Argo POLIFEMO CLASS White Operating Instructions Manual

Argo POLIFEMO CLASS White Operating Instructions Manual

Evaporative air cooler

Advertisement

EN
EVAPORATIVE AIR COOLER
OPERATING INSTRUCTIONS
Read the instructions carefully before operating the appliance or carrying out maintenance operations.
Observe all the safety instructions; failure to observe the instructions may lead to accidents and/or damage.
Keep these instructions in a safe place for future reference.
V 12/16
11

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the POLIFEMO CLASS White and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Argo POLIFEMO CLASS White

  • Page 1 EVAPORATIVE AIR COOLER OPERATING INSTRUCTIONS Read the instructions carefully before operating the appliance or carrying out maintenance operations. Observe all the safety instructions; failure to observe the instructions may lead to accidents and/or damage. Keep these instructions in a safe place for future reference. V 12/16...
  • Page 2: General Safety Information

    GENERAL SAFETY INFORMATION  Only use this appliance as described in this manual. Any other use not recommended by the manufacturer may cause fire, electric shock or injury to people.  Make sure that the type of mains power complies with the electrical requirements of the appliance (220 V~/50 Hz).
  • Page 3 Do not bend or stand heavy objects on the power Do not use the appliance if the cord or plug is cord. damaged. Do not attempt to change the power cord yourself. If the power cord is damaged, it must be replaced by the manufacturer, dealer or a similarly qualified person so as to avoid any safety risks.
  • Page 4: Description Of Parts

    DESCRIPTION OF PARTS 1. Button 9. Remote repository 2. Blade 10. Back shell 3. Function display window 11. Air filter 4. CD grain decorative sheet 12. Reel 5. Front shell 13. Power cord 6. Water level display window 14. Water tank 7.
  • Page 5: Display And Control Panel

    DISPLAY AND CONTROL PANEL ON/OFF SPEED SWING TIMER COOLER/HUMIDIFIER MODE 1. Low speed 2. Medium speed 3. High speed 4. Swing blade 5. Function not available 6. Cooler/humidifier 7. Sleep mode 8. Natural sleep 9. Smart mode V 12/16...
  • Page 6: On/Off Button

    REMOTE CONTROL ON/OFF BUTTON In power on state, press this button, the unit turns off and enters standby mode. In power off state, press this button and all LED lights flash sequentially clockwise; then it enters default working state, except the Timing, Sleep and Natural mode. V 12/16...
  • Page 7: Mode Button

    Below is default working states: MODE BUTTON In power on state, press this button to switch the working mode among Normal, Natural, Sleep e Smart. Normal mode: the unit runs at a constant speed setting; Natural mode: the unit runs at changing wind speed; in natural wind state, LED only displays the set level, which doesn’t change with the wind speed, same as natural wind.
  • Page 8: Protection Functions

    TIMING BUTTON a. After turning on, the timer indicator is turned off by default and the digital tube displays ambient temperature; when the button is first pressed, the timer sets to 30 minutes; the time increases by 30 minutes when the button is pressed every time, and the timer can be set up to 8 hours;...
  • Page 9: Filling The Water Tank

    FILLING THE WATER TANK THE TANK MUST BE FILLED WITH DEMINERALIZED WATER FOR THE APPLIANCE TO OPERATE IN COOLER/HUMIDIFIER MODE. Water tank Water tank Water tank Filling water locked unlocked pulled out Counter-rotate the tank knob by 90° and remove it from its slot; fill it with demineralized water, up to the maximum level mark. Reposition the tank and turn the knob.
  • Page 10 Clean the dust filter using a soft brush or a vacuum cleaner, and wash it in a solution of water and mild detergent. Remove the cooling panel at the same time and soak it in a solution of water and mild detergent.

This manual is also suitable for:

Polifemo class
