Service Manual
Refrigerator
Model : VR-130
Caution

: In this Manual, some parts can be changed for improving, their
performance without notice in the parts list. So, if you need the
latest parts information,please refer to PPL(Parts Price List) in
Service Information Center (http://svc.dwe.co.kr).
DAEWOO ELECTRONICS CO., LTD.
S/M No. : VR1300000
(Basic Mdl. : FRM-116)

Advertisement

Table of Contents
loading

Related Manuals for Daewoo VR-130

Summary of Contents for Daewoo VR-130

  • Page 1 S/M No. : VR1300000 Service Manual Refrigerator Model : VR-130 (Basic Mdl. : FRM-116) Caution : In this Manual, some parts can be changed for improving, their performance without notice in the parts list. So, if you need the latest parts information,please refer to PPL(Parts Price List) in Service Information Center (http://svc.dwe.co.kr).

  • Page 2: Table Of Contents

    SAFETY AND PRECAUTIONS 1) For starters, be sure to check any chances of the leakage of electricity 2) You could handle a part in the vicinity of electricity after unplugging 3) You should put on rubber glovers to prevent an electric shock on operation test 4) Make sure the rated current, voltage, capacity before using an instrument 5) Keep your wet hands away from the metal goods in the freezer compartment not to be frostbitten 6) Be careful not to let water to permeate the electric part in the machine room...

  • Page 3: Specification

    1. Specification 1. Components of Refrigerator Quantity Description Part name Remark White Yellow Ice tray Ice box F room F Shelf F Pocket R shelf Cover vegetable case Vegetable case R room Egg tray Egg pocket Multi pocket Bottle pocket 2.

  • Page 4: Name Of Parts

    2. Name of parts F Louver F room Temp contrtol Knob F Shelf F pocket Ice box * Pocket R Pocket Egg Thermostat Egg tray Lamp R Shelves Pocket Multi Cover vegetable case Vegetable case Pocket Bottle...

  • Page 5: Temperature Adjust Method

    3. Temperature Adjust Method 1) Freezing room temperature adjust method MIDDLE HIGH WINTER HIGH WINTER HIGH WINTER HIGH WINTER HIGH WINTER * Storage of Vegetabl is a lot * Ambient temperature * Storage of Vegetable is * Normal use small blow 10℃...

  • Page 6: Air Flow Diagram

    4. AIR FLOW DIAGRAM Freezer door pocket Do not put ice cream or frozen food in freezer door pocket to Freezer room store for a long team. Opening and shutting the door can rise Do not put in any bottle such as up the temperature.

  • Page 7: Refrigerant Cycle Diagram

    5. Refrigerant cycle diagram SIDE PIPE . Welding point Specification 3% welding 25% welding . Refrigerant circuit COMP → → → → → → → SIDE DRYE CAPI RESS PIPE PIPE PIPE TUBE PIPE HIGH PRES PRESU...

  • Page 8: Wiring Diagram

    6. WIRING DIAGRAM...

  • Page 9: Mechanical Room Lay Out & Parts Name

    7. Mechanical Room Lay out & Parts name PART NAME PART NAME ASSY CABINET COMPRESSOR COVER CABINET PIPE SERVICE BASE CAB AS COVER RELAY PIPE HOT BAND RELAY PIPE *S PLT TIMER , R/CAPACITOR PIPE SUC AS SWITCH P-RELAY AS PIPE CONN (SUC) CORD POWER DRYER AS...

  • Page 10: Electric Parts

    8. Electric Parts 1. COMPRESSOR Description WHITE YELLOW Part name SL17J-5 SL17J-5 Starting Method RSCR RSCR Rated Voltage 220 [V] / 50 [㎐] 220 [V] / 50 [㎐] 2. RELAY WHITE YELLOW Description Part name 174SHBYY-52 174SHBYY-52 Resistance 22[Ω] 22[Ω] 3.TEMPERATURE FUSE WHITE YELLOW...
  • Page 11 6. DEFROST HEATER WHITE YELLOW Description Rated Voltage AC 220 [V] 88 [W] AC 220 [V] 88 [W] Resistance 550 ± 5 % [Ω] 550 ± 5 % [Ω] Glass tube Length 254 [㎜] 254 [㎜] 7. LAMP WHITE YELLOW Description Rated Voltage AC 240 [V] / 15 [W]...

  • Page 12: Methods Of Exchanging Main Parts

    9. Methods Of Exchanging Main Parts 1.Bi-Metal, Temperature Fuse, D Frost Heater 1) Pull out the F louver by pulling forward with inserting screwdriver into the hole of F louver 2) Cut Cable tie with tool 3) Disassemble Bi-Metal 4) Remove Temperature Fuse fixture with "+"...
  • Page 13 2. EVAPORATOR 6) Remove 2 screws with "+"screwdriver. 7) Evaporator move to up ,left,right and pull slightly forward The Right side taken out first at this time * Caution : Connect Pipe bending carefully 8) Disassemble Defrost HTR...
  • Page 14 3. Fan Motor 1) Disassemble Fan Ring 2) Disassemble Fan 3) Disassemble Fan Motor as 4. F/R DOOR 1) Remove 2 screw with "+"screwdrive at Table Panel fixed 2) Disassemble Table Panel from set with "-"screwdrive at center of Table panel rear part...
  • Page 15 3) Table Panel left to up and disassemble F door 4) Remove Middle hinge bolt with 8mm boxer from set and disassemble R door 5. Gasket 1) Disassemble Gasket from door liner home...
  • Page 16 6. D FROST Timer 1) Remove 2 screw and disassemble Power Box with "+"screwdrive 2) Disassemble Timer 7. Control Box 1) Remove 2 screw with "+" screwdrive and pull slightly forward 2) Changed Thermostat if necessary...

  • Page 17: Exploded View And Parts List

    10. Exploded View And Parts List 1) Exploded View DOOR F ROOM MECH ROOM R ROOM...
  • Page 18 2) Parts List  Caution: In this Service Manual, some parts can be changed for improving, their performance without notice in the parts list. So, if you need the latest parts information, please refer to PPL(Parts Price List) in Service information Center(http://svc.dwe.co.kr) PART NAME PART CODE DESCRIPTION...
