  • Page 1 Wireless MIDI Interface User’s Manual ————————————————— Model:WIDI-XU Read “Precautions” on page 5 before use Please ready this manual carefully before use. Please keep this manual for reference.
  • Page 2 Thank you for choosing CME WIDI-XU wireless MIDI interface. Please keep all the important information here. Attach your invoice or receipt here ~~~~~~~~~~~~~~~~~~~~~~~ for reference Purchase date Serial (on the back of the product) Dealer’s name and addr. Dealer’s tel.
  • Page 3 ENVIRONMENTAL ISSUES: cords of any kind. The use of an extension cord is CME strives to produce products that are both not recommended! If you must use an extension user safe and environment friendly. We sincerely...
  • Page 4: Fcc Warning

    1. IMPORTANT NOTICE: DO NOT MODIFY THIS UNIT! This product, when installed as indicated in the instructions contained in this manual, meets FCC requirements. Modifications not expressly approved by CME may void your authority, granted by the FCC, to use the product.
  • Page 5 PRECAUTIONS IMPORTANT Always follow the basic precautions listed below to avoid the possibility of serious injury or even death from electrical shock, damages, fire or other hazards. These precautions include, but are not limited to, the follows: 1、 Read and understand all the instructions. 2、...
  • Page 6 Other precautions: Keep the instrument away from electrical interface sources, such as fluorescent light and electrical motors. Keep the instrument away from dust, heat and vibration. Do not expose the instrument to sunlight. Do not place heavy objects on the instrument; do not place containers with liquid on the instrument.
  • Page 7: Table Of Contents

    Content Features ........................8 System requirement..................... 8 Operation ........................9 Power supply ....................9 Connection......................9 Routing......................10 Radio channel setting ..................10 Removal of the product ................... 11 Automation ........................ 12 Automatic communication establishing ............12 Automatic notes off ..................12 On-line detection.....................
  • Page 8: Features

    1 Features Professional WIDI products with all the function. The working band is 2.4GHz ISM. 64 radio channels for MIDI data receiver, with manual or automatic radio channel setting mode. Manual switching for one-to-multi communication (auto searching and selecting). Compatible with WIDI-X8 and other WIDI devices. RF USB data route.
  • Page 9: Operation

    3.1 Power supply WIDI-XU uses USB bus power. If it is the first time the WIDI-XU is connected to the computer, the OS will automatically install the device driver. Follow the instructions for driver installation. When asked for the device driver, please let the OS automatically search the driver. When the installation is completed, the WIDI-XU will show in the system device list as the “USB Audio...
  • Page 10: Routing

    Channel setting Command: F0 00 20 63 00 07 02 02 10 nn F7 Set the channel of the WIDI-XU to channel “nn”, “nn” is hex number from 01 to 40, indicates channel 1~64, see appendix. If using “WIDI Control.EXE”, select channel, then click “Set Channel” button.
  • Page 11: Removal Of The Product

    3.5 Removal of the product Please follow the below steps to remove the WIDI-XU from your system after using it: Close your music software that accesses WIDI-XU. Find “USB Audio Device” in the Windows Device Manager, stop or uninstall it. You needn’t to do this step if you’re not going to use it again in 5 minutes.
  • Page 12: Automation

    Off” MIDI message to stop the sound from the tone generator. Bad signal with data loss. During the transmitter is switched off. Radio channel changed 4.3 On-line detection After power on, the WIDI-XU will automatically detect the on-line status. The green indicator will show the communication status.
  • Page 13: Notes

    Please make sure the WIDI-XU is properly connected to the computer before you launch you music software. Close your music software before you stop or uninstall the WIDI-XU from the computer. It is recommended that you stop or uninstall the USB Audio device before you unplug the WIDI-XU.
  • Page 14: Appendix

    No. Name Command Description Channel setting F0 00 20 63 00 07 02 02 10 nn F7 Set the channel of the WIDI-XU to channel “nn”, “nn” is a hex number of 01~40 , indicates channel 1~64 Automatically F0 00 20 63 00 07 02 02 10 50 F7...
