTXA35A2V1BS FTXA42A2V1BS FTXA50A2V1BS CTXA15A2V1BT FTXA20A2V1BT FTXA25A2V1BT FTXA35A2V1BT Operation manual FTXA42A2V1BT English Daikin room air conditioner FTXA50A2V1BT... -
Page 2: Table Of Contents
▪ Detailed step-by-step instructions and background information 4.7.1 Precautions when using the wireless adapter..... 12 for basic and advanced usage 4.7.2 To install the Daikin Online Controller application ..12 ▪ Format: Digital files on http://www.daikineurope.com/support- 4.7.3 To set the wireless connection........12... -
Page 3: Indoor Unit
▪ Temperature setting = 25°C (hold for 2 seconds) to open the front panel when you clean the air filters. See "6.4 To open the front ▪ Airflow rate = Automatic panel" on page 15. (C)(F)TXA15~50A2V1B(W)(S)(T) Operation manual Daikin room air conditioner 3P485919-7C – 2017.12... -
Page 4: Status: User Interface Lcd
2 Insert both batteries at once. 3 Put back the front cover. Streamer is active ON timer is active OFF timer is active Weekly timer is active Day of the week Operation manual (C)(F)TXA15~50A2V1B(W)(S)(T) Daikin room air conditioner 3P485919-7C – 2017.12... -
Page 5: Clock
Result: Setting is complete. blinks. 3 Press to select the menu. Result: blinks. Brightness of the indoor unit display Adjust the brightness of the indoor unit display as desired, or turn OFF the display. (C)(F)TXA15~50A2V1B(W)(S)(T) Operation manual Daikin room air conditioner 3P485919-7C – 2017.12... -
Page 6: Operation
To adjust the airflow direction (swing or Airflow fixed position). ▪ Outside temperature. The system's cooling or heating effect direction decreases when the outside temperature is too high or too low. Operation manual (C)(F)TXA15~50A2V1B(W)(S)(T) Daikin room air conditioner 3P485919-7C – 2017.12... -
Page 7: To Start/Stop Operation And To Set The Temperature
To use 3-D airflow direction 1 Press Result: appear on the LCD. The flaps (horizontal blades) and louvers (vertical blades) will begin to swing. (C)(F)TXA15~50A2V1B(W)(S)(T) Operation manual Daikin room air conditioner 3P485919-7C – 2017.12... -
Page 8: Comfort Airflow And Intelligent Eye Operation
Note: If there are people close to the front of the indoor unit or there are too many people, use both operations at the same time. 2 Press to change the menu screen. Result: The menu appears on the display. Operation manual (C)(F)TXA15~50A2V1B(W)(S)(T) Daikin room air conditioner 3P485919-7C – 2017.12... -
Page 9: Powerful Operation
Example: At night. Timer functions are useful for automatically switching the air conditioner on/off at night or in the morning. You can also use OFF timer and ON timer in combination. (C)(F)TXA15~50A2V1B(W)(S)(T) Operation manual Daikin room air conditioner 3P485919-7C – 2017.12... -
Page 10: To Start/Stop Off Timer Operation
LCD. The timer lamp lights up. INFORMATION Each time is pressed, the time setting advances by 10 minutes. Holding the button down will change the setting rapidly. Operation manual (C)(F)TXA15~50A2V1B(W)(S)(T) Daikin room air conditioner 3P485919-7C – 2017.12... -
Page 11: To Set Weekly Timer Operation
Note: To change the reservation setting, refer to "4.6.1 To set Note: The set temperature is only displayed when the mode setting Weekly timer operation" on page 11. is on. (C)(F)TXA15~50A2V1B(W)(S)(T) Operation manual Daikin room air conditioner 3P485919-7C – 2017.12... -
Page 12: To Deactivate And Reactivate Weekly Timer Operation
4 Operation ▪ Installed free Daikin Online Controller application 3 Press to exit the confirmation mode. Note: If needed, the SSID number and the KEY are located on the 4.6.4 To deactivate and reactivate Weekly timer unit or can be found in the accessory bag. - Page 13 ▪ the user interface, Result: is blinking. ▪ the wireless adapter ON/OFF button on the unit. 4 Open the Daikin Online Controller application and follow the steps on the screen. To use the wireless adapter ON/OFF switch Result: The timer LED is blinking.
-
Page 14: Energy Saving And Optimum Operation
▪ Be careful NOT to cool or heat too much. To save energy, keep the temperature setting at a moderate level. Operation manual (C)(F)TXA15~50A2V1B(W)(S)(T) Daikin room air conditioner 3P485919-7C – 2017.12... -
Page 15: To Clean The Indoor Unit And User Interface
To order titanium apatite deodorizing filter or silver particle filters, contact your dealer. To clean the air filters 1 Push the tab at the centre of each air filter, then pull it down. 2 Pull out the air filters. (C)(F)TXA15~50A2V1B(W)(S)(T) Operation manual Daikin room air conditioner 3P485919-7C – 2017.12... -
Page 16: To Clean The Titanium Apatite Deodorizing Filter And The Silver Particle Filter (Ag-Ion Filter)
1 Remove the dust from the filter with a vacuum cleaner. 2 Soak the filter for 10 to 15 minutes in warm water. Do NOT remove the filter from frame. Operation manual (C)(F)TXA15~50A2V1B(W)(S)(T) Daikin room air conditioner 3P485919-7C – 2017.12... -
Page 17: To Take Following Items Into Account Before A Long Idle Period
In certain operating conditions the inside of the unit may get dirty after several seasons of use. This results in poor performance. Troubleshooting If one of the following malfunctions occur, take the measures shown below and contact your dealer. (C)(F)TXA15~50A2V1B(W)(S)(T) Operation manual Daikin room air conditioner 3P485919-7C – 2017.12... -
Page 18: Symptoms That Are Not System Malfunctions
The unit can absorb the smell of rooms, furniture, cigarettes, etc., Contact your dealer. and then emit it again. The user interface Replace the batteries of the user interface. display is blank. Operation manual (C)(F)TXA15~50A2V1B(W)(S)(T) Daikin room air conditioner 3P485919-7C – 2017.12... -
Page 19: Symptom: The Outdoor Fan Rotates While The Air Conditioner Is Not In Operation
Freeze-up protection or high-pressure control default" on page 13. Fan motor (DC motor) abnormality Streamer unit error Indoor heat exchanger thermistor abnormality Opening or closing front panel error Room temperature thermistor abnormality Humidity sensor error (C)(F)TXA15~50A2V1B(W)(S)(T) Operation manual Daikin room air conditioner 3P485919-7C – 2017.12... - Page 20 MUST comply with applicable legislation. Units MUST be treated at a specialised treatment facility for reuse, recycling and recovery. Operation manual (C)(F)TXA15~50A2V1B(W)(S)(T) Daikin room air conditioner 3P485919-7C – 2017.12...
- Page 24 3P485919-7C 2017.12...
