6. HOW TO OPERATION

• HERE ARE 3 WAYS TO OPERATE:
1. Master/slave build-inprogram to control
2. DMX controller
6.1 Master/slave build-infunction
Connect the lights in series, the first light control
the other light to auto show, sound control show
and so on. It's very good for the instant show
mod. Must set the first light to be master light
MAST same time to choose SH0 (Random show),
SH1 (show 1) or ...or SH8 (show 8). If there are no
DMX signals, the master mode LED will light up,
the sound control LED will strobe according to the
music , the other lights will not work in slave mode.
C Choose SL1 (Normal) or SL2 (two light show)
mode, when connect the DMX cable, the slave LED
will light up.
DMX 512
(Choose A001 DEFAULT ADRESS CODE)
CH 1
Channel
CH1
(008-255allundersound control)
Two light show
For the slave light, slave1 (SL1) running same as
the master light, slave 2 (SL2) running against
the master light.If there are just two light, could
set these cond light as slave light (SL2) for better
show.
6.2 DMX Controller
If controlled by DMX controller, you need to set the
DMX address code to control the light, the address
code value is between 1-512, then the light will
receive the signal accordingly.
Press MENU button, choose
button, address code will strobe. Use UP/DOWN to
select DMX 512 address code. After address code
settled, press ENTER button until the address
code stops strobing, it will automatically return to
the menu after 8 seconds. If you want to go back
to the previous status and without any changes,
you could press MENU button.
Value
000-007
008-037
038-067
068-097
098-127
128-157
158-187
188-217
218-247
248-255
, press ENTER
Function
No function
Show mode 1
Show mode 2
Show mode 3
Show mode 4
Show mode 5
Show mode 6
Show mode 7
Show mode 8
Random show 1-8
