Summary of Contents for Acer DT653
-
Page 1: User Manual
Public Information Display User Manual DT653... -
Page 3: Table Of Contents
Table of Contents Declaration of Conformity ..............3 FCC DECLARATION OF CONFORMITY .............. 3 CE DECLARATION OF CONFORMITY ..............4 Safety Information .................5 Warnings ........................ 5 Safety Information .................7 SAFETY PRECAUTIONS ..................7 RECOMMENDED USE ..................8 Package Contents ..................9 Features of Your Display ..............10 IMAGE FEATURES .................... - Page 4 Connecting Devices to Your Display ..........22 ANALOG CONNECTIONS ................... 23 DIGITAL CONNECTIONS ..................23 USING THE TOUCHSCREEN ................25 PICTURE ASPECT RATIO ................... 25 OSD (On-Screen-Display) Controls ........... 26 BASIC OPERATIONS OF THE OSD SCREEN ........... 27 Troubleshooting .................. 35 Product Specifications ................
-
Page 5: Declaration Of Conformity
Declaration of Conformity FCC DECLARATION OF CONFORMITY This device complies with Part 15 of FCC Rules. Operation is subject to the following two conditions. (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. FCC Information 1. -
Page 6: Ce Declaration Of Conformity
CE DECLARATION OF CONFORMITY Hereby, Acer Inc., declares that this LCD monitor is in compliance with the essential requirements and other relevant provisions of EMC Directive 2014/30/EU, Low Voltage Directive 2014/35/EU, and RoHS Directive 2011/65/EU and Directive 2009/125/EC with regard to establishing a framework for the setting of eco-design requirements for energy-related product. -
Page 7: Safety Information
Safety Information Warnings This symbol warns user that uninsulated voltage within the unit may have sufficient magnitude to cause electric shock. Therefore, it is dangerous to make any kind of contact with any part inside this unit. This symbol alerts the user that important literature concerning the operation and maintenance of this unit has been included. - Page 8 North America European China Japan (USA/Canada/ Union Taiwan) Plug Shape Voltage (110 in Taiwan) When operating a display which requires an AC 125-240V power supply, make sure to use a power supply cord that matches the power supply voltage of the AC power outlet being used. NOTE This product can only be serviced in the country where it was purchased.
-
Page 9: Safety Information
Safety Information SAFETY PRECAUTIONS Please note the following when setting up and using the display: • DO NOT OPEN THE DISPLAY. There are no user serviceable parts inside and opening or removing covers may expose you to dangerous shock hazards or other risks. Refer all servicing to qualified service personnel. -
Page 10: Recommended Use
RECOMMENDED USE • For optimum performance, allow 20 minutes for warm-up. • Position the display at a 90° angle to windows and other light sources to minimize glare and reflections. • Clean the display surface with a lint-free, non-abrasive cloth. Avoid using any cleaning solution or glass cleaner. -
Page 11: Package Contents
Package Contents Your new display should include the following items: Power cord Darwin Large Format Display User Manual LCD monitor DT653 Model Number: S645HF64 V0 IWB65 Setup Manual Wireless Remote Control Remote Control Batteries NOTE For models shipped with touchscreen functionality, an additional A-type USB connector will be attached to the left side of the display. -
Page 12: Features Of Your Display
Features of Your Display IMAGE FEATURES Advanced Color Control: Adjust the colors of your screen image and customize the color accuracy of your display to a wide variety of standards. Six-Axis Color Control: Utilizes six-axis color control with the sRGB color control. Six-axis color control allows color adjustments via six axes (R, G, B, C, M and Y) rather than through the typical three axes (R, G and B). -
Page 13: Installation Of Your Display
Installation of Your Display WARNING • For proper installation it is strongly recommended to use a trained, authorized technician. Failure to follow standard mounting procedures could result in damage to the equipment or injury to the user or installer. • Product warranty does not cover damage caused by improper installation, remodelling, or natural disasters. -
Page 14: Mounting Location
Mounting Location It is important to install the display in a location that allows adequate ventilation around the display, so that heat can properly dissipate away from the display and its mounting accessories. If installing the display onto a ceiling or wall with a mounting bracket, then the ceiling and wall must be strong enough to support the display and its mounting accessories. -
Page 15: Mounting Equipment
Mounting Equipment CAUTION This display cannot be used or installed without a support stand or a mounting support accessory. The display is designed for use with the VESA mounting system. When using mounting accessories other than those that are approved by the dealer, they must comply with the VESA- compatible (FDMlv1) mounting method. - Page 16 400.00mm 3. Make sure there is no gap between the display and the bracket. 4. To ensure safe installation, use two or more brackets to mount the display. Mount the display to at least two points on the installation location. NOTE •...
-
Page 17: Display Components
Display Components CONTROL PANEL – LOCATION & BUTTONS MENU button Turns the OSD menu on/off. SOURCE button Toggles between the input sources of your display: [HDMI1], [HDMI2], [VGA], [USB] and [DVI-D]). Also acts as an INPUT button within the OSD menu. Volume Up button (+) In the OSD menu, acts as the LEFT button to adjust or increase the function. -
Page 18: Ports & Connectors
PORTS & CONNECTORS 2 3 4 5 Remote control sensor Receives the signal from the remote control. See also and Power Indicator “USING THE REMOTE CONTROL” on page 18. When the display is in active use the power indicator illuminates GREEN. When the display is powered off it illuminates RED. -
Page 19: Remote Control
REMOTE CONTROL POWER Switches the power on/off. button SOUND Selects the sound mode options buttons STANDARD, DYNAMIC and CUSTOM. PICTURE Selects the picture mode options button from STANDARD, DYNAMIC, CINEMA and CUSTOM. INFO Displays the current screen button resolution and refresh rate. VOLUME Increases the audio output levels. -
Page 20: Using The Remote Control
USING THE REMOTE CONTROL Setting Up the Infrared Remote Control Sensor Before using the infrared remote control, the display’s remote control sensor must be positioned. The remote control sensor is the small black box located on the back of left of the display. Press the small button near the base of the remote control sensor, and slide the sensor away from the display until it locks in place. -
Page 21: Preparing Your Display For Use
Preparing Your Display for Use 1. Install in the desired location. CAUTION MOVING OR INSTALLING THE DISPLAY MUST BE DONE BY TWO OR MORE PEOPLE. Failure to follow this caution may result in injury if the display falls. CAUTION Do not mount or operate the display upside down, face up or face down. IMPORTANT When setting the display down to install the wall mount, place it face down on a flat and stable surface covered by a protective sheet or cloth and a table cushion. -
Page 22: Operating Your Display
Operating Your Display POWER ON AND OFF MODES 1. Turn the AC switch located at the bottom of the display on. AC SWITCH 2. To power up the display, select either the Power button [ ] on the control panel (A) or the Power button [ ] on the remote control (B). -
Page 23: Led Power Indicator
LED POWER INDICATOR Indicator Condition LED (RED) LED (GREEN) Off (=Standby) Power Saving Schedule Standby BLINK Over safe temperature BLINK USB auto upgrade (use in BLINK BLINK factory) Over alarm temperature BLINK Operating Your Display | 21... -
Page 24: Connecting Devices To Your Display
Connecting Devices to Your Display Before connecting any equipment: • First turn off the power of all the attached equipment and then make connections to the display. • Refer to the user manual included with each separate piece of equipment. NOTE Do not connect/disconnect cables when turning on the display or when turning on other external equipment as this may result in image loss. -
Page 25: Analog Connections
Input signal Connecting Connecting Connecting audio Input button on name on equipment video terminal terminal remote control source menu HDMI 1 HDMI 1 HDMI 1 INPUT > HDMI 1 HDMI 2 HDMI 2 HDMI 2 INPUT > HDMI 2 HDMI 3 HDMI 3 HDMI 3 INPUT >... -
Page 26: Connecting A Personal Computer
NOTE Some display cards or drivers may not display an image correctly. NOTE The image may be reduced and may not be displayed full screen at a resolution of 1920 x 1080. Check the setting of the device’s video card. Connecting a Personal Computer: Some display cards with a pixel clock over 162MHz may not display an image correctly. -
Page 27: Using The Touchscreen
USING THE TOUCHSCREEN The display supports touchscreen functionality with an external A-type USB connector located at the left side of the panel. To use the touchscreen function: 1. Turn off the power of the display. 2. Connect the display’s A-type USB connector to the USB port of an external computer. 3. -
Page 28: Osd (On-Screen-Display) Controls
OSD (On-Screen-Display) Controls For this display, an OSD (On-Screen Display) function is used to allow you to easily adjust settings. You can use the OSD function to control the menu displayed on the screen and to adjust the picture, sound and other settings of the display. To access the OSD Main Menu, press the [MENU] button on the remote control or the control panel. -
Page 29: Basic Operations Of The Osd Screen
BASIC OPERATIONS OF THE OSD SCREEN Make sure that the display is powered on and that the LED power indicator is green. Step Wireless Remote Control Keypad Operation Opening and Navigating the Press the [MENU] button to Press the [MENU] button to OSD Main Menu display the OSD screen. - Page 30 Step Wireless Remote Control Keypad Operation Opening and Navigating Press the up ()/down () Press the up ()/down () OSD Sub-Menus button to navigate to an button to navigate to an item in the sub menu. item in the sub menu. Making Selections in the Press the [OK] button to Press the [SOURCE] button...
- Page 31 Step Wireless Remote Control Keypad Operation Adjusting settings in the Press the left ()/right () Press the plus (+)/minus (–) OSD sub-menus button to adjust a setting or button to select a setting press the [OK] button to and press the [SOURCE] display further features of button to determine the the setting.
- Page 32 PICTURE P i c t u r e P i c t u r e M o d e D y n a m i c B a c k l i g h t 1 0 0 C o l o r Te m p e r a t u r e 1 1 5 0 0 G a m m a 2 .
- Page 33 SOUND S o u n d Sound Mode S t a n d a r d S u r r o u n d S o u n d O f f S p e a k e r I n t e r n a l A u d i o S o u r c e H D M I 1 R e s e t A u d i o S e t t i n g...
- Page 34 SETUP S e t u p S c h e d u l e r O ff S i g n a l C h e c k P r i o r i t y C E C C o n t r o l S l e e p Ti m e r O ff P o w e r S a v e...
-
Page 35: Initial Setting
INITIAL SETTING I n i t i a l S e t t i n g M e n u L a n g u a g e E n g l i s h Ti m e F o r m a t 1 2 - h o u r C l o c k 2 0 1 7 / 1 / 1 1 2 : 0 0 P M... -
Page 36: System Information
SYSTEM INFORMATION S y s t e m I n f o r m a t i o n M o d e l N a m e B H 2 8 1 S W Ve r s i o n 0 . -
Page 37: Troubleshooting
Troubleshooting No picture • The signal cable should be completely connected to the display card/computer. • The display card should be completely seated in its slot. • Check the main Power Switch, it should be in the ON position. • Power Switch and computer power switch should be in the ON position. •... - Page 38 LED on display is not lit (no green or red color can be seen) • Power Switch should be in the ON position and power cord should be connected. • Check the main Power Switch, it should be in the ON position. •...
- Page 39 Interference in TV • Check components for shielding, move away from monitor if necessary. The touch panel does not respond • Check the input signal setting. • Make sure the USB cable is connected properly. • When using touch function at the display edge, there may be a slight gap between touch position on the screen and where you touched.
-
Page 40: Product Specifications
Product Specifications LCD Module 65" V / 1639.0 mm diagonal Pixel Pitch 0.744 mm Resolution 1920 x 1080 Color Over 1073 million colors Brightness 400 cd/m2 (with cover glass) Contrast Ratio 4000:1 Viewing Angle Left/Right: 170° (typ) @ CR>10, Up/Down: 170° (typ) @ CR>10 Frequency Horizontal... - Page 41 Audio Audio Input Stereo Mini Analog Stereo L/R 0.5 Vrms Jack Audio HDMI Digital Audio PCM 32, 44.1, 48 KHz (16/20/24bit) Connector Audio Stereo Mini Analog Stereo L/R 0.5 Vrms Output Jack Audio Speaker Output Internal Speaker 10W + 10W Control Remote IN Stereo Mini jack 3.5?
- Page 42 Protective Glass Material Tempered glass Thickness 4.0 mm Surface Treatment Anti-Glare coating Transparency More than 89% Reflection Rate δ2% Surface Hardness Impact Resistance 100 cm VESA compatible mounting interface 400 mm x 400 mm (M6, 4 Holes) Power Management VESA DPM Plug &...
-
Page 43: Appendix - Supported Media
Appendix – Supported Media VIDEO SPECIFICATIONS MPEG-1 Maximum File Video Maximum Maximum Audio Container frame WMA L-PCM extension codec resolution bit rate Layer2 rate and 3 .mpg − MPEG-2 1080P 30fps 20Mbps .mpeg Video MPEG2- MPEG-2 1080P 30fps 20Mbps ... -
Page 44: Audio Specifications
AUDIO SPECIFICATIONS File extension Audio codec Bit rate Sampling rate MPEG1 Audio .mp3 32Kbps - 320Kbps 32kHz - 48kHz Layer 3 .m4a AAC, HEAAC 24Kbps - 384Kbps 8kHz - 48kHz .AAC .wma 128Kbps - 320Kbps 8kHz - 48kHz .asf LPCM 64Kbps - 1.5 Mbps 8kHz - 48kHz (Movie file only) -
Page 45: Manufacturer's Recycling And Energy Information
We at Acer are very conscious of the environmental effects of our business and strive to identify and provide the best working procedures to reduce the environmental impact of our products. - Page 46 WEEE Mark (European Directive 2012/19/EU) Disposing of your used product: In the European Union EU-wide legislation as implemented in each Member State requires that used electrical and electronic products carrying the mark (left) must be disposed of separately from normal household waste.
