Page 1: Installation Guide
Huddle Hub One / Huddle Hub One+ Installation Guide Product version 1.21 – Manual version 01... - Page 2 OR CONSEQUENTIAL DAMAGES (INCLUDING DAMAGES FOR LOSS OF PROFITS, LOSS OF BUSINESS, LOSS OF USE OR DATA, INTERRUPTION OF BUSNESS AND THE LIKE), EVEN IF HRT HAS BEEN ADVISED OF THE POSSIBILITYOF SUCH DAMAGES ARISING FROM ANY DEFECT OR ERROR IN THIS MANUAL OR PRODUCT.
-
Page 3: Table Of Contents
Table of Contents Introduction ............................. 2 Product description ..........................3 Unpack HHO / HHO+ ..........................3 Front panel ..............................5 Rear panel..............................6 Deployment ............................. 8 Page 1... -
Page 4: Introduction
The result is that every place in your company / organization can be used as a Virtual Huddle Room. The Huddle Hub solution is made of two components: • The Huddle Hub unit, currently available in two versions: Huddle Hub One (HHO) and Huddle Hub One+ (HHO+); •... -
Page 5: Product Description
2 Product description 2.1 Unpacking HHO / HHO+ 1 Huddle Hub One / Huddle Hub One+ unit 5 L-shape mounting kit 2 Power cord (localized) 6 VESA mounting kit 3 AC-DC Adapter 7 Screws kit 4 Quick start guide 8 Wi-Fi antennas (HHO+ only) -
Page 6: Quick Start Guide
• The product should not be located in a place where it will be exposed to moisture or excessive heat. • Place HHO in a well-ventilated place, far from any heater or heating vent. • Avoid direct irradiation of any strong light (such as sunlight) and keep at least 2 inches (5 cm) of clear space around your device. -
Page 7: Front Panel
After the first installation, and at every power-on or reboot, HHO connects to the HRT software repository to check for firmware updates and automatically installs its own latest release. For this reason, HHO may appear unresponsive for few minutes after power- on or reboot. -
Page 8: Rear Panel
2.3 Rear panel USB webcam port (HHO+) TV port (HHO+ only) Network port only) Power supply Restore button Antenna (HHO+ only) Antenna (HHO+ only) Power supply Plug the power cord to the AC-DC power supply and connect the power supply to the DCIN connector. Connect the power supply to the wall socket. -
Page 9: Restore Button
To start recovery, turn the unit on and, within 2 seconds, press the restore button for 15 seconds. After the recovery operation, HHO connects to the HRT software repository to check for firmware updates and automatically installs its latest release. -
Page 10: Deployment
3 Deployment 3.1 Usage scenarios As explained in the Introduction, the Huddle Hub product family gives you access to a new and unprecedented collaboration mode, called the Virtual Huddle Room. This means that you can make your presentations and share your documents from the screen of your computer (desktop or laptop) directly to the screen of other devices (computers, tablets or smartphones), with no need for a specifically equipped place. -
Page 11: Network Topology
There are some possible network topologies allowed by HHO and especially by HHO+, described in the following chapters. 3.2.1 Company LAN ③ ② ① ① Internet ② Company router ③ Huddle Hub One / One+ ④ ④ Company access point ⑤ Wi-Fi devices Wired company LAN ⑤ ⑤ Wireless company LAN ⑤... - Page 12 3.3 Company LAN – Clustered ③ ② ① ④ ① Internet ② Company router ③ Huddle Hub One / One+ ④ Company access point ⑤ ⑤ ⑤ Wi-Fi devices ⑤ Wired company LAN Wireless company LAN Internet connection This configuration is similar to the previous one, but describes the case where you have multiple HHO units in the same LAN.
- Page 13 3.3.1 Dedicated network (HHO+ only) ② ① ③ ① Internet ② Company router ③ Huddle Hub One+ ④ ④ Wi-Fi devices ④ ④ Wired company LAN HHO+ wireless network Internet connection HHO+ features an on-board access point, which the Wi-Fi devices can connect to.
- Page 14 3.3.2 Mixed configuration (HHO+ only) ② ① ① Internet ④ ③ ② Company router ③ Huddle Hub One+ ④ Company access point ⑤ Wi-Fi devices ⑤ ⑤ Wired company LAN ⑤ Wireless company LAN HHO+ wireless network Internet connection In a mixed configuration, part of the devices ⑤ reach HHO+③ via a direct connection, and another part via the company LAN through an access point ④.
- Page 15 3.3.3 Station mode (HHO+ only) ② ① ④ ① Internet ② Company router ③ Huddle Hub One+ ④ Company access point ⑤ ⑤ ⑤ Wi-Fi devices ⑤ ③ Wired company LAN Wireless company LAN Internet connection Station mode is useful when you have no way to connect HHO+ to the company LAN with an Ethernet cable.
