How to Set Up Your JSA3800 Appliance
Juniper Secure Analytics 3800 (JSA3800) is an enterprise-class appliance that provides a
scalable network security management solution for medium-sized companies up to large
global organizations.
The JSA3800 appliance is a 1-U, rack-mountable chassis with AC power supplies (or op-
tional DC power supplies), hot-swappable eight hard drives with 64 GB memory, and four
Gigabit Ethernet interfaces.

Front Panel

Front bezel
Hard drive 1
Hard drive 3
Hard drive 0
Hard drive 2

Back Panel

Dedicated
Power
supplies
IPMI LAN port
COM
USB
port
ports
USB
ports
Hard drive 5
Hard drive 4
Hard drive 6
Hard drive 7
GB
10GB+SFP
ports
ports
VGA
GB
port
ports
JSA3800 Package Contents
Lock
Power cords
Reset
Power
button
button
Rail adapters
UID
LEDs
Warranty and Registration
Information

Physical Specifications

Dimensions (H x W x D)
Chassis weight
Average power
Maximum thermal output
Relative humidity
Noise level
Rail kit
L-brackets
• End-User License Agreement
• Quick Start Guide
• Safety Guide
1.7 in x 17.2 in. x 23.5 in.
37 lb
203 W
693 BTU/hour
5% to 90%, noncondensing
67.7 dB - 68.4 dB per EN ISO 7779
Rail kit screws
DB9 adapter
1
