Continuing to turn the drum may cause
the cable to twist and kink. It may be
necessary to back the cable out of the
blockage by turning the drum in reverse.
In some cases, it may be possible to pull
the cable and the blockage out of the
drain by hand. If this is done, be careful to
not damage the cable. Remove the block-
age from the cable, feed cable back into
the drum, and continue cleaning the drain
as detailed above.
10. Once the blockage is broken up and drain
is flowing, if possible, turn the water on to
flush any debris down the drain.
11. Continue to clean the rest of the drain.
Pay attention to how far the cable has
gone. Do not overrun the cable into a
larger drain. This can cause the cable to
knot up or cause other damage. The
cable includes an increase in diameter
that will not feed through the AUTOFEED
mechanism – this can be identified by
openings in the cable wind just outside
the drain cleaner (see Figure 9).
Figure 9 – Openings in Cable Wind at the End
of Cable
12. Once the drain has been cleaned, turn
the drum counterclockwise while squeez-
ing the drain cleaner trigger to retract the
cable. Pay close attention, as the cable
may lodge in a blockage while being re-
tracted.
13. Release the trigger and stop turning the
drum when end of the cable nears drain
opening. Do not pull the cable end from
drain while it is rotating. The cable can
whip around and could cause serious in-
jury.
14. Several passes through a line are recom-
mended for complete cleaning. If needed,
repeat the above procedure.
POWER SPIN + ™ Drain Cleaner
15. Pull any remaining cable from the line
by hand and push the cable into the
drum.
Storage
The drain cleaner must be kept
WARNING
dry and indoors or well covered if kept out-
doors. Store the machine in a locked area that
is out of reach of children and people unfa-
miliar with drain cleaners. This machine can
cause serious injury in the hands of untrained
users.
Maintenance
Instructions
WARNING
Drill should be removed from drain
cleaner before any maintenance is per-
formed.
Cleaning
Cable, drum and AUTOFEED mechanism
should be thoroughly flushed with water after
every use to prevent the damaging effects of
chemicals and sediment. Clean exterior as
needed with hot soapy water and/or disinfec-
tants. Drain drum by tipping forward after
every use and cleaning
Installing Replacement Cable
1. Press non-headed end of pivot pin through
the trigger and remove trigger from handle
(Figure 10). Do not lose the spring.
Figure 10 – Trigger Assembly
2. Pull cable out of drain cleaner until increase
in cable diameter is visible (Figure 9).
5
