Viewing Drive Assignments

The View Drive Assignments <2> option i n the Main Menu displays whether drives
are assigned to a disk arrays or are unassigned.
Under the "Assignment" column, drives are labeled with their assigned disk array
or shown as "Free" if unassigned. Such "Free" drives can be used for a future
array or used as a spare drive when a drive fails in a mirrored array. Unassigned
drives are not accessible by the OS. The menu also displays the data transfer
mode that relates to speed used by each drive (U5 refers to 100MB/sec transfers,
U4 refers to 100MB/sec transfers, etc...)
FastBuild (tm) Utility 1.xx (c) 1995-2000 Promise Technology, Inc.
Channel:ID Drive Model
1 : Master QUANTUMCR8.4A
1 : Slave QUANTUMCR8.4A
2 : Master QUANTUMCR8.4A
[ ] Up [ ] Down [ESC] Exit Mode (U=UDMA, P=PIO, D=DMA)
FastTrak100 User Manual
[ View Drive Assignments ]
Capacity(MB) Assignment Mode
8063 Array 1
8063 Free
8063 Array 1
[ Keys Available ]
21
U5
U5
U5
