SEFRAM DAS60 User Manual

Hide thumbs Also See for DAS60:
Table of Contents

Advertisement

Quick Links

Download this manual
RECORDER
DAS60
USER'S MANUAL
November 2017

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the DAS60 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for SEFRAM DAS60

Summary of Contents for SEFRAM DAS60

  • Page 1 RECORDER DAS60 USER’S MANUAL November 2017...
  • Page 2 Thank you for buying a SEFRAM recorder and for your trust in our company. The main goal of our various teams (research department, production, commercial, after-sales…) is to meet your requirements as much as possible by designing or updating high tech products.
  • Page 3 In case of guarantee contract, this will cancel or replace these guarantee conditions here above. The guarantee conditions by SEFRAM are available on the website www.sefram.com. The general guarantee conditions should prevail on the following conditions that they sum up.
  • Page 4 What to do in case of malfunction? In case of malfunction or for any advice for use, please contact the technical support by SEFRAM Instruments & Systèmes: A technician shall answer you and give you any information required to solve your problem.
  • Page 5 Climate and environmental conditions restrict the specifications of your recorder. SEFRAM checks the characteristics of each appliance one by one on an automatic bench during its manufacture. The adjustment and control are guaranteed under conditions of the ISO9001 certification by facilities in connection with the COFRAC (or equivalent in the context of ILAC reciprocity).

  • Page 6: Table Of Contents

    Important Information 1. TABLE OF CONTENT TABLE OF CONTENT ......................1.1 IMPORTANT INFORMATION ....................2.7 2.1. Specific cautions ......................... 2.7 2.2. Security instructions ......................2.7 2.3. Conformity and limits of the device ................... 2.8 PRESENTATION ........................3.1 3.1. General ..........................3.1 3.2.
  • Page 7 Important Information 5.2. Setup menu ......................... 5.2 5.3. Channels Menu ........................5.3 5.3.1. Analog channels ......................5.4 Type of measurement ΔV/Δt : ................. 5.5 5.3.1.1. Type of measurement ʃV.dt: ..................5.7 5.3.1.2. 5.3.2. Additional functions between channels ............... 5.8 5.3.3. Logic channels ......................
  • Page 8 Important Information 9.5. Double Trigger mode ......................9.4 9.6. Recording..........................9.5 9.7. Memory output ........................9.7 TEMPLATE MODE ......................10.1 10.1. Setup and launching of the data acquisition ..............10.1 10.2. Creation of the template ....................10.3 FILE MODE ......................... 11.2 11.1.
  • Page 9 Important Information ETHERNET INTERFACE ....................15.2 15.1. Ethernet Interface ......................15.2 15.1.1. General ........................15.2 15.2. WIFI interface ....................... 15.3 15.3. FTP transfer ........................15.4 15.4. Managing with VNC: ....................15.5 15.4.1. Changing the password ..................15.5 15.4.2. External software VNC Viewer ................15.5 15.4.3.
  • Page 10 Important Information 15.9. Error messages ......................15.27 TECHNICAL SPECIFICATIONS ..................16.1 16.1. Isolated inputs ....................... 16.1 16.1.1. General characteristics ................... 16.1 16.1.2. Voltage recording ....................16.1 16.1.3. RMS recording ...................... 16.2 16.1.4. Temperature recording ..................16.2 16.1.5. Frequency recording: ..................... 16.2 16.1.6.
  • Page 11 Important Information 16.14. Accessories ......................... 16.11 16.14.1. Accessories provided with the device ..............16.11 16.14.2. Accessories and options..................16.11 16.14.3. Consumables ......................16.11 APPENDS ..........................17.2 17.1. Information about the input calibers ................17.2 17.1.1. Insulated voltage type inputs ................. 17.2 17.2.

  • Page 12: Important Information

    In case of malfunction or for the maintenance of the device, only a qualified personal shall be allowed to work on it. In such a case, it is necessary to use Sefram spare parts. Never cover the device: there is live voltage.

  • Page 13: Conformity And Limits Of The Device

    Ground: accessible parts linked to the ground of the device. 2.3. Conformity and limits of the device The DAS60 recorder is in conformity with CEI 61010-1 (2001-02). It includes high-potting (IR) with two primary insulation levels (IP). Thanks to them, the channels 1 to 6 are insulated from each other and from the carter. This architecture allows independent floating measurements within the limits of the admissible maximum voltages.

  • Page 14: Presentation

    3. PRESENTATION 3.1. General DAS60 is a programmable recorder that make it possible to measure and record voltages, currents, temperatures, etc. on 6 channels and on 16 logical channels. You can also record from Pt100 or Pt1000 probes on dedicated channels.

  • Page 15: Description

    Presentation 3.2. Description 3.2.1. Connection: 1- A RJ45 connector for the ETHERNET 10/100BaseT interface 2- two USB connectors for (female) USB stick 3- a SUB-D 25-pin connector for the 16 logic inputs and the alarm outputs 4- 6 inputs through pin plugs according to the device 5- 2-way Pt100 (screw terminal block) 6- Power/Battery charger (on the upper side) 7- Power on button and light...

  • Page 16: Touch Screen

    Presentation 3.3. Touch screen 3.3.1. Description of the title bar Various zones on the screen: 1- Current mode (direct mode, memory mode…) 2- Status of acquisition (pending acquisition, stop) 3- Status of the battery 4- Direct access to display 5- Access to the display of the memory 6- Access to the recording 7- Screenshot button 8- Date and time...

  • Page 17: Description Of The Channel Validation Window

    Presentation 3.3.2. Description of the channel validation window 1- Change of the color of the channel (by pressing this button, you can access pre-defined colors or design customary paint mixes: 2- Change the thickness of the line for the selected channel. You can also change this thickness with the (thinner) and (thicker) keys...

  • Page 18: Description Of The Network Analysis Window

    Presentation Some information is available on this window: when clicking on a logic channel, the relevant pin on the connector turns red when pressing the keyboard, you can change the name of the channel. 3.3.3. Description of the network analysis window 1- Setup of the network analysis 2- Changing the color of the various measurements (voltage, current, power…) Page 3.5...
  • Page 19 Presentation 3- Measurement mode of the current (clamp, shunt, transformer) 4- Parameters of the current measurement (conversion from the measured value and the value sent to the recorder) 5- Nominal current in the phase conductor 6- Wiring scheme 7- Logic channels (validation and parameter setting) 8- Display of the measured values 9- Phase diagram 10- Type of network...

  • Page 20: Main Menu

    Presentation 3.4. MAIN MENU 1- Direct mode key (direct printing of the curve) 2- Memory mode key 3- File mode key 4- Template mode key 5- Network mode key 6- Start screen to display the serial number, the software version… 7- Recording 8- Replay of the memory 9- Digital display of the values of the various inputs...
  • Page 21 Presentation Note: By pressing various parameters, you can change them. In addition, by pressing the name of the channel (A1, A2…), you directly access the parameter setting page of the channel 16- Configuration of the function channels (calculations between several channels) 17- Activation or deactivation menu of the various channels.

  • Page 22: Update Of The Internal Software

    The internal software is regularly updated with the latest evolutions. These updates are available on our website. http://www.sefram.com/wwwfr/F_D_SOFTWARE.asp To update it, copy the file you receive on an USB stick. Plug it on to the USB connector at the rear of the device.

  • Page 23: Setup And Precautions Of Use

    Set-up and Precautions of Use 4. SETUP and PRECAUTIONS of USE 4.1. Loading of the recording paper NOTE: Only one face of the paper is heat-sensitive. Reversing the paper at loading will result in the absence of any printing out. Procedure: ...

  • Page 24: Setup

    Set-up and Precautions of Use 4.2. Setup You turn on the recorder by pressing the button at the top of the device. When the device is on, the ON/OFF button is lit blue. After launching the software, the recorder displays a homepage that specifies the hardware version, then switches automatically to the «...

  • Page 25: Voltage Measurement

    Set-up and Precautions of Use CONNECTION TO THE MEASUREMENT NETWORK 4.3.1. Voltage measurement The voltage is measured between the red and black terminals of the inputs with wires and male security pin plugs (according to CEI 1010). 4.3.2. Temperature measurement with a thermocouple The voltage resulting from thermocouple effect must be measured between the red and black terminals of the relevant input.

  • Page 26: Connection Of The Ground

    Attention: Any intervention on the battery requires dismantling of the device and shall be made by a SEFRAM technician. Only use batteries provided by SEFRAM. Security advice: ...

  • Page 27: Offset Calibration

    Set-up and Precautions of Use The battery should last 200 charge-discharge cycles or 2 years. Advice to extend the life of the battery:  Do not discharge too much  Do not store the batteries too long without using them ...

  • Page 28: Default Calibration

    4.10. User mode You can activate or disactivate the user mode. The user mode allows you to lock the configuration of the device while keeping all other menus available. The password is: Sefram. You can access this parameter at page...

  • Page 29: Use

    5. USE 5.1. Description of the various modes Selection of the functioning mode of the recorder:  DIRECT mode:  real time print out of the measured signals (Option)  use: immediate paper printing, slow protracted data acquisition  possibilities: complex triggers of the drawing, action after the end of the drawing, simultaneous record on file ...

  • Page 30: Setup Menu

    5.2. Setup menu General configuration of the device, monitoring of the alarm outputs, network address TCP/IP, calibration of the channels, update of the internal software. 1- Language: selection of the language of the device 2- Screen intensity: increase/diminution of the backlighting of the LCD screen, adjustment of the delay with the keys (decrease) and (increase)

  • Page 31: Channels Menu

     Left: max. value of the left channel 11- Date change: changing the date and time of the device 5.3. Channels Menu By pressing the menu « channels », you access the table of all available analog and temperature channels of your recorder. This table gives you a quick insight of the various adjustments of the channels.

  • Page 32: Analog Channels

    5.3.1. Analog channels 1- Number of the channel 2- Name of the channel: give a name to the channel (max. 26 characters) 3- Type: selection of the type of measurement made on the input  voltage, current, frequency, thermocouple or counter ...

  • Page 33: Type Of Measurement Δv/Δt

     None: no function  Change of unit: changes the unit of the measures made on the channel; you can program a couple of dots X1, Y1 and X2, Y2 for scaling  Calculation: available mathematical functions, associated parameters and unit aX+b : identical to the change of units, but instead of giving a couple of dots, you give the intercept (b) and the slope (a).
  • Page 34 Select the measurement period from 200µs to 10min It’s the time between 2 derivative calculations. Take a period compatible with the signal speed: a period too short give a derivative with noise. Example: Channel 1: triangle signal, -5V to + 5V, period 5s Channel 2: use measurement type ΔV/Δt with the same signal ΔV +-10V Δt 50ms...

  • Page 35: Type Of Measurement Ʃv.dt

    Type of measurement ʃV.dt: 5.3.1.2. 1- ʃV.dt :Put on the measurement type « integral » If U is the voltage measurement, every period dt the recorder calculate U*dt and add this to the previous calculation: this sum or integral is expressed in Vs (Volt*second). The integral is reset by the user and/or every start of measurement.

  • Page 36: Additional Functions Between Channels

    5.3.2. Additional functions between channels There are function channels on this device. You can activate up to 4 function channels (FA, FB, FC, FD). These channels make it possible to make calculations between channels or calculations of average values… For example, if you want to calculate a value of power, select the parameters of the A function channel You get this page above.

  • Page 37: Logic Channels

    y = channel A2 coefficient a = 1 coefficient b = 0 5.3.3. Logic channels The 16 logic channels can be recorded simultaneously with the analog channels. To set the parameters of the logic channels, you can press the « logic channels » menu on the main window or directly press the logic channels part at the bottom of each configuration window: You access the configuration page of the logic channels: 1- Selection of the name of each channel on screen...

  • Page 38: Validation Of The Channels

    5.4. Validation of the channels You can validate or not the channels to record or print out in the various configuration menus of the recorder. In order to validate or not the record or the printing of a channel, you must check (to validate) or uncheck (not to validate) the checkbox right to the bargraph of the channel.

  • Page 39: Direct Display » Key

    5.5. « Direct display » key 5.5.1. Real time on-screen display of the measurements 1- Screen configuration: configuration of the display of measurements on screen. Selection of the mode of graphic display:  F(t)  XY  Digital measures (full screen) ...

  • Page 40: Xy Display

    7- Access to the channel configuration page: 1- Screen setup: configuration of display of measurements on screen  Selection of the graphic display mode:  F(t)  XY  Digital measures (full screen)  Full screen to display the reticule on the whole screen (mode f(t)) ...

  • Page 41: Digital Display

    1- Screen setup: configuration of the display of measurements on screen. Selection of the mode of graphic display:  F(t)  XY  Digital measures (full screen)  Full screen to display the reticule on the whole screen (mode f(t)) ...
  • Page 42 Page 5.14...

  • Page 43: Trigger » Menu

    5.6. « Trigger » menu Programming the start and stop conditions for the paper print in Direct mode, and the data acquisition conditions for the channels in Memory, File and Template modes. Selection of the actions after data acquisition or plot and validation of the save in real time. The program of triggers is different according to the pending mode (Direct, Memory, File or Template).

  • Page 44: Memory Output » Key

    5.7. « Memory output » key Display on screen of the data acquisitions available from the internal memory or from files of the internal memory or an USB stick. This function includes the same commands as the « Direct display » function. The «...

  • Page 45: Record » Key

    The display is made in 2 phases:  A quick phase to display the frame of the data acquisition: some dots may not appear  A slower phase where all data acquisition dots are displayed: the advancement percentage is displayed at the bottom of the screen. 5.8.

  • Page 46: Screen Copy

    5.9. Screen copy You can create a file copying the content of the LCD screen: You only have to press at the top right of the screen. The file will be created either onto the USB stick, if there is one, or into the internal memory. The name of the file will be bmpxxxxx.bmp (incremental name).

  • Page 47: Triggers

    Triggers 6. TRIGGERS This chapter describes all possible triggers of the device. They are used by: the « configuration » menu, with the A and B alarms the « triggers » menu, with the start and stop parameters of the recording. ...

  • Page 48: Analog Channel Trigger

    Triggers 6.1. Analog channel trigger By pressing Start or Stop, you open the setup window for the trigger of the start or stop of recording. After selection of the trigger on Analog Channels, the following line on screen allows you to set the trigger condition.

  • Page 49: Multiple Thresholds

    Triggers 6.1.2. Multiple thresholds After selection of a trigger on a set of logic channels, the window allows you to set the trigger under several conditions. Then, by pressing the various thresholds in front of their respective channels, you open the threshold parameter window.

  • Page 50: Parasites

    Triggers 6.1.3. Parasites You can trigger a parasite with a periodic 50Hz signal: trigger when the shape of the signal radically changes:  parasite impulsion >200µs  sudden change of frequency  sudden change of shape Page 6.4...

  • Page 51: Trigger On Logic Channels

    Triggers 6.1.4. Trigger on Logic Channels After selection of the trigger on Logic Channels, the window allows you to set the trigger condition. The 16 logic channels can be used in the trigger word:  either active at status 0 (less than 1.6 volt) ...

  • Page 52: Mathematical Calculations

    Mathematical calculations 7. MATHEMATICAL CALCULATIONS You can apply mathematical calculations on your data acquisitions. You can access them with the « Direct display » function. 7.1. Definitions Press the « Mathematical calculations » key. 1- Add: add a mathematical calculation 2- Remove: remove one of the displayed mathematical calculations 3- Channel: selection of the channel on which the calculation is applied 4- Function: selection of the calculation function applied in the formula.

  • Page 53: Types Of Calculations

    Mathematical calculations 18 various mathematical formulas are available. You can display up to 5 simultaneous calculations on screen. The display is made in windows above the diagrams, where are specified:  the number of the channel (with its color)  the type of calculation ...
  • Page 54 Mathematical calculations Drawing Math function Calculation Observations The lowest negative Minimum voltage bottom The highest positive Maximum voltage peak Max – Min Peak to Peak The most frequent value below the median The most frequent High value above the median High –...
  • Page 55 Mathematical calculations = 90% Amplitude = 10% Amplitude Falling edge – T fall Measurement of the time of 1 Width of positive pulse. It is measured at positive impulsion 50% of amplitude Width of Measurement of the time of 1 negative negative pulse.

  • Page 56: Direct Mode

    Direct Mode 8. DIRECT MODE This chapter describes the Direct mode of the recorder, designed to print out the measurements made on the channels in real time on heat-sensitive paper. This mode does not exist on models without integrated printer You can start and stop the print out under various conditions.
  • Page 57 Direct Mode 3- Print configuration: see chapter 4.2 4- Start: start condition of the print  Manual: with the  Trigger: with a channel, with a combination of analog and logic channels (see chapter 5)  Stand-by: after a delay or at a precise date and time 5- Stop: stop condition of the print ...

  • Page 58: Configuration Of Print

    Direct Mode 8.2. Configuration of print Press Definition of the specific characteristics of the paper printing: 1- Reticule: setup of the reticule on paper  none, all 5mm, 10mm or per integer number of divisions  fine or wide, which means with or without subdivisions ...

  • Page 59: Relaunching The Printing

    Direct Mode 8.3. Relaunching the printing In relaunch mode, as soon as stop conditions happen, the device waits for new start conditions for the print out. To terminate the cycle, you only have to force the interruption of the print by pressing during the print.

  • Page 60: Memory Mode

    Memory Mode 9. MEMORY MODE This chapter describes the Memory mode designed to record in real time the measurement data made on the channels into the internal memory. You can start and stop the data acquisition under various conditions. You can simultaneously save measurements on file. 9.1.
  • Page 61 Memory Mode 3- Start: start condition of the data acquisition  Manual: with the  Trigger: with a channel, with a combination of analog and logic channels  (see chapter 5)  Stand-by: after a delay or at a precise date and time ...

  • Page 62: Sampling Period

    Memory Mode « Impossible » shows up when there is not enough place for saving data: you should reduce the sampling rate or the number of channels See chapter File mode to know the restrictions of the recording on file. 9.2.

  • Page 63: Double Trigger Mode

    Memory Mode Thus, the memory block always contains the last N samples. The operator can select when the samples in buffer will be frozen; to do so, you will select a delay between the trigger start and the beginning of the effective buffering. This delay may be positive or negative: thus, buffered samples may be before, after or on both sides of the start moment.

  • Page 64: Recording

    Memory Mode 9.6. Recording You launch the data acquisition by pressing after pressing At the top left of the screen appear: the number of the pending block, if required the current sampling rate the status of data acquisition (waiting for trigger, filling xx%…) the opening of a save file, if required a bargraph showing the percentage of data acquisition made and the percentage of data acquisition displayed...
  • Page 65 Memory Mode For longer acquisition time, you can zoom onto a part of the data or change of page. When changing of menu page, you can return to data acquisition by pressing Additional menu keys:  Display:  Total : the whole memory is displayed and refreshed during the data acquisition. ...

  • Page 66: Memory Output

    Memory Mode 9.7. Memory output You can access the « memory output » mode by pressing Display of the data acquisitions available in the internal memory or in files. Possibility to start the paper printing of the data acquisitions. 1- Read blocks or file: selection of the memory block or of the file to display; if there is no valid block, the only menu key available will be «...

  • Page 67: Template Mode

    Template Mode 10. TEMPLATE MODE This chapter describes the Template mode designed to record in real time the measurement data made on the channels into the internal memory. You can start the data acquisition under various conditions It stops when the measurement values go out of a range defined by a previous data acquisition called Template.
  • Page 68 Template Mode 8- Blocks: parting of the internal memory in blocks  1, 2, 4, 8, 16, 32, 64 or 128  Erase blocks: erasing of all blocks: the current block is #1 1- Acquisition period: sampling speed of the channels ...

  • Page 69: Creation Of The Template

    Template Mode 10.2. Creation of the template Make a data acquisition into memory. Press , then select The device displays the current template. It is marked as 2 curves (a min. curve and a max. curve) around the channel selected as a reference for the template. The 2 curves are saved in internal ROM.
  • Page 70 Template Mode Use of the template The comparison with the template is the stop criterion of the data acquisition. This comparison shall be made with the « Template Channels » selected in the page. The information window at the bottom of the page sums up the general configuration of the data acquisition: ...

  • Page 71: File Mode

    File Mode 11. FILE MODE This chapter describes the File Mode designed to record in real time the measures made on the channels. The start and stop of the plot can be triggered under various conditions. 11.1. Setup and triggering of the data acquisition Press Setup of the data acquisition into a file.

  • Page 72: Restrictions

    File Mode  Automatic 4- Stop: stop condition of the data acquisition  Automatic: when the disk is full  Trigger : with a channel, with a combination of analog and logic channels (see chapter 5) Trigger mode Double Trigger; see chapter Memory mode. 11.2.

  • Page 73: Network Analysis

    The connections of the inputs on the installation to test shall be made by a duly authorized personal. In network analysis the DAS60 should be strictly connected to its external power supply and connected to the socket : this for security reasons ensuring earthing.

  • Page 74: Network Setup

    Network Analysis 12.2. Network setup In the main menu, change of mode by pressing . You directly access the setup page. Select the basis configuration of the network:  single-phase  three-phase mode Aaron: Only 2U and 2I are used. The 3 phase is re-calculated (method of the double-wattmeters).
  • Page 75 Network Analysis Wiring and check: Direct display of the network wiring. Any wrong wiring may lead to wrong results. The colors of the channels match the colors of the respective inputs. The voltage inputs U1, U2 and U3 are connected to the terminals 1, 3 and 5. The current inputs I1, I2 and I3 are connected to the terminals 2, 4 and 6.
  • Page 76 Network Analysis You can record additional channels by checking channels to record in the setup of your network analysis. The number of channels will change as a function of the network (single phase: more additional channels, three phases: less additional channels): Page 12.4...

  • Page 77: Real Time Display Of The Signals

    Network Analysis 12.3. Real time display of the signals By pressing , you have access to the following windows. You have access to this page even during data acquisition. Each of these windows can be invalidated by pressing  Fresnel diagram: display of the signal and of the RMS values of the inputs and of the frequency.

  • Page 78: Power Analysis Setup

    Network Analysis  Selection of the channels: you select either all the voltage channels (U1, U2, U3) or all current channels (I1, I2, I3) or all network channels (U1, U2, U3 + I1, I2, I3) or only one channel (these channels are also used to record harmonics. ...
  • Page 79 Network Analysis 12.4.2.1. Manual launch You only have to press the record key to launch the record. You can select a stop condition (recording time or manual stop) 12.4.2.2. Automatic trigger You only have to press the record key to launch the record,but no stop condition is possible unless manually.

  • Page 80: Recordable Parameters

    Network Analysis You can set up the record so that it starts after a selected period or at a specified date and select a stop condition (record time or manual stop) 12.4.3. Recordable parameters  Number of observed values: you can select it under "Number of parameters". The possible values range from 1 to 14.

  • Page 81: Measurement Process

    Network Analysis You launch the data acquisition by pressing . There is no trigger: the record is made in real time, directly on the disk. During the data acquisition, you cannot change the parameters of data acquisition, but you can change the display parameters (zoom, color, display validity...).

  • Page 82: File Management

    File Management 13. FILE MANAGEMENT 13.1. General For all possible files, the device has an internal flash disk available and may accept an USB stick, which makes it possible:  to save and load the total configuration of the recorder ...

  • Page 83: Management Of The Configuration Files

    File Management It is highly advisable to work in a directory and not at the root of the flash disk When erasing a directory, all files in this directory will be erased too. 13.2. Management of the configuration files The configuration file management page is linked to the key.
  • Page 84 File Management  Manual: Available under every mode; you can access it from the function after stopping the sweep and pressing . The following window pops up: 1- Read block: lire un bloc mémoire 2- Selection of the block to read 3- Read a recorded file 4- Write data into a file: Record the data displayed on screen into another file.

  • Page 85: Recovery Of The Data Acquisition Files

    File Management Name of the files: the name of each file is made of 12 characters plus one 4-cipher number. The device will automatically increase this number at each record. Only the validated channels (i.e. in ON position; see chapter Use) will be recorded into the file. Before writing into the file, a pop-up reminds you the saved channels and the number of points per channel.
  • Page 86 File Management Select the place and the name of the file to load and display on screen, then press Page 13.6...

  • Page 87: Operating Software

    Thanks to the FTP protocol. 13.3.1. Transfer via FTP  Using SeframPilot: The ftp transfer is made directly by SeframPilot: if the IP address is for DAS60, validate with  Using Windows Explorer: You can create a favorite icon: ...

  • Page 88: Display Under Seframviewer

    File Management 13.3.2. Display under SeframViewer Launch SeframViewer (or double-click on a file) Open a.REC file. You can select:  the channels to display  the display mode f(t) or xy  the autocalibration of the channels. Your data acquisition file shows up on screen. SeframViewer functions are available.

  • Page 89: Managing With Seframpilot

    File Management You can also directly create a result file (text or Excel file) by launching the following line in the ® Windows command mode: (see Menu, sub-menu Help Options) Example: C:\SeframViewer monfichier.rec /x : direct creation of an Excel file C:\SeframViewer monfichier.rec /t : direct creation of a text file.

  • Page 90: Inputs / Outputs

    Inputs / Outputs 14. INPUTS / OUTPUTS 14.1. Additional Input/Output Connectors The connector is at the rear (female SUB-D 25pin). # pin Name of the signals Logic channel 1 Logic channel 2 Logic channel 3 Logic channel 4 Logic channel 5 Logic channel 6 Logic channel 7 Logic channel 8...

  • Page 91: Logic Inputs

    Inputs / Outputs 14.2. Logic inputs Non-connected inputs are according to the following circuit: Non-connected inputs are 0V potential (level 0). Number of logic channels: from 1 to 16. TTL level: 3.3V (protected up to 24V) To create a rising edge, you only have to place a connection between the power input and output of the connector.

  • Page 92: Use

    Inputs / Outputs 14.3.1. Use Signal for internal events to the outside toward the recorder (triggers on logic or analog channels, status of the printing block…) See chapter « Use ». 14.4. Power supply output There is a power supply output restricted to 0.2A (see figure "connector"). The voltage is the one of the 9-12V battery as a function of the charge and 15V is the charger is connected.

  • Page 93: Exvoltage Box Input/Output Interface

    Inputs / Outputs 14.5. Exvoltage box input/output interface The exvoltage box input/output interface option (code 984405500) makes it possible to:  Convert an alternating voltage (example 230V 50Hz) into a logic signal 1  Easy connection of the inputs of the 16 logic channels ...
  • Page 94 Inputs / Outputs  0 to 10V=~ connection 0 - 10V logic channel 1 by a screw terminal between the points 1 and 2 of the screw terminal box max. usable voltage: 10V continu ou alternatif frequency: 45 à 440Hz typical trip threshold (AC or DC): 2.2V undetected low threshold (AC or DC): 0 to 1V detected high threshold (AC or DC): 3V to 10V...

  • Page 95: Ethernet Interface

    Ethernet Interface 15. ETHERNET INTERFACE 15.1. Ethernet Interface 15.1.1. General You can use the recorder remotely via its Ethernet interface with the TCP-IP protocol. Connect the recorder to your network with a straight-through cable onto the 10/100 BASE-T (RJ45) connector at the rear of the device. You can use the recorder on an Ethernet network 10 Mbit/s or 100Mbit/s.

  • Page 96: Wifi Interface

    Then, you only have to send the commands as per the following paragraphs to the recorder. 15.2. WIFI interface Use only the USB stick provided by SEFRAM. Turn the device on with the USB stick on a relevant port. In the « Setup » menu, press the « Network » key.

  • Page 97: Ftp Transfer

    Ethernet Interface 15.3. FTP transfer Transfer your files to your computer to save them or view them with the SeframViewer software.  Using of the Windows file explorer  Filezilla: freeware (https://filezilla-project.org/)  Using an external browser (Internet Explorer, Mozilla, Opera, Chrome, etc.) Launch your browser and type the connection address (see §...

  • Page 98: Managing With Vnc

    On the VNC Server line: you must type the IP address of your recorder and the password (the default password is « sefram »), then click « Connect » You will be able to control your recorder from your computer.

  • Page 99: Programming Language

    Ethernet Interface 15.4.3. 15.5. Programming language 15.5.1. Format of the reception messages In all the following examples, the space character is pictured as a blank space. Exchanges from a controller to the recorder are made as messages made of a chain of ASCII characters (and possibly of binary octets) with a message termination at the end.

  • Page 100: Formats Of Emission Messages

    Ethernet Interface A header chain always starts with an alphabetic character. It may be preceded by a colon ":" (compound header) or end by a question mark "?" (query message). Query messages must be followed by the termination. - Header separator: One or several ASCII characters (0 to 32, decimal except 10 and 13).

  • Page 101: Standard Instructions

    Ethernet Interface A message unit (ex. TYP:THE J,COMP) is made of several fields: - One header: (ex.TYP:THE) made of only one (simple header) or several (compounds header) chains of 1 to 12 alphanumeric characters (upper scale only or digital or "_" (code ASCII 95 in decimal format). A header chain always starts with an alphabetic character.

  • Page 102: Indication Of The Status Of The Device

    Ethernet Interface *RST RESET OF AN DEVICE action: setup of a recorder in a fixed configuration (voltage inputs, 10V caliber, centered on 0V...) *REM PENDING PROGRAMMING PART (REMOTE) (facultative) *LOC RETURN TO LOCAL MODE *CLS ERASING THE STATUS LOGS action: the device resets the status logs. *ESE VALIDATION OF THE STANDARD EVENT BITS OF A DEVICE *ESE is followed by a number between 0 and 255...

  • Page 103: Service Request Logs

    Ethernet Interface 4 logs are used: - the service request log (STB) associated with its validation log. - the standard event log (ESR) associated with its validation log. The bits #0, 1, 2 and 7 of the STB log are available for use as sum-up messages specific to the device.
  • Page 104 Ethernet Interface Status log: It includes the status word of the device. You can read this status word thanks to the request with the "*STB?" instruction. In this case, the bit #6 is MSS (Master Summary Status) that results from the logic operations as pictured in the figure below.

  • Page 105: Log Of Standard Events

    Ethernet Interface description of this log). Its status specifies whether one or several authorized events have happened in the status log of alarms since its latest reset. Validation log: The status word is associated to a validation log that makes it possible to manage the service request by allowing it only for some specific cases.

  • Page 106: Use Of The Status Data Structure

    Ethernet Interface The structure of the log of alarms is appended to the bit #0 of the log of service requests. Log of status: This log contains some messages specific to the recorder, whose meaning is exposed hereafter. You can read its content with the command SRQ_TYPE? Reading the log erases it.
  • Page 107 Ethernet Interface The controller should regularly read the log of service requests with the instruction "*STB?". Switching of bit #6 (MSS) to 1 shows that an authorized event happened. Reading the status word makes it possible to discover the type of event that happened. In the case of a standard or specific event, you have to read the associated status log with the instructions "*ESR?"...

  • Page 108: Dictionary Of Programming

    Ethernet Interface 15.8. Dictionary of programming In the following table, it is not compulsory to send the lower case characters of the headers and parameters. As a rule, digital parameters are integers (NR1); parameters specified "decimal" may be NR1, NR2 or NR3.

  • Page 109: Parameters Of The Channels

    Ethernet Interface 15.8.2. Parameters of the channels HEADER PARAMETERS EXAMPLES CHAN 3 CHAnnel Allows you to set the CHANNEL input you can change with We chose to change the the commands channel 3 P1 = selection of the input 1, 2, PT1, PT2, A, B, C, D. Returns the number of the selected input and its value.
  • Page 110 Ethernet Interface HEADER PARAMETERS EXAMPLES FILTER 10Hz FILter Definition of the filter of the selected channel from the CHANNEL command P1 = WOUT,F10kHz,F1kHz,F100Hz,F10Hz, F1Hz,F10S,F100S or F1000S Returns the filter of the selected input FILter ? P1,P2,P3 RANGE 12,3,0 RANGE Changes the caliber and the center of the input :CHAN caliber = 12 Volts P1 = Caliber in ISO units (Volts or °C) in real time centered around 3 Volts...

  • Page 111: Functions Of The Channels And Between Channels

    Ethernet Interface 15.8.3. Functions of the channels and between channels HEADER PARAMETERS EXAMPLES CHAN 2; FUNCTION LOGX; FUNCMATH Allows the selection of a mathematical function for the The channel 2 = aLog(x)+b CHANNEL input P1 = Type of function : NONe, UNIT, AX, ABSX, SQRX, SQROOTX, LOGX, EXPX,AINVX,ADVDT,AINTV (none, change of unit, ax+b, a|x|+b, ax²+b, ...)

  • Page 112: Paper

    Ethernet Interface 15.8.4. Paper HEADER PARAMETERS EXAMPLES DIRECTPLOT DIRECTPLOT FT Set-up of the transcription mode on paper in direct mode P1 = FT, TEXTe, XY Returns the paper mode DIRECTPLOT ? SPEed P1,P2 SPEED 10,MM_S Definition of the paper scroll speed Speed 10 mm/s P1 = speed value: 1,2,5,10,20 for P2 = MM_H or MM_M,...

  • Page 113: Triggerings

    Ethernet Interface 15.8.5. Triggerings EN-TETE PARAMETRES EXEMPLES Manual trigger (start or stop) START:MANUAL START:MANual Trigger on a combination of thresholds (see chapter 8.3) start:trig;:trig:chan A1,S1,POS START:TRIG P1,P2,P3 START:WAIt 0,2,10 START:WAIt Trigger on a waiting time waiting 2min 10sec P1 = number of hours waiting (0 to 23) P2,P3 = minutes, seconds (0 to 59) P1,P2,P3,P4,P5,P6 SEQ START;SEQ:DATE...

  • Page 114: Triggers

    Ethernet Interface 15.8.7. Triggers TRIG:LOG P1 P1,P2 TRIG:LOG "XXXXXXXXXXXXXXX1", AND Selection of trigger on logic channels P1 = sets the 16 values of the triggers; add a message trigger on logic channel VL1 delimiter (brackets) P2 = AND or OR TRIG:CHan P1,P2,P3 P1 = Number of the channel (1,2, etc.) TR:CH 1,S1,EDGEP...

  • Page 115: Memory Mode

    Ethernet Interface 15.8.9. Memory mode HEADER PARAMETERS EXAMPLES P1,P2 MEMSpeed 10,MICro MEMSpeed Set-up of the sampling period 10 µsec period P1 = Period (from 1 to 500) P2 = MICro,MILIsec,Sec,MIn,HOurs is the unit Use of an external clock MEMSpeed:EXT Returns the data acquisition speed MEMSpeed ? MEMBLOC 4 MEMBloc...

  • Page 116: Relaunchs, Real Time Save

    Ethernet Interface 15.8.10. Relaunchs, real time save HEADER PARAMETERS EXAMPLES REARm SINGLE REARm définition du réarmement manuel P1 = SINgle, AUTo, SETup REARM SETUP; REARm:SETup REAR:SETUP 2 Number of the set-up to change Go to configuration 2 P1 = 1 to 15 Returns the type of relaunch REARm ? SAVE DISK...

  • Page 117: Diagrams

    Ethernet Interface 15.8.13. Diagrams P1,P2 GRID:LOG 50,5,UP;:GRID GRID 2,SEPLOGON Set-up of the diagrams P1 = Number of the diagram The logic channels are at the top and are 50mm tall on 2 P2 = SEPLOGON or SEPLOGOFF : separate logic channels 100mm screens Returns the set-up of all diagrams GRID ?

  • Page 118: Direct Display

    Ethernet Interface 15.8.14. Direct display SCREEN SCREEN FT Set-up of the display mode P1 = FT, TEXT or XY P1,P2,P3 PAGE SCOPE;SCREEN SCREEN:FT FT;:SCREEN Set-up in F(T) VER,BOUNON,FULLON P1:VER or HOR for vertical or horizontal P2:BOUNON or BOUNOFF to display the boundaries vertical full-screen display P3:FULLON or FULLOFF for full-screen display or not P1,P2...

  • Page 119: Memory Output

    Ethernet Interface 15.8.16. Memory output HEADER PARAMETERS EXAMPLES P1,P2,P3 OUTBLOC 1,25.2,80 OUTBloc Set-up of the block and of the output window block 1, start at 25.2%, stop at 80 % P1 = 1 to 128 number of block P2 = from 0 to 100 (real percent of start) P3 = from 0 to 100 (real percent of end) Returns the command OUTBloc ?

  • Page 120: Request Of Service

    Ethernet Interface 15.8.18. Request of service Refers to the explanations about the structure of the status data. HEADER PARAMETERS EXAMPLES SRQ_ENABLE 3 SRQ_ENABLE Allows you to modify the validation log of alarms P1 = value of the log 3 = 1 + 2, chich means bits 0 and 1 decimal The start and end of drawing...

  • Page 121: Technical Specifications

    Technical Specifications 16. TECHNICAL SPECIFICATIONS 16.1. Isolated inputs 16.1.1. General characteristics Number of inputs: 6 according to the device Impedance: Impedance > 25 MΩ for calibers < 1V Impedance = 1 MΩ for the other calibers Max. acceptable voltages: between the 2 terminals of a channel: +500 V or 500 V 50Hz Installation category: overvoltage category: III 600V...

  • Page 122: Rms Recording

    Technical Specifications 16.1.3. RMS recording Software RMS calculation: sampling: 200µs max. frequency: 500Hz peak factor 2.2 and 600V max. instant accuracy: ± 1% (sine signal) answering time: typical 100ms (40ms @ 50Hz) max. measurable voltage: 424 V AC 16.1.4. Temperature recording Sensor Domain of use -210°C to 1200°C...

  • Page 123: Sampling

    Technical Specifications decision threshold variable from -99V and 99V with 0.1V increment min sensitivity +100mV + 1% of the decision threshold max count while recording 65536 (beyond this limit, the counter is reset) max digital count 16.1.8. Sampling definition 14 bits max sampling period: memory and file modes: 1µs (i.e.

  • Page 124: Additional Inputs / Outputs

    Technical Specifications 16.2. Additional inputs / outputs 16.2.1. Logic channels Number of channels Input impedance 4.7 kΩ Sampling frequency identical to the main inputs max acceptable voltage 24 V Category 1 16.2.2. Alarm outputs A, B, C and D alarms 0-5V outputs on trigger (see chapter on data acquisition trigger...

  • Page 125: Triggers

    Technical Specifications 16.4. Triggers The triggers are identical for every various modes  date  delay  thresholds and combinations (or/and) of thresholds (2 thresholds per channel)  channel slopes (calculation on 10 ms to 1 s periods)  parasites (50 Hz signal) ...

  • Page 126: Network Analysis

    Technical Specifications 16.7. Network analysis These accuracy values require that the nominal values are correct. 16.7.1. Ranges and accuracies for voltage and intensity Root mean square voltage:  range: from 1 mV to 400 V  Accuracy: 0.5% of the nominal voltage. Root mean square current: ...

  • Page 127: Rate Of Harmonics As Calculated In Power Analysis

    Technical Specifications Peak factor: 1% accuracy up to 5 16.7.5. Rate of harmonics as calculated in power analysis Range: THD: from 0% to 600% from 0% to 100% Accuracy: measurement value ± 2.5% Harmonics: from ca. 2 up to ca. 50 Range: from 0% to 600% Accuracy:...

  • Page 128: Display

    Technical Specifications 16.10. Display Screen TFT 10", color, backlit Total definition 1024 x 600 dots 16.11. Environment conditions 16.11.1. Weather conditions Working temperature 0°C to 40°C max. relative humidity 80 % non-condensing Storage temperature -20°C to 60°C 16.12. Power supply - battery External power supply: mains block 100/240 VAC, jack 5.5 mm, hole 2.1 mm...

  • Page 129: Electromagnetic Compatibility, Security

    Technical Specifications 16.13. Electromagnetic compatibility, Security 16.13.1. Electromagnetic compatibility according to EN 61326-1 and 61326-1-2 Page 16.9...

  • Page 130: Security, Insulation Class, Installation Category

    Technical Specifications 16.13.2. Security, insulation class, installation category Security class: handy device for use on field Security conform to EN61010-1 (2001-02) Pollution degree Power supply by 15 V external block code 207195117 Installation category (overvoltage category) Measurement input category III 600 V, overvoltage 6000 V Other input/ouput measurement category I (CAT I) The carter of the device is grounded if the mains block is connected to the recorder...

  • Page 131: Accessories

    Technical Specifications 16.14. Accessories 16.14.1. Accessories provided with the device User’s manual Assistance CD with software and notices Battery charger 207195117 Common accessories:  1 male 25-pin connector 214200250  1 connector plug 214299014 Printer accessories:  1 paper roll 837500526 Accessories for 2-channel module: ...

  • Page 132: Appends

    Appends 17. APPENDS 17.1. Information about the input calibers Reminder: The caliber is the difference between the max. and min. values that you can display on screen or on paper. The origin is the center of the screen or of the paper. 17.1.1.

  • Page 133: Measurement Accuracy For Thermocouple

    Appends 17.2. Measurement accuracy for thermocouple The thermocouple measurements are treated as voltage measurements. For a given range of temperature measurement, the software calculates the voltage caliber the following way: * Let « T » the absolute value of the max. measurable value, in °C * Add 40°C to take the max.
  • Page 134 Appends EXAMPLE OF ACCURACY CALCULATION You make a welding between -50°C and +50°C with a J thermocouple with compensation of cold welding. Pt = Pl + Ps + Pm + Pd Pl = + 0.25°C (linearization accuracy) Ps = + 1.25°C (compensation of cold welding) Used caliber 10mV (see previous example) Accuracy for voltage measurement 0.1%*10mV + 10µV = 20µV...

  • Page 135: Instant Measurement Accuracy As A Function Of The Filters

    Appends 17.4. Instant measurement accuracy as a function of the filters The instant measurement accuracy is specified with a 10Hz filter: ± 0,1% of full scale ± 10µV ± 0.1% of the offsets Fr filters with higher frequency and for low calibers (great gain), the noise becomes more intense (the product gain ×...

Table of Contents
