CME U2MIDI PRO User Manual

Usb midi interface
Hide thumbs Also See for U2MIDI PRO:

Advertisement

Quick Links

Download this manual
U2MIDI PRO
USER MANUAL V05
Hello, thank you for purchasing CME's professional product!
Please read this manual completely before using this product.
The pictures in the manual are for illustration purposes only, the
actual product may vary. For more technical support content and
videos, please visit this page:
IMPORTANT INFORMATION
WARNING
⚫
Improper connection may cause damage to the device.
COPYRIGHT
⚫
Copyright © 2022 CME Pte. Ltd. All rights reserved. CME is a
registered trademark of CME Pte. Ltd. in Singapore and/or other
countries. All other trademarks or registered trademarks are the
property of their respective owners.
LIMITED WARRANTY
⚫
CME provides a one-year standard Limited Warranty for this
product only to the person or entity that originally purchased this
product from an authorized dealer or distributor of CME. The
warranty period starts on the date of purchase of this product. CME
www.cme-pro.com/support/
1 / 14

Advertisement

loading
Need help?

Need help?

Do you have a question about the U2MIDI PRO and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for CME U2MIDI PRO

Summary of Contents for CME U2MIDI PRO

  • Page 1 Improper connection may cause damage to the device. COPYRIGHT ⚫ Copyright © 2022 CME Pte. Ltd. All rights reserved. CME is a registered trademark of CME Pte. Ltd. in Singapore and/or other countries. All other trademarks or registered trademarks are the property of their respective owners.
  • Page 2 Your delivery or sales receipt, showing the date of purchase of this product, is your proof of purchase. To obtain service, call or visit the authorized dealer or distributor of CME where you purchased this product. CME will fulfil the warranty obligations according to local consumer laws.

  • Page 3: Package Contents

    U2MIDI Pro Interface User Manual INTRODUCTION U2MIDI Pro is a professional USB MIDI interface that provides plug-and-play MIDI connectivity to any USB equipped Mac or Windows computer, as well as iOS (via the Apple USB Connectivity Kit) and Android tablets or phones (via Android OTG cable).
  • Page 4 The U2MIDI Pro has one LED indicator on the USB plug. When the power supply is normal, the green LED light will be lit. When there is data transmission, the green LED light will flash.
  • Page 5 CONNECTION 1. Connect the U2MIDI Pro to the USB-A port of your computer. If the computer does not have a USB-A port, you can use the corresponding adapter cable (not included) or a USB HUB. After connecting, the green LED indicator of the U2MIDI Pro will light up and the computer will automatically recognize the device.
  • Page 6 Note: Only one MIDI plug can be connected to the MIDI device according to actual needs. 3. Open the music software on your computer, set the MIDI input and output ports to U2MIDI Pro on the MIDI settings page, and get started. 6 / 14...

  • Page 7: Software Settings

    “UxMIDI Tool” for macOS or Windows (compatible with macOS X and Windows 7 or higher). You can use it to upgrade the firmware of U2MIDI Pro products at any time and get the latest functions. At the same time, you can adjust advanced functions such as MIDI routing settings and data filtering.
  • Page 8 Image A MIDI Filter Settings After selecting the port in the input window for which the filter is to be set, detailed settings can be made in the setting area below. For example, you can select a MIDI channel to filter all channel messages completely, or select the type of MIDI message to filter for the entire interface (see Figure B).
  • Page 9 U2MIDI Pro. Note: All filter settings will be automatically saved to the internal memory of the U2MIDI Pro. Image B Firmware Upgrade Please connect your computer to the Internet, the software will...
  • Page 10 CME's cloud server to check if there is a latest version of firmware available for update. After loading the new firmware program, click [Start upgrade] to start the upgrade. After the upgrade is complete, the software will display a prompt indicating that the upgrade is successful.
  • Page 11 Settings UxMIDI Tool is a common setting software for CME's newly developed UxMIDI Pro series of professional USB MIDI interfaces. If you have connected multiple MIDI interfaces of the same series to one computer at the same time, please select the product name in the product list of the setting page.

  • Page 12: System Requirements

    SYSTEM REQUIREMENTS Windows: Any PC with a USB port. ⚫ Operating System: Windows XP (SP3) / Vista (SP1) / 7 / 8 / 10 / ⚫ 11 or higher. Mac OS: Any Apple Macintosh computer with a USB port. ⚫ Operating System: Mac OS X 10.6 or later.
  • Page 13 2 meters / 6.56 feet Weight 81.5 g / 2.87 oz Specifications are subject to change without notice. The LED light of U2MIDI Pro does not light up: ⚫ Please check if the USB plug is inserted into the USB port of the computer.
  • Page 14 The computer does not receive MIDI messages when playing a ⚫ MIDI keyboard: Please check if the U2MIDI Pro is correctly selected as the MIDI IN device in your music software. Please check if you ever set up custom MIDI routing through the UxMIDI Tool software.
